- Page 1 USER’S MANUAL MANUEL DE L’UTILISATEUR MANUAL DEL USUARIO L2270NW Monitor Moniteur...
- Page 2 Westinghouse Digital Electronics Santa Fe Springs, CA SE-UM-2204-0701...
-
Page 3: Table Of Contents
CONTENTS IMPORTANT PRODUCT SAFETY INSTRUCTIONS ...2 ...3 AFETY UIDELINES FCC C OMPLIANCE TATEMENT CLEANING THE LCD MONITOR...4 FEATURES...5 ...5 OWER AVER & P ...5 INSTALLATION ...6 ...6 ACKAGE ONTENTS 1. A TTACHING THE TAND TO THE 2. C ONNECT OMPUTER AND 3. -
Page 4: Important Product Safety Instructions
• Do not attempt repairs yourself. Your warranty does not cover repairs or attempted repairs by anyone not authorized by Westinghouse Digital Electronics. • If your LCD Monitor will not be used for a long period of time, unplug the LCD Monitor. -
Page 5: Safety Guidelines
If a BNC cable used, use only a shielded BNC (5) cable. Also, any unauthorized changes or modifications not expressly approved by Westinghouse Digital Electronics will void the user's authority to operate this device. -
Page 6: Cleaning The Lcd Monitor
Westinghouse Digital Electronics does not recommend the use of any ammonia or alcohol-based cleaners on the LCD Monitor screen or case. Some chemical cleaners have been reported to damage the screen and/or LCD Monitor case. Westinghouse Digital Electronics will not be liable for damage resulting from the use of any ammonia or alcohol-based cleaners. -
Page 7: Features
FEATURES • Bright Display Image • Ultra Fast Response Time • Built-in Speakers (optional) • Power Saver • Plug & Play • Kensington Security Lock Compatible (optional) Power Saver A power control system, Power Saver, is installed inside the LCD monitor. If the LCD monitor has not been used for a certain period of time, the system will turn the LCD monitor to low voltage mode to save electrical power. -
Page 8: Installation
INSTALLATION Congratulations on your purchase of a Westinghouse widescreen LCD Monitor. Sleek and practical, this lightweight LCD monitor delivers a bright and clear display optimized for high display resolution from your PC or notebook computer. Package Contents Your product package includes: •... -
Page 9: Control Panel Buttons
Control Panel Buttons Use the control buttons in the front of the LCD Monitor to display the On Screen Display (OSD) menu. Below is a list of the control button functions. The OSD controls are defined in “OSD Functions” on page 8. ▲... -
Page 10: Osd Menu Functions
OSD Menu Functions All the function settings for this LCD monitor are controlled via the control keys located on the side of the monitor. To display the OSD main menu, press the display will disappear automatically after approximately 10 seconds, if no action is taken.) This LCD monitor has been adjusted to optimal settings before shipment. -
Page 11: Quick Adjustments
Quick Adjustments You can skip the Menu pages and display an adjustment scale directly by using the following button operations: • Press the Brightness: • Press the Contrast button when the Menu is not displayed. Contrast: • Press the ▼ button when the Menu is not displayed. Auto Setting: •... -
Page 12: Display Modes
Display Modes The monitor backlighting can be controlled by using the ▲ key on the control keypad. There are 3 modes: Economy, Text, and Picture. To toggle between these modes, press the ▲ key until the mode you desire is selected. -
Page 13: Troubleshooting
Troubleshooting No Power • Make sure the AC cord is plugged into the back of the LCD monitor. • Make sure the AC power cord is securely connected to an AC outlet. • Plug another electrical device (like a radio) to the power outlet to verify that the outlet is supplying the proper voltage. -
Page 14: Image Is Not Centered (Size Is Not Scaled Correctly)
Audio input of the monitor will switch to its 3.5 mm stereo jack automatically. Additional Questions • See our website at www.wde.com. • Contact Westinghouse Digital Electronics Customer Service at (866) 287-5555 or write us at service@westinghousedigital.com. Please visit our website for more information...
