Setup Instructions

Spiderlite TD5 Window Light Kit Plus
Style Series: 4898

Description

This kit provides both a main and fill/accent light providing over 1800 watts of power. Create the natural look of
window light using two 24" x 32" Soft Boxes mounted onto two Spiderlite TD5s. Powerful 50-watt fluorescent
lamps not only stay cool to the touch, but provide over 8,000 hours of use. The heavy-duty stands and location
carry case complete the kit. Instructional DVD included featuring Master Photographer James Schmelzer.

Product Contains

[2] Spiderlite TD5s
[2] Tilter Brackets
[2] 24" x 32" Silver Soft Boxes
[8] 50-watt fluorescent Lamps
[2] 20-watt fluorescent Lamp
[2] 10' Heavy-Duty Light Stand
[1] Location Travel Case
[1] Instructional DVD - Volume 2

INSTRUCTIONS

Set up the included light stand(s) and adjust to your required height using the turn knobs located on the
stem of the stand. Secure each knob to lock into place.
Attach the included tilter bracket(s) onto the top of the light stand insuring the umbrella receptacle is
located towards the top. Tighten knob to lock into place.
Next, insert the support rods into the rod sleeves in the corner of the fabric shell of the included soft box(es) all
the way into the end of the pockets. Before putting on the exterior diffusion panel, place the soft box onto a table
or the floor and spread rods apart so the soft box is rectangular in shape. Insert one rod into the hole located on
the Spiderlite TD5 head next to the slotted hole. Insert the next rod into the hole directly across from the first hole.
Repeat the steps using the two open holes. The slotted hole should be the last rod you insert.
Questions? Please call 800.886.1689 or email . ©F.J. Westcott Company
