  • Page 1 USER’S MANUAL MANUEL DE L’UTILISATEUR MANUAL DEL USUARIO SK-26H240S SK-26H520S Widescreen HDTV TVHD à Écran Géant TVHD Pantalla Grande...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS IMPORTANT SAFETY AND PRECAUTIONS ...1 Important Information...1 Safety Precautions...2 GENERAL INFORMATION...4 Feature...4 Controls and Ports of the Panel...5 Accessories ...7 Remote Control...8 INSTALLATION & FUNCTION ADJUSTMENT ...10 Installation... ……………10 How to remove the Base ... ……………13 Function Adjustment ...14 TROUBLESHOOTING ...25 PC INPUT PRESET TIMMING TABLE...29 PRODUCT SPECIFICATION ...30...
  • Page 3: Important Safety And Precautions

    IMPORTANT SAFETY AND PRECAUTIONS This wide active matrix TFT (thin film transistor) liquid crystal monitor is designed for use as a stand alone TV as well as a display device for video electronics appliances and personal computers. Important Information Warning : To reduce the risk of fire or electric shock, do not expose this product to rain or moisture.
  • Page 4: Safety Precautions

    Safety Precautions 1. Cleaning : Unplug the power cord from the AC outlet before cleaning the product. Use a damp cloth to clean the product. Do not use liquid cleaners or aerosol cleaners. 2. Water and moisture : Do not use the product near water or areas of high moisture content such as swimming pools, bathtubs or wet basements.
  • Page 5 7. Stand : Do not place the product on an unstable cart, stand, tripod or table. Placing the product on an unstable base can cause the product to fall, resulting in serious personal injuries as well as damage to the product. Use only a cart, stand, tripod, bracket or table recommended by the manufacturer or sold with the product.
  • Page 6: General Information

    GENERAL INFORMATION Feature Your TV is designed with the latest technology and is a high-performance unit that includes the following special feature : Multi-sources input included RF IN, D-SUB, HDMIx2, Compositex2, S-Videox2, and Componentx2. Built-in combo tuner is able to receive ATSC, NTSC and Clear QAM Cable signals. Built-in 10W dual channel speakers.
  • Page 7: Controls And Ports Of The Panel

    Controls and Ports of the Panel Remote sensor window & Power indicator FUNCTION KEYS 1. MENU : Display the main menu. When OSD is appeared, press the button to select or access the sub-menu. 2. VOLUME (+ / -) : Increase/decrease the volume or be the left/right arrow button for menu.
  • Page 8 1. S-Video1 input Connect to a legacy video device such as a VCR or video game system. 2. S-Video2 input 3. Video1 & S-Video1 Audio input Connect an external audio source to this jack. 4. Video2 & S-Video2 Audio input Connect an external audio source to this jack.
  • Page 9: Accessories

    Accessories LCD - TV User’s Manual Remote Control & Batteries Quick connect Power Cord Quick Connect Guide Warranty Card Warranty Card Screw driver & Screws x4(base)
  • Page 10: Remote Control

    Remote Control Power Switch TV power on/off. Mute Turn the sound on/off. Swap No support No support Backlight No support Sleep Press to select a preset time interval for automatic power down. Press to enable or disabled closed caption. Favorite Select, remove or add your favorite channel.
  • Page 11 Guide Broadcast program information. Info. Display the source and channel information. YPbPr1 Select YPbPr1 or 2 source input. Select TV(NTSC/ATSC) source input. Select VGA source input. HDMI Select HDMI 1 or 2source input. YPbPr2 Select YPbPr2 source input. No support. Video Select Video 1 or 2 input.
  • Page 12: Installation & Function Adjustment

    INSTALLATION AND FUNCTION ADJUSTMENT Installation 1. Insert Batteries into Remote Control 1) Remove the battery cover. 2) Insert two size AAA batteries corresponding to (+) and (-) marks on the battery compartment. CAUTION ‧ Only use AAA batteries. ‧ Do not mix new and old batteries. This may result in cracking or leakage, which may pose a fire risk or lead to personal injury.
  • Page 13 2. Connections...
  • Page 14 3. Connect power cables Connect the power cord to the LCD TV then to a proper AC outlet. IMPORTANT: The power input voltage for TV is 120Vac, before beginning; make sure all devices are turned off. 4. Turn Power On Press the power button on the right side of the LCD TV, or press the power (Red) button on the remote control.
  • Page 15: How To Remove The Base

    How to remove the BASE a. Carefully place the TV face down on a soft clean surface. b. Remove the four screws underneath the BASE. (See picture below) c. Pull out the BASE from the TV.
  • Page 16: Function Adjustment

    Function adjustment There are four main Setup Menus; these are Settings, Channels, Locks and Guide. All the functions can be adjusted either by the remote control or by using the control keys on the LCD TV’s right side. Viewing OSD Menu To display the main menu, press the Menu button on the right side of front control keys of the LCD TV or the MENU key on the remote control.
  • Page 17: Video Settings

    Menu/Exit Exit to previous menu Right Enter Down Video Video settings: Press arrow keys to select or adjust your favorite picture settings. DONE button to close picture setting menu.
  • Page 18: Audio Setting

    Screen Fit: Adjust your TV screen to handle different picture formats. Standard/Fill/Overscan/DVD Restoration Color Temp.: Press arrow keys to select or adjust your preferred color temperature settings. Cool/Neutral/Warm/User 3D Comb Filter: Press arrow keys to select or adjust your preferred settings. Off/Low/Medium/High Temporal NR: Press arrow keys to select or adjust your preferred settings.
  • Page 19 Use arrow keys to adjust the bass, treble and balance. Optical Out Select AC3/PCM Analog Preference Select an analog audio preference if TV signal is analog. Mono/Stereo/SAP Digital Preference Select language preference for digital channels. English/French/Spanish Settings Close Captions Basic Selection...
  • Page 20: Menu Language

    Choose the type of closed caption settings to use for programs broadcast with basic caption. Advanced Selection Use arrow keys to adjust closed caption appearance such as font and size, each change can be previewed on bottom of menu. Caption Preference Select Always Basic/Always Advanced/Automatic.
  • Page 21: Power Management

    Input Autosource Autosource can detect new source which is plugged in TV and switch input source setting of your TV to the source automatically. Power Management Set TV power saving modes(Normal/quick boot-up time, but large power consumption; Energy saving/longer boot-up time, but small power consumption.) Power On Plug Set TV power on memory when un-plug power cord and re-plug it.(ON/automatic power-on...
  • Page 22: System Info

    System Info Display important system info, you may need the information when calling customer service or troubleshooting such as firmware version and micro version. Press DONE button or arrow key to previous menu. RESET ALL Reset all settings back to factory defaults. Reset will delete all settings you have made including channel list.
  • Page 23 Master Channel list To display which channels have been scanned. Scan Channels To auto scan current available channels by using “Antenna or cable” scan. Favorites To display which channels have been set for Favorites.
  • Page 24 Find Channel Enter channel number via number key then press DONE button to find a channel. You may be required to enter four digits pin number if pin number was set before. Channel Name Edit Edit the channel name in channel list. Enter the edited channel, press “enter” button of remote control, shows “Change name”...
  • Page 25 Rating Locks Select which USA or Canada rating you want to set. USA TV Rating TV Y All children TV Y7 For older children TV G General audience TV PG Parental guidance suggested TV 14 Parental strongly cautioned TV MA Mature audience only USA Movie Rating General audience Parental guidance suggested...
  • Page 26: Channel Locks

    8 ans+ Children eight years and older 13 ans+ Viewers 13 year and older 16 ans+ Viewers 16 year and older 18 ans+ Adult programming Canada-English Children Children eight years and older General programming, suitable for all audience Parental guidance Viewers 14 year and older Adult programming Channel Locks...
  • Page 27: Troubleshooting

    TROUBLESHOOTING...
  • Page 28 There is no picture or sound. ▪ Make sure the AC adapter is connected. ▪ Verify that there is a valid source signal. ▪ Make sure the correct input mode is selected. There is no picture from AV. ▪ Make sure the BRIGHTNESS is properly adjusted. ▪...
  • Page 29 Picture is light or improperly tinted. ▪ Check the Hue, Saturation and Color adjustments. ▪ Reset the TV to the factory default settings. The picture is too dark. ▪ Select a different Video Preset mode. ▪ Check the Brightness of Picture Settings. ▪...
  • Page 30 The picture is not sharp. ▪ The signal source may be weak. ▪ The provider may be experiencing difficulties. ▪ Check input connections. ▪ Check the Sharpness of Picture Settings. The picture moves. ▪ The source signal may be weak. ▪...
  • Page 31: Pc Input Preset Timming Table

    PC INPUT PRESET TIMMING TABLE PC / Timing Table No. Mode Name H.Freq. H. Polarity Pixel Resolution V.Fre. V. Polarity (MHz) VGA 70HZ 31.469 28.322 720*400 70.087 VGA 60HZ 31.469 25.175 640*480 59.941 VGA 67HZ 35.00 30.24 640*480 66.667 VGA 72HZ 37.861 31.5 640*480...
  • Page 32: Product Specification

    PRODUCT SPECIFICATION ITEMS Screen Size Aspect Ratio Panel Resolution Display colors Viewing Angle (CR>10) Broadcasting System Receiving Channel TV Function Sound System Resolution Data Broadcasting Composite Signal Video Input Y, C Signal Component Signal HDMI Connection PC Input VGA Connection Scanning Frequency Audio 1 Audio Input...
  • Page 33 Westinghouse Digital Electronics Santa Fe Springs, CA SE-UM-2602-0701...
