- Page 1 HOT TAP WATER HEATERS type WJ/W-Q with a helical coil and an electric heater INSTALLATION AND USER’S MANUAL GUARANTEE TERMS ver.01/2 PANNEX DUO COMBI VVB 160L...
-
Page 2: Table Of Contents
Please read „Instructions for Use” and „ Warranty Terms and Conditions” carefully before heater installation and start up. Heater installation and start up should be performed in accordance with the “Instructions for Use” by a qualified person. ver.01/2 PANNEX DUO COMBI VVB 160L... -
Page 3: Construction And Use
The heaters should be mounted on walls or other suitable and solid constructions in vertical position. The heater PANNEX DUO COMBI VVB 160L is additionally equipped with the so-called “dry” electric heater with the heating power of 3000 W supplied with the three-phase electric current of ~400 V. - Page 4 CT – Temperature sensor ø16 mm 1¼” AN – Magnesium Anode [30 x 270] Picture 1. Construction and dimensions of PANNEX DUO COMBI VVB 160L heaters. Table 1. Technical specification of PANNEX DUO COMBI VVB 160L heaters ver.01/2 PANNEX DUO COMBI VVB 160L...
-
Page 5: Installation
The spiral coil pipe may be supplied with water from the low-temperature water boiler ver.01/2 PANNEX DUO COMBI VVB 160L... -
Page 6: Connecting To The Wiring System
2 – thermostat with the temperature switch regulator LS1, LS2 – signaling lamps Picture 2. The wiring diagram of the PANNEX DUO COMBI VVB 160L heater Connecting to the power supply system may be performed only by a qualified person. -
Page 7: Start-Up
2. During the work of the heater the magnesium anode rod slowly depletes so its condition should be checked periodically, at least once every 18 months and it ver.01/2 PANNEX DUO COMBI VVB 160L... -
Page 8: Warranty Terms And Conditions
Warranty Card and confirmed by a proof of purchase (receipt) written and stamped by the vendor. 4. The guarantor guarantees a faultless operation of the heater on the condition that it is installed and used in accordance with this Instructions for Use. ver.01/2 PANNEX DUO COMBI VVB 160L... - Page 9 - PN - EN 61000-3-2 - PN - EN 61000-3-3 - PN - EN 55014-1 Gołuszowice, 06. lipiec. 2017r. …………………………………………………….….. ………………………………………………… (imię i nazwisko oraz podpis) (miejsce i data wystawienia) (place and date) (Name, Surname and Signatu ver.01/2 PANNEX DUO COMBI VVB 160L...
- Page 10 PANNEX DUO COMBI VVB 160L...
- Page 11 PANNEX DUO COMBI VVB 160L...
- Page 12 PANNEX DUO COMBI VVB 160L...
