DWV303
VESTA™ DWV303B
Automatic Compact
Dishwasher
Installation
Instructions and
Use & Care Guide
™
Compact Dishwasher
READ ALL INSTRUCTIONS BEFORE USING
Contents
DOOR OPEN
POWER
SANIWASH
SANI
ECONO
POWER
ON
OFF
1
2
3
4
5
6
7
7
7
8
9
9
10
10
11
Advertisement
Table of Contents
Related Manuals for Vesta DWV303B
Summary of Contents for Vesta DWV303B
-
Page 1: Table Of Contents
™ DWV303 VESTA™ DWV303B Automatic Compact Dishwasher Installation Instructions and Use & Care Guide Compact Dishwasher Contents Unit Parts Identifi cation Important Safety Instructions Installation Instructions Installation Requirements Built-in Installation Countertop Installation Disconnecting Your Dishwasher Use & Care Guide Loading the Dishwasher... -
Page 3: Unit Parts Identifi Cation
UNIT PARTS IDENTIFICATION 1. WINDOW 2. FRONT PANEL 3. DOOR RELEASE BUTTON 4. LED (POWER) 5. LED (SANIWASH) 6. SANIWASH/ECONO BUTTON 7. POWER (ON/OFF) BUTTON 8. PROGRAM/TIMER SELECTOR 9. WATER INLET CONNECTION 10. DRAIN HOSE CONNECTION 11. POWER CORD - 6’ Length (182.8 cm) 12. -
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS WARNING When using your dishwasher, follow basic safety precautions: - Read all instructions before using the dishwasher. - Use the dishwasher only for it’s intended use. - Use only detergents or wetting agents recommended for use in a dishwasher and keep them out of reach of children. -
Page 5: Installation Instructions
INSTALLATION INSTRUCTIONS INSTALLATION REQUIREMENTS All Installations - Remove all packing materials carefully. - Make sure the electrical power supply is within easy reach of the machine. The power cord is 6 Feet (182.8 cm) long. - Supply shut-off valves should be easily accessible. - If the water pipes you will be connecting to are new or un- used, run the water until clear to remove any debris that could clog the water valves before connecting the... -
Page 6: Built-In Installation
INSTALLATION INSTRUCTIONS If you specifi ed a built-in installation, your dishwasher came with the Built-In Hose Kit (Part# DWVBIHK) and Built-In Trim Kit (Part# DWVTKBL). Installation Location - This dishwasher is approved for built-in installations. - Air space requirements: Sides=3/16” (.48 cm), Top/Bottom=1-1/8”... -
Page 7: Countertop Installation
INSTALLATION INSTRUCTIONS COUNTERTOP INSTALLATION If you specifi ed a countertop installation, your dishwasher came with a Quick-Connect Faucet Adapter Kit (Part# DWVCTHK) that includes a fi ll and drain hose assembly that is compatable with both male (exterior) and female (interior) threaded faucet connections. -
Page 8: Disconnecting Your Dishwasher
INSTALLATION INSTRUCTIONS DISCONNECTING YOUR DISHWASHER When the cycle is complete, always relieve water pressure from the inlet hose: - Close the HOT water supply at the stopcock. - Disconnect the Power Supply Cord For Built-In Installations Periodically inspect and replace hoses if bulges, kinks, cuts, wear, or leaks are found. -
Page 9: Use & Care Guide
USE AND CARE GUIDE LOADING THE DISHWASHER The dishwasher is designed to receive a standard “4 piece” plate setting consisting of the following: - 4 Dinner Plates - 4 Bread & Butter Plates - 4 Fruite Bowls - 4 Cups and Saucers - 4 Dinner Forks - 4 Dinner Knives - 4 Salad Forks... -
Page 10: Pre-Rinse, Sani, Econo Features
USE AND CARE GUIDE Unscrew the Rinse Agent Dispenser Cap, then use the Measuring Container (provided) to fill the dispenser PRE-RINSE FEATURE The “Pre-Rinse” is a convenience feature that allows dishes to be rinsed, if you don’t have a full load ready to be washed. -
Page 11: Operating Instructions
USE AND CARE GUIDE PROGRAM SUMMARY/SELECTION PRE-RINSE Water Temperature: Incoming Water (Tank Temperature) Program Duration: 6 Minutes Water Consumption: 0.84 gal. (3.2 liters) NORMAL/SANIWASH Water Temperature: 154°F / 68°C Program Duration: 35 Minutes Water Consumption: 3.3 gal. (12.8 liters) NORMAL/ECONO Water Temperature: Incoming Water (Tank Temperature) -
Page 12: Troubleshooting Common Problems/Solutions Chart
COMMON PROBLEMS & SOLUTIONS PROBLEM Dishwasher will not start Dishes not clean Chipping or breaking glassware Water remains in bottom IF YOU NEED SERVICE This Vesta™ appliance comes with a Limited Warranty (please read the Limited Warranty Statement that came with your dishwasher for complete details.) You’ll fi... -
Page 13: Warranty Statement
If the machine fails to operate due to any defects in material or workman- ship it will be repaired at no cost to you at Westland Sales. Parts will be supplied at no cost during the warranty period for fi eld repairs by your installer or any authorized repair center. - Page 14 ™ Vesta DWV303 Automatic Compact Dishwasher Westland Sales Corporate Headquarters : Clackamas, OR Westland Sales Elkhart Operations: Elkhart, IN Phone: 503-655-2563 Toll-Free: 800-356-0766 www.westlandsales.com © 2003 Westland Sales...
