Westell 2200 User Manual

Dual connect nat router with dmh technology
Hide thumbs
Table of Contents

Advertisement

Quick Links

)
D
C
NAT R
(M
2200
UAL
ONNECT
OUTER
ODEL
TM
DMH
WITH
TECHNOLOGY
U
G
SER
UIDE
© Copyright 2003 Westell, Inc.
i
030-300372 Rev. A
July 2003

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2200 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Westell 2200

Summary of Contents for Westell 2200

  • Page 1 NAT R 2200 ONNECT OUTER ODEL WITH TECHNOLOGY UIDE © Copyright 2003 Westell, Inc. 030-300372 Rev. A July 2003...

  • Page 2: Table Of Contents

    User Guide TABLE OF CONTENTS 1. PRODUCT DESCRIPTION ...1 2. SAFETY INSTRUCTIONS ...1 3. REGULATORY INFORMATION ...2 FCC Compliance Note...2 Canada Certification Notice...3 4. SYSTEM REQUIREMENTS...4 Minimum System Requirements for 10/100 Base-T/Ethernet Installation ...4 Minimum System Requirements for USB Installation ...4 5.
  • Page 3 User Guide 10. STATUS...42 10.1 Connection Summary ...42 10.2 About ...43 11. CONFIGURATION ...44 11.1 VC Configuration ...44 Configuring the Router’s Protocol Settings...48 11.2 DNS Configuration...52 11.3 DHCP Configuration (Private LAN) ...54 11.4 Private LAN Configuration ...58 11.5 Public LAN Configuration...59 11.6 Single Static IP Configuration ...64 11.7...
  • Page 4 User Guide 14.7 LAN Statistics...106 15. HELP...107 16. NAT SERVICES...119 17. TECHNICAL SUPPORT INFORMATION ...123 18. WARRANTY INFORMATION ...123 19. PRODUCT SPECIFICATIONS...124 20. SOFTWARE LICENSE AGREEMENT...125 21. PUBLICATION INFORMATION...126 030-300372 Rev. A Westell Dual Connect NAT Router with DMH Technology July 2003...

  • Page 5: Product Description

    User Guide 1. PRODUCT DESCRIPTION The Westell® Dual Connect NAT Router with DMH existing home or office phone line. Your ADSL connection is “always-on” ending the hassles of dial-up modems and busy signals. Installation is easy ... no tools ... no headaches. Simply connect the hardware, apply power, and perform the simple software configuration for your Dual Connect NAT Router.

  • Page 6: Regulatory Information

    PART 68 - COMPLIANCE REGISTRATION This equipment (Model 2200) complies with Part 68 of the FCC rules and the requirements adopted by the ACTA. A label on the bottom of this equipment contains, among other information, the Ringer Equivalence Number (REN), and the product identifier.

  • Page 7: Canada Certification Notice

    If you experience trouble with this equipment (Model 2200), do not try to repair the equipment yourself. The equipment cannot be repaired in the field and must be returned to the manufacturer. Repairs to certified equipment should be coordinated by a representative, and designated by the supplier.

  • Page 8: System Requirements

    User Guide 4. SYSTEM REQUIREMENTS 4.1 Minimum System Requirements for 10/100 Base-T/Ethernet Installation The following system specifications are required for optimum performance of the Dual Connect NAT Router via 10/100 Base-T installation: • Pentium or equivalent and above class machines, Macintosh ®...

  • Page 9: Installing The Hardware

    User Guide 5. INSTALLING THE HARDWARE 5.1 Installation Requirements To install the Dual Connect NAT Router, you will need the following: • A Network Interface Card (NIC) installed in your PC or • An available USB port installed on your PC. •...
  • Page 10 User Guide 5.4.1 Router Installation via 10/100 Base-T Ethernet NOTE: Before you connect the Dual Connect NAT Router via 10/100 Base-T, you must have an available Ethernet card installed in your computer. If your Ethernet card does not auto-negotiate, you must set it to half duplex.
  • Page 11 User Guide 5.4.2 Router Installation via USB NOTE: The USB installation will not function for Macintosh computers. Macintosh computers must install the Router via Ethernet connection. See section 5.4.1. 1. Connect the power supply cord to the power connector marked other end of the power supply into an AC wall socket.

  • Page 12: Led Indicators

    User Guide 5.5 LED Indicators The LED indicators are used to verify the unit’s operation and status. LED states are described in Table 1. State Solid Green POWER No Light Slow Flashing Green Moderate Flashing Green READY Solid Green Steady Red (less than 20 sec.) Flashing Yellow Solid Yellow No Light...
  • Page 13 User Guide SYMBOL LINE 6-pin RJ-11 modular jack 4-pin USB Series B connector ∼ POWER Barrel connector ETHERNET 8-pin (RJ-45) modular jack Table 4. USB Series B Connector Pinouts 030-300372 Rev. A Westell Dual Connect NAT Router with DMH Technology Table 2.

  • Page 14: Installing The Usb Drivers

    User Guide 6. INSTALLING THE USB DRIVERS This section explains how to install the USB modem drivers for the Dual Connect NAT Router. If you are using only Ethernet ports, USB driver installation is not necessary. The Microsoft® Plug and Play auto-detect feature recognizes when new hardware has been installed.
  • Page 15 User Guide Westell Dual Connect NAT Router with DMH Technology Figure 5. Add New Hardware 2. Windows 98: Click the option button for Search for the best driver for your device. (Recommended). See Figure 6. Click Next. Figure 6. Windows 98 030-300372 Rev.
  • Page 16 User Guide 3. Windows 98: Select CD-ROM drive option. See Figure 7. Click Next. Windows will search for the driver. 4. Windows 98: Select option button The updated driver (Recommended) Westell Dual Connect Modem. See Figure 8. Click Next. Note: If Figure 8 does not appear at this step, and Figure 9 appears with the text ‘USB Composite device’, ‘C:\Windows\Inf\USB.Inf’, do not continue.
  • Page 17 User Guide 5. Windows 98: Windows will display the location of the driver. See Figure 9. Click Next. Note: The drive “letter” may vary. 6. Windows 98: Remove the Westell CD from the CD-ROM Drive. Next, insert the Windows operating system CD into the CD-ROM Drive.
  • Page 18 User Guide 8. Windows 98: Figure 12 may pop up, depending on how Windows 98 was installed on the computer. The installation of the Westell modem requires files that are supplied by Microsoft for Windows 98. If Figure 13 pops up, insert the Windows 98 Operating System CD into the computers CD-ROM drive, wait a moment for the CD to be recognized by the system, and then click on OK.
  • Page 19 User Guide 9. Windows 98: The window below confirms that the PC has finished loading the drivers (Figure 14). Click Finish. 10. Windows 98: Click Yes to restart your computer. See Figure 15. Congratulations! You have completed the software installation for the USB drivers. After the computer has restarted, the Router is ready for use.

  • Page 20: Installing The Usb Drivers For Windows Me

    User Guide 6.3 Installing the USB Drivers for Windows ME 1. Windows ME: After you have connected the Dual Connect Modem to your PC, the Found New Hardware window appears (Figure 16). In a few moments, the Add New Hardware Wizard window appears (Figure 17). Click the option button for Automatic search for a better driver (Recommended).
  • Page 21 User Guide 3. Windows ME: The window below confirms that the PC has finished loading the drivers. See Figure 19. Click Finish. 4. Windows ME: When the System Settings Change screen appears, the USB drivers are installed properly. See Figure 20. Click Yes. Congratulations! You have completed the software installation for the USB drivers.

  • Page 22: Installing The Usb Driver For Windows 2000

    User Guide 6.4 Installing the USB Driver for Windows 2000 1. Windows 2000: After you have connected the Westell Dual Connect Modem to your PC, the Found New Hardware window appears (Figure 21). In a few moments, the Found New Hardware Wizard window appears (Figure 22).
  • Page 23 User Guide 2. Windows 2000: The Install Hardware Device Drivers window appears. Select Search for a suitable driver for my device (recommended) See Figure 23. Click Next. 3. Windows 2000: The Driver Files Search Results window appears. Select the CD-ROM drives option See Figure 24).
  • Page 24 User Guide 4. Windows 2000: The Driver Files Search Results window appears (Figure 25). Click Next. Note: The drive “letter” may vary. F:\WSTLVRTR.INF 5. Windows 2000: The window below confirms that the PC has finished loading the drivers (Figure 26). Click Finish.

  • Page 25: Installing The Usb Driver For Windows Xp

    User Guide 6. Windows 2000: When the System Settings Change screen appears, the USB drivers are installed properly. See Figure 27. Click Yes. Congratulations! You have completed the software installation for the USB drivers. After the computer has restarted, the Router is ready for use. You must now go to section 7. 6.5 Installing the USB Driver for Windows XP 1.
  • Page 26 User Guide Westell Dual Connect NAT Router with DMH Technology 2. Windows XP: The window below confirms that the PC has finished loading the drivers (Figure 29). Click Finish. Figure 29. Windows XP Congratulations! You have completed the software installation for the USB drivers. After the computer has restarted, the Router is ready for use.

  • Page 27: Configuring The Router For Internet Connection

    User Guide Westell Dual Connect NAT Router with DMH Technology 7. CONFIGURING THE ROUTER FOR INTERNET CONNECTION To surf the Internet using your Westell Dual Connect NAT Router, you must set up your account profile, confirm your DSL sync, and establish a DHCP/PPP session with your Internet service provider (ISP). Refer to the Internet service provider’s installation manual to install the software required for your Internet connection.
  • Page 28 User Guide If you clicked on next, the following screen will be displayed. This screen will allow you to set up your account profile. NOTE: Before you set up your account profile, you must obtain your Account ID, Account Password, and VPI/VCI values from your Internet service provider.
  • Page 29 User Guide Enter the VPI and VCI values (0 for VPI and 35 for VCI) you obtained from your Internet service provider. Click on next. NOTE: Depending on your Internet Service Provider, the VPI/VCI screen may come pre-configured and it will be displayed here. In this case, you should not change any values in this screen.
  • Page 30 User Guide Select the Protocol type that you obtained from your Internet Service Provider. Click on next. NOTE: Depending on your Internet Service Provider, the PROTOCOL screen may come pre-configured and it will be displayed here. In this case, you will need to click on next to go to the SET-UP COMPLETE screen.

  • Page 31: Establishing A Ppp Session

    User Guide Westell Dual Connect NAT Router with DMH Technology If you clicked on OK in the preceding screen, the following screen will be displayed. This screen shows that the Router is being reset. 7.2 Establishing a PPP Session View the Connection Rate at the Connection Overview section in the following Home page. If this status reads No DSL Connection, check the DSL physical connection, explained in section 5 (INSTALLING THE HARDWARE).
  • Page 32 User Guide Westell Dual Connect NAT Router with DMH Technology If you clicked on connect, the following screen will appear briefly. The PPP Status in the Connection Overview screen allows you to view the state of your ISP connection. When the PPP Status displays Connecting…, this means that you are establishing a PPP session.

  • Page 33: Disconnecting A Ppp Session

    User Guide Westell Dual Connect NAT Router with DMH Technology Once a PPP session has been established, the PPP Status will display UP. Congratulations! You may now surf the Internet. 7.3 Disconnecting a PPP Session If you are ready to disconnect from your Internet service provider, click on the Disconnect button in the Connection Overview screen (the preceding screen).
  • Page 34 User Guide Westell Dual Connect NAT Router with DMH Technology The screen below will appear briefly. When the PPP Status displays Disconnecting…, this means that you are disconnecting from your PPP session. If you clicked the Disconnect button in the preceding Connection Overview screen, the PPP Status should display DOWN.

  • Page 35: Service Configuration

    User Guide Westell Dual Connect NAT Router with DMH Technology 7.4 Service Configuration To use an application that utilizes the NAT (Network Address Translation) protocol, you will have to configure your Router’s NAT settings. Select Service Configuration from the Configuration menu. Westell has developed an extensive list of NAT services, and you may select any service from this list.
  • Page 36 User Guide Westell Dual Connect NAT Router with DMH Technology If you clicked on enable, the following Host Service screen will be displayed. Click on OK. This will load the new NAT Configuration and the settings will be saved automatically. If you clicked on OK in the Host Service? screen, the Host Device screen will be displayed.
  • Page 37 User Guide Westell Dual Connect NAT Router with DMH Technology If you select details, the screen below will be displayed. It contains the service name, type, protocol, and port information for the NAT service you selected. Click on close to continue. 030-300372 Rev.

  • Page 38: Exiting The Dual Connect Nat Router

    User Guide Westell Dual Connect NAT Router with DMH Technology 7.5 Exiting the Dual Connect NAT Router When you are ready to exit this interface, click on X (close) in the upper right-hand corner of the homepage window. NOTE: Closing this window will not affect your PPP Status (your PPP session will not be disconnected). You must click on the disconnect button to disconnect your PPP session.

  • Page 39: Setting Up Macintosh Os X

    User Guide 8. SETTING UP MACINTOSH OS X This section provides instructions on how to use Macintosh Operating System 10 with the Westell Dual Connect NAT Router. Follow the instructions in this section to create a new network configuration for Macintosh OS X. NOTE: The USB installation will not function for Macintosh Computers.
  • Page 40 User Guide Westell Dual Connect NAT Router with DMH Technology Create a New Location After selecting the Network icon at the System Preferences screen, the Network screen will be displayed. Select New Location from the Location field. Name the New Location After selecting New Location from the Network screen, the following screen will be displayed.
  • Page 41 User Guide Westell Dual Connect NAT Router with DMH Technology Select the Ethernet Configuration After clicking on OK in the previous step, the Network screen will be displayed. The Network screen shows the settings for the newly created location. From the Configure field in the Network screen, select Built-in Ethernet. Click on Save.

  • Page 42: Create A User Account

    User Guide Westell Dual Connect NAT Router with DMH Technology Create a user Account In the address window of your Internet Explorer web browser, type Http://dslrouter/. Press enter on your keyboard. The Getting Started screen will be displayed. You may now begin your Account Setup. Refer to section 7 of this User Guide to configure your Router.

  • Page 43: Home

    User Guide Westell Dual Connect NAT Router with DMH Technology 9. HOME 9.1 Setting Up Advanced Configuration STOP! The following sections assume that you have active DSL and Internet service. The Advanced Configuration section of your Westell Router allows you to make changes to features like your firewall settings.

  • Page 44: Adding Account Profiles

    User Guide Connection Overview Displays your DSL connection rate. Connection Name This Connection Name is from the connection profile that you established in section 7. PPP Status UP = PPP session established DOWN = No PPP session established. Connect/Disconnect CONNECT = Establish a PPP session DISCONNECT = Disconnect a PPP session Profile Editor This allows you to make changes to the profile that you created in section 7.
  • Page 45 User Guide Connection Name Account ID Account Password Service Profile Manual On Demand Always On Time Out Enable Save Password Minutes for Connection Time Out 030-300372 Rev. A Westell Dual Connect NAT Router with DMH Technology This field allows you to enter a new connection name of your choice (up to 64 characters).

  • Page 46: Status

    User Guide 10. STATUS 10.1 Connection Summary The following settings will be displayed if you select Connection Summary from the Status menu. The actual information displayed in this screen may vary. Connection Rate This field will let you know if you have a DSL Sync (UP/DOWN) and the DSL rate at which you are connected.

  • Page 47: About

    User Guide transmitted (OUT) in packets. Dropped: Monitors information traffic that was not successfully received (IN) or transmitted (OUT) due to your firewall settings. Connection Name This is from the connection profile that you established in section 7. Connection Duration This field will display how long your PPP session has been connected.

  • Page 48: Configuration

    User Guide Westell Dual Connect NAT Router with DMH Technology 11. CONFIGURATION 11.1 VC Configuration The following settings will be displayed if you select VC Configuration from the Configuration menu. NOTE: The actual information displayed in this screen may vary, depending on the network connection established. NOTE: If you experience any problems, please reset your Router via the external hardware re-set button or via the procedure defined under the Maintenance menu.
  • Page 49 User Guide Status Protocol NOTE: The configuration specified by your Service Provider will determine which Protocols are available to you. Bridge Broadcast Bridge Multicast Spanning Tree Protocol 030-300372 Rev. A Westell Dual Connect NAT Router with DMH Technology Allows you to enable or disable your VC (Virtual Connection) Displays the VPI (Virtual Path Indicator) value for a particular VC, which is defined by your Service Provider.
  • Page 50 User Guide Westell Dual Connect NAT Router with DMH Technology The following settings will be displayed if you select edit from your VC Configuration menu on any of your existing VC (Virtual Connections) settings. If you change any of your existing VC settings, click on Set VC. NOTE: If you experience any problems, please reset your Router via the external hardware re-set button or via the procedure defined under the Maintenance menu.
  • Page 51 User Guide This setting allows you to change your VPI (Virtual Path Indicator) value for a particular VC, which is defined by your Service Provider. This setting allows you to change your VCI (Virtual Channel Indicator) value for a particular VC, which is defined by your Service Provider. Factory Default = 100% Peak Cell Rate (PCR)-The maximum rate at which cells can be transmitted across a virtual circuit, specified in cells per second and defined by the interval between the...

  • Page 52: Configuring The Router's Protocol Settings

    User Guide Westell Dual Connect NAT Router with DMH Technology Configuring the Router’s Protocol Settings If you want to change your Router’s protocol setting, select VC Configuration from the Configuration menu. Next, select edit from your VC Configuration menu on any of your existing VC (Virtual Connections) settings. The following screen will be displayed.
  • Page 53 User Guide If you selected Bridge as the protocol you want to use, the following screen will be displayed. Select a mode from the options displayed at the Mode pull-down arrow under VC – 1 Bridge Settings. This setting allows you to change your VPI (Virtual Path Indicator) value for a particular VC, which is defined by your Service Provider.
  • Page 54 User Guide Protocol The Protocol for each VC, which is specified by your Service Provider. PPPoA = Point to Point Protocol over ATM (Asynchronous Transfer Mode) PPPoE = Point to Point Protocol over Ethernet Bridge = Bridge Protocol Classical IPoA = Internet Protocol over ATM (Asynchronous Transfer Mode). This is an ATM encapsulation of the IP protocol.
  • Page 55 User Guide Westell Dual Connect NAT Router with DMH Technology If you select Routed Bridge, the following screen will be displayed. Click on set VC to save your VC settings. If you clicked on set VC, the following pop-up screen will be displayed. Click on OK when asked Set this PPPoE VC configuration? If you click on cancel, the new VC settings will not be saved.

  • Page 56: Dns Configuration

    User Guide 11.2 DNS Configuration The following settings will be displayed if you select DNS Configuration from the Configuration menu. Enable Factory Default = CHECKED Displays the status of the DNS Server. If you disable this feature, the router will not automatically resolve the host name. Domain Name This field allows you to enter a Domain Name for your Router.
  • Page 57 User Guide Westell Dual Connect NAT Router with DMH Technology If you want to add a new Host Name and IP address to your DNS server, enter your Router’s Host Name and IP Address in the fields provided in the Static Host Assignment section. The following screen displays a Host Name and an IP Address in the fields.

  • Page 58: Dhcp Configuration (Private Lan)

    User Guide Westell Dual Connect NAT Router with DMH Technology If you clicked on add, the following screen will be displayed. The Host Name and IP Address have been added to the Static Host Assignment. 11.3 DHCP Configuration (Private LAN) The following settings will be displayed if you select DHCP Configuration from the Configuration menu.

  • Page 59: Disabling The Dhcp Server

    User Guide DHCP Server This setting allows the ADSL router to automatically assign IP addresses to local devices connected on the LAN. Westell advises setting this to enabled for the private LAN. Off = DHCP Server is disabled Private LAN = DHCP addresses will be saved into the Private LAN configuration.
  • Page 60 User Guide Westell Dual Connect NAT Router with DMH Technology If you selected Off at DHCP Server:, the following screen will be displayed. Click on save to save the DHCP Server setting. If you clicked on save, in the preceding DHCP Configuration screen, the following pop-up screen will appear. Click on OK.

  • Page 61: Enabling The Dhcp Server

    User Guide Westell Dual Connect NAT Router with DMH Technology 11.3.2 Enabling the DHCP Server If you want to enable your DHCP Server settings, select Private LAN at the DHCP Server pull-down arrow. If you selected Private LAN, the following screen will be displayed. Click on save to save your DHCP Server setting.

  • Page 62: Private Lan Configuration

    User Guide Westell Dual Connect NAT Router with DMH Technology If you clicked on save, in the preceding DHCP Configuration screen, the following pop-up screen will appear. Click on OK. 11.4 Private LAN Configuration The following settings will be displayed if you select Private LAN Configuration from the Configuration menu. (Private LAN is the default configuration for this Router.) NOTE: Private LAN allows you to set up a network behind your Router.

  • Page 63: Public Lan Configuration

    User Guide Private LAN DHCP Server Enable Private LAN Enable Modem IP Address Subnet Mask DHCP Start Address DHCP End Address DHCP Lease Time NOTE: DHCP Lease Time is displayed in the following format: (dd:hh:mm:ss)* This value must be greater than 10 seconds.
  • Page 64 User Guide Public LAN DHCP Server Enable Public LAN Enable Public LAN IP Address Public LAN Subnet Mask 030-300372 Rev. A Westell Dual Connect NAT Router with DMH Technology Default = NOT CHECKED If this box is CHECKED, it enables DHCP addresses to be served from the Public LAN pool.
  • Page 65 User Guide Westell Dual Connect NAT Router with DMH Technology If you clicked on the Public LAN DHCP Server Enable box, the following screen will be displayed. Click on the Public LAN Enable box to enable Public LAN. NOTE: By enabling the Public DHCP Server, you automatically disable the Private LAN DHCP Server on your Router.
  • Page 66 User Guide If you made changes and clicked on save in the preceding screen, the following pop-up screen will be displayed. Click on OK. This will save you Public LAN Configuration settings. If you click on Cancel, your new settings will not take effect.
  • Page 67 User Guide Westell Dual Connect NAT Router with DMH Technology If you clicked on OK in the preceding screen, the following screen will be displayed. This screen shows that the Router is being reset. After the modem has completed resetting, the following screen will be displayed. Confirm that you have a DSL sync and click on the connect button to establish a PPP session.

  • Page 68: Single Static Ip Configuration

    User Guide Westell Dual Connect NAT Router with DMH Technology 11.6 Single Static IP Configuration The following settings will be displayed if you select Single Static IP Configuration from the Configuration menu. STOP: Static NAT must be disabled before you can enable Single Static IP. To disable Static NAT, select Service Configuration from the Configuration menu.
  • Page 69 User Guide Westell Dual Connect NAT Router with DMH Technology If you clicked on enable, the following pop-up screen will appear. Click on OK to enable this device for Single Static IP. Click on Cancel if you do not want to enable Single Static IP. NOTE: The actual information displayed in this screen may vary.
  • Page 70 User Guide Westell Dual Connect NAT Router with DMH Technology If you clicked on OK, the following screen will be displayed. The Router will be reset and the new configuration will take effect. After the modem has completed resetting, the following screen will be displayed. Confirm that you have a DSL sync and click on the connect button to establish a PPP session.
  • Page 71 User Guide Westell Dual Connect NAT Router with DMH Technology 11.7.2 Disabling Single Static IP To disable Single Static IP, select Single Static IP Configuration from the Configuration menu. Next, select your device (from the options displayed in the window). Click on disable. STOP! After you enable Single Static IP, you must reboot your computer.
  • Page 72 User Guide Westell Dual Connect NAT Router with DMH Technology If you clicked on OK, the following screen will be displayed. The Router will be reset and the new configuration will take effect. After the modem has completed resetting, the following screen will be displayed. Confirm that you have a DSL sync and click on the connect button to establish a PPP session.
  • Page 73 User Guide 11.7.3 Configuring Static IP on Your PC If you have static IP service (your Internet service provider (ISP) supplies static IP addresses), you will need to perform the following steps to obtain Internet access: 1. Configure your PC settings to obtain an IP address automatically. (Refer to your Windows Help screen for instructions.) 2.

  • Page 74: Service Configuration

    User Guide 11.7 Service Configuration The following settings will be displayed if you select Service Configuration from the Configuration menu. Westell has developed an extensive list of NAT services and you may select any service from this list. By selecting your specific NAT service and setting up a NAT profile, you will ensure that the appropriate ports on your Router are open and that the required application traffic can pass through your LAN.
  • Page 75 User Guide Westell Dual Connect NAT Router with DMH Technology 11.8.1 Creating a New NAT Service Profile If you select new from the preceding Service Configuration screen, the Create new Service Profile? pop-up screen will be displayed. Click on OK to begin creating your new NAT service profile. Click Cancel if you do not want to create a new NAT service profile.
  • Page 76 User Guide Westell Dual Connect NAT Router with DMH Technology If you selected “A New Service Profile #1” from the Current Profile pull-down arrow, the following screen will be displayed. This screen shows that you have chosen to create a new NAT service profile. You may create up to four NAT service profiles and attach an unlimited number of services to each profile.
  • Page 77 User Guide Westell Dual Connect NAT Router with DMH Technology Once you have created a NAT service profile, you may edit the profile. If you select edit from the Service Configuration screen, the following screen will be displayed. By selecting the edit button, you can make changes to your NAT profile by adding or deleting NAT applications that will work with your Router.
  • Page 78 User Guide Westell Dual Connect NAT Router with DMH Technology If you clicked on save in the Edit NAT Profile screen, the following pop-up screen will be displayed. Click OK to save your new profile settings. If you click on Cancel, your new profile settings will not be saved. 030-300372 Rev.
  • Page 79 User Guide Westell Dual Connect NAT Router with DMH Technology 11.8.3 Adding NAT Services to a Profile This section explains how to add NAT services to your NAT service profile. Remember, you may attach an unlimited number of NAT services to your profile. To add a NAT service to your NAT service profile, select a service from the options provided at the Service Name pull-down arrow.
  • Page 80 User Guide Westell Dual Connect NAT Router with DMH Technology If you clicked on enable, the following Host Service screen will be displayed. Click on OK. This will load the new NAT Configuration and the settings will be saved automatically. If you clicked on OK in the preceding pop-up screen, the Host Device screen will be displayed.
  • Page 81 User Guide Westell Dual Connect NAT Router with DMH Technology Once you have selected a NAT service and you have saved it to your NAT service profile, the following screen will be displayed. It shows which NAT service is active for the selected profile. If you select details, the screen below will display the details of the selected NAT service.

  • Page 82: Firewall Configuration

    User Guide 11.8 Firewall Configuration The following settings will be displayed if you select Firewall Configuration from the Configuration menu. High High security level only allows basic Internet functionality. Only Mail, News, Web, FTP, and IPSEC are allowed. All other traffic is prohibited. Medium Factory Default = MEDIUM Like High security, Medium security only allows basic Internet functionality by default.
  • Page 83 User Guide If you select Edit in the preceding Firewall Configuration screen, the User Defined Firewall Rules screen will be displayed. This screen allows you to change the security parameters on your Inbound and Outbound Firewall rules via the User Defined Firewall Rules pull-down arrow. To apply the new settings, click on Apply in the screen labeled User Defined Firewall Rules.
  • Page 84 User Guide Westell Dual Connect NAT Router with DMH Technology If you want to save your new firewall settings, click on save in the screen labeled User Define Firewall Rules. NOTE: Westell recommends that you do not change the settings in the User Defined Firewall Rules screen. If you need to reset the Router to factory default settings, push the reset button on the rear of the Router.

  • Page 85: Atm Loopbacks

    User Guide If you select Help in the screen labeled User Defined Firewall Rules, the following screen will be displayed. This screen gives a detailed explanation of the Firewall Rules. 11.9 ATM Loopbacks If you select ATM Loopbacks from the Configuration menu, the following settings will be displayed. Enable ATM 0/21 Loopback: Factory Default = ENABLED This option enables the 0/21 loopback , which is used by your ISP.

  • Page 86: Setting Up Advanced Service Configuration

    User Guide 12. SETTING UP ADVANCED SERVICE CONFIGURATION You can set up additional Service Configuration options for your NAT Router that allow you to enter the port forwarding and trigger ports ranges of your choice. Go to Configuration at the homepage menu and select Service Configuration.

  • Page 87: Port Forwarding Ranges Of Ports

    User Guide Westell Dual Connect NAT Router with DMH Technology 12.1 Port Forwarding Ranges of Ports To select Port Forwarding Ranges of Ports, click on define custom service from the Service Configuration screen, and then select Port Forwarding Ranges of Ports from the Custom Service screen. Click on Next. The follow settings will be displayed in the Port Range screen.

  • Page 88: Port Forwarding Trigger Ports

    User Guide Service Name The NAT service for which you are configuring Port Forwarding. Type The type of NAT service configuration you selected. Protocol The type of Protocol that is used to run this NAT service. TCP- Transmission Control Protocol. UDP-User Datagram Protocol (UDP).

  • Page 89: Adding Local Trigger Ports

    User Guide Westell Dual Connect NAT Router with DMH Technology 12.4 Adding Local Trigger Ports If you made changes in the Local ‘Trigger’ Port Range screen and clicked next, the following screen will be displayed. You may either click on close to accept the changes, or click on add to go back to the Trigger Ports screen, enter additional port range values, and click on next.

  • Page 90: Static Nat

    User Guide Westell Dual Connect NAT Router with DMH Technology 12.5 Static NAT To configure you Router for Static NAT, click on the static NAT button in the Service Configuration screen. NOTE: Static NAT will allow you to configure your Router to work with the special NAT services. 12.6 Enabling Static NAT If you clicked on static NAT in the Service Configuration screen, the following screen will be displayed.

  • Page 91: Disabling Static Nat

    User Guide Westell Dual Connect NAT Router with DMH Technology This following screen shows Static NAT enabled. 12.7 Disabling Static NAT If you click on static NAT in the Service Configuration screen, the following screen will be displayed, select a device name from the Static NAT Device pull-down arrow and click on disable.
  • Page 92 User Guide Westell Dual Connect NAT Router with DMH Technology The following screen shows Static NAT disabled (No device is displayed in the field adjacent to the static Nat button.) 030-300372 Rev. A July 2003...

  • Page 93: Maintenance

    User Guide 13. MAINTENANCE 13.1 Backup/Store The following settings will be displayed if you select Backup/Restore from the Maintenance menu. Current configuration Select this button if you want to store all of the current configuration data becomes Backup such that it can be recalled later. Configuration Backed up configuration Select this button if you want to retrieve the last back up copy of all...

  • Page 94: Firewall Log

    User Guide 13.2 Firewall Log The following settings will be displayed if you select Firewall Log from the Maintenance menu. This screen is an advanced diagnostics screen. It alerts you of noteworthy information sent to your Router from the Internet. The screen can contain 1000 entries, but a maximum of 50 entries are displayed at a time. Once 1000 entries have been logged, the oldest entry is removed to make space for the new entries as they occur.

  • Page 95: Change Password

    User Guide 13.3 Change Password The following settings will be displayed if you select Change Password from the Maintenance menu. After you enter your data into the appropriate settings, click on change. Enter Administrative Name NOTE: This changes the Systems Administrator password not the PPP password.

  • Page 96: Remote Access

    User Guide 13.4 Remote Access The following screen will appear if you select Remote Access from the Maintenance menu. To enable Remote Access, type in a password and click the enable remote access button. NOTE: The password should be at least 4 characters long and should not exceed 32 characters. Do not type a blank space or asterisks in the Password field.

  • Page 97: Update Device

    User Guide Westell Dual Connect NAT Router with DMH Technology 13.5 Update Device The following screen will be displayed if you click on Update Device from the Maintenance menu. This screen is used to update the firmware that controls the operation of the DSL Router. The updated firmware may be loaded from either a file that is located on your PCs hard drive or from update files stored on an Internet server.
  • Page 98 User Guide Westell Dual Connect NAT Router with DMH Technology Click on the local update now button in the Update Device screen to select the upgrade file from your PC’s hard drive. This screen allows you to upgrade the software on your Router. Click Browse… and go to the location where the upgrade file is stored.
  • Page 99 User Guide Westell Dual Connect NAT Router with DMH Technology Select the appropriate upgrade file from your browser. The file name will appear in the field labeled Upgrade File. Click on upload file. This screen shows that the file is being uploaded to your Router. 030-300372 Rev.
  • Page 100 User Guide Westell Dual Connect NAT Router with DMH Technology The screens below show that the file upload has completed and that the Programming Flash is being erased to prepare the Flash storage area for upload of the new file. (Programming Flash is a temporary storage area for uploaded files.) The screen below shows that the upload was successful.
  • Page 101 User Guide Westell Dual Connect NAT Router with DMH Technology The screen below shows that the Router is being reset. 030-300372 Rev. A July 2003...

  • Page 102: Troubleshooting

    User Guide Westell Dual Connect NAT Router with DMH Technology 14. TROUBLESHOOTING 14.1 System Self Tests The following settings will be displayed if you select System Self Tests from the Troubleshooting menu. Click on test all to run a diagnostic test on your Router’s connection. This screen had been displayed in two parts for illustrative purposes.
  • Page 103 User Guide The Router checks the status of the Router connection. Possible responses are: UP: The Router is operating correctly and has obtained synchronization with the opposing network device. DOWN: The Router is operating correctly, but has not synchronized with the opposing device.

  • Page 104: Diagnostic Logs

    User Guide the Service Provider’s network. You can PING a remote computer via the IP address or the DNS address. If your PING fails, try a different IP or DNS address. Possible responses are: Success: The Remote Host computer was detected. No Response: There was no response to the Ping from the remote computer.
  • Page 105 User Guide Westell Dual Connect NAT Router with DMH Technology To see a list of the log options, click on the arrow at the LOGS pull-down menu. Select an option from the list provided at the Diagnostics Logs screen. If you clicked on All, the following screen will be displayed. This screen provides a detailed list of the Router’s connection status and system information.

  • Page 106: Wan Vc Statistics

    User Guide 14.3 WAN VC Statistics The following settings will be displayed if you select WAN VC Stats from the Troubleshooting menu. VPI/VCI Displays the VPI/VCI values obtained from your Internet Service Provider. In Errors The number of error packets received on the ATM port. In Discard Packets The number of discarded packets received.

  • Page 107: Ethernet Statistics

    User Guide 14.4 Ethernet Statistics The following settings will be displayed if you select Ethernet Stats from the Troubleshooting menu. In Errors The number of error packets received on the Ethernet interface. In Discard Packets The number of discarded packets received. In Non Unicast Packets The number of non-Unicast packets received on the Ethernet interface.

  • Page 108: Transceiver Statistics

    User Guide 14.5 Transceiver Statistics The following settings will be displayed if you select Transceiver Stats from the Troubleshooting menu. Transceiver Revision The transceiver software version number. Vendor ID Code The CPE Vendor’s ID code for their chipset. Line Mode The operational mode.

  • Page 109: Usb Port Statistics

    User Guide 14.6 USB Port Statistics The following settings will be displayed if you select USB Port Stats from the Troubleshooting menu. Number of Resets The number of times the Host PC reset the USB interface. Number of Isrs The number of times the Host PC requested communication with the Router. In Unicast Packets The number of packets received that did not have a Multicast or Broadcast class destination IP address.

  • Page 110: Lan Statistics

    User Guide 14.7 LAN Statistics The following settings will be displayed if you select LAN Stats from the Troubleshooting menu. Device IP Address Displays the IP address of the devices on the LAN. DHCP NetMask Displays the Subnet Mask, which determines what portion of an IP address that is controlled by the network and what portion is controlled by the host.

  • Page 111: Atm Loopback

    User Guide 15. HELP If you select Help from the menu bar, a message from the help screens will be displayed. The type of message displayed depends on the menu that you are viewing. If you are viewing a pop-up screen, click the help link in the pop-up screen to obtain help messages.

  • Page 112: Change Administration Password

    User Guide Backup/Restore This option allows the Router configuration to be backed up to or restored from a secure location in flash. The following options are displayed. Current becomes Back-up Selecting this command button will backup the current active configuration to the secure flash location.

  • Page 113: Diagnostics Help

    User Guide Diagnostics Help This screen provides tools for diagnosing PPP connection problems. Some tests depend on the Router status and the capabilities exercised by previous tests, which may prevent other types of testing. Beginning of Diagnostics Help screens The Router status checks the Router connection. The following is a list of the possible responses: The Router is operating correctly and has obtained synchronization with the opposing modem.
  • Page 114 User Guide This field displays the PPP Connection status. A PPPoE or PPPoA session must already be established. The following is a list of the possible responses: Connection up The Router has established a PPP connection. no connection There is no PPP connection. A PPP session must be connected from the homepage screen.
  • Page 115 User Guide The DNS test issues a request to try to resolve the name of a particular host. The host name is entered in the input box. The following is a list of the possible responses: Success The Router has successfully obtained the resolved address. The IP address is shown below the host name input box No Response Explanation: The Router has failed to successfully obtain the resolved address.

  • Page 116: Dhcp Configuration

    User Guide DHCP Configuration This screen contains the settings which control how the ADSL router interacts with the local devices connected to the router. Westell does not recommend that you change these settings. The following settings are displayed. DHCP Server DHCP Start Address (If DHCP is enabled) DHCP End Address (If DHCP is...

  • Page 117: Firewall Settings

    User Guide Edit Connection Profiles This screen facilitates the changing of connection profile parameters. The following settings are displayed. Connection Name This field is a description of the default connection profile that the Router will use. Feel free to use whatever description you desire. Account ID Your account ID is supplied by your ISP.

  • Page 118: Lan Configuration

    User Guide security, Medium security, allows customization through NAT configuration, so you can enable the traffic that you want to pass. The low security setting will allow all traffic except for known attacks. With low security, your Router is visible by other computers on the Internet. Custom Custom is a very advanced configuration option that allows you to edit the firewall configuration directly.

  • Page 119: Private Lan

    User Guide LAN Statistics This page contains information regarding the configuration and status of your Local LAN. The following settings are displayed. Device IP Address This displays the IP address that the ADSL router uses for local communication. DHCP NetMask This displays the subnet address that the ADSL router’s DHCP server issues in DHCP responses.
  • Page 120 User Guide Protocol Protocol This screen informs the Router which networking protocol to use when communicating with your ISP. This information is provided by your ISP. Public LAN This screen contains the settings that control how the ADSL router interacts with the local devices connected to the router.

  • Page 121: Single Static Ip

    User Guide Single Static IP This page contains the settings that would allow the PPP address received from the network to be propagated to a single LAN device behind the modem. WAN IP Address This is the PPP IP address the ISP has assigned the modem. Selection box This box contains the devices available to share the Single Static IP address the ISP has assigned the modem.

  • Page 122: User Name

    User Guide Update Device Update Device This screen is used to upgrade the Router’s application image. The application (Software Upgrade) image is specified by entering in the filename or by using the browse button. User Name This screen is asks for information that will allow the Router to make a connection to the ISP on your behalf. The Router will need to know your Account ID and Account Password.

  • Page 123: Nat Services

    User Guide 16. NAT SERVICES Table 7. Applications/Games/VPN Support Application/Game Aliens vs. Predator America Online AoE II: Conquors AOL Instant Messenger Asheron's Call Battlecom Black and White Blizzard Battle.net (Diablo II) Buddy Phone Bungie.net, Myth, Myth II Server Calista IP Phone Citrix Metaframe Client POP/IMAP Client SMTP...
  • Page 124 User Guide Application/Game Ghost Recon GNUtella Half Life Server Heretic II Server Hexen II Hotline Server HTTPS ICMP Echo ICQ OLD ICQ 2001b ICUII Client ICUII Client Version 4.xx IMAP IMAP v.3 Internet Phone IPSEC ESP IPSEC IKE Ivisit KALI, Doom & Doom II KaZaA Limewire Medal Of Honor: Allied Assault...
  • Page 125 User Guide Application/Game Napster Need for Speed 3, Hot Pursuit Need for Speed, Porsche Net2Phone NNTP Operation FlashPoint Outlaws Pal Talk pcAnywhere host Phone Free Quake 2 Quake 3 Quicktime 4/Real Audio Rainbow Six & Rogue Spear RealOne Player Real Audio Roger Wilco ShoutCast Server SSH Secure Shell...
  • Page 126 User Guide Application/Game USENET News Service VNC, Virtual Network Computing Westwood Online, C&C World Wide Web (HTTP) XBOX Live Yahoo Messenger Chat Yahoo Messenger Phone VPN Protocol IPSec Encryption L2TP PPTP 030-300372 Rev. A Westell Dual Connect NAT Router with DMH Technology Port/Protocol [UWeb.WebServer] section of the server.ini file, set the ListenPort to 8080 and ServerName to the IP assigned to...

  • Page 127: Technical Support Information

    User Guide 17. TECHNICAL SUPPORT INFORMATION Westell Technical Support If technical assistance is required, contact Westell by using one of the following options: North America Phone: 1-630-375-4500 U.K./Europe Phone: (44) 01256 843311 18. WARRANTY INFORMATION Warranty Westell warrants this product free from defects at the time of shipment. Westell also warrants this product fully functional for the period specified by the terms of the warranty.

  • Page 128: Product Specifications

    User Guide 19. PRODUCT SPECIFICATIONS ADSL • DSL Line Code: Discrete Multi-Tone (DMT) • DSL Rates: 32 kbps to 8 Mbps downstream and 32 kbps to 800 Kbps upstream • Power spectral density: -40 dBm/Hz • DSL Impedance: 100 Ohms •...

  • Page 129: Software License Agreement

    AGREEMENT. IF YOU ARE NOT WILLING TO BE BOUND BY THE TERMS OF THIS LICENSE AGREEMENT, YOU SHOULD PROMPTLY RETURN THE SOFTWARE AND HARDWARE TO WESTELL TECHNOLOGIES, INC. THIS LICENSE AGREEMENT REPRESENTS THE ENTIRE AGREEMENT CONCERNING THE SOFTWARE BETWEEN YOU AND WESTELL TECHNOLOGIES, INC.

  • Page 130: Publication Information

    21. PUBLICATION INFORMATION Westell Dual Connect NAT Router (Model 2200) ® User Guide Part Number 030-300372 Rev. A July 2003 ©...

Table of Contents
