Lighting
Page 1 of 2
Setup Instructions
Spiderlite TD5 2 Light Ultimate Daylight Kit
Style Series: 4896
Description
. This two light Ultimate Daylight Kit provides a large soft box as your main light and a compact and narrow 12"
x 36" Strip Bank as a hair light or accent light. Included for the strip bank, is a 40-degree egg-crate grid. This grid
will alter the shape and intensity of the light output from your soft box resulting in a narrow and directional
spread of light. Ideal for keeping light spill off of the background or unwanted areas. 50-watt included
fluorescents provide over 1800 watts of total output utilizing soft and natural daylight color temperature.
Product Contains
[2] Spiderlite TD5s
[2] Tilter Brackets
[1] 36" x 48" Silver Soft Box
[1] 12" x 36" Strip Bank
[1] 40-degree grid for Strip Bank
[1] 6' Boom Arm
[8] 50-watt fluorescent Lamps
[2] 20-watt fluorescent Lamps
[2] 10' Heavy-Duty Light Stand
[1] Deluxe Wheeled Case
[1] Instructional DVD - Volume 2
INSTRUCTIONS
Set up the included light stand(s) and adjust to your required height using the turn knobs located on the
stem of the stand. Secure each knob to lock into place.
Attach the boom arm to one light stand. The boom arm will need adjusted once the light is attached for
proper counterweight distribution.
Attach the included tilter bracket(s) onto the top of the light stand or boom insuring the umbrella
receptacle is located towards the top. Tighten knob to lock into place.
Questions? Please call 800.886.1689 or email
.
©F.J. Westcott Company
info@fjwestcott.com
Advertisement
Table of Contents
Related Manuals for Westcott 4896
Summary of Contents for Westcott 4896
-
Page 1: Setup Instructions
Page 1 of 2 Setup Instructions Spiderlite TD5 2 Light Ultimate Daylight Kit Style Series: 4896 Description . This two light Ultimate Daylight Kit provides a large soft box as your main light and a compact and narrow 12" x 36" Strip Bank as a hair light or accent light. Included for the strip bank, is a 40-degree egg-crate grid. This grid will alter the shape and intensity of the light output from your soft box resulting in a narrow and directional spread of light. - Page 2 Insuring the unit is not plugged in, place your (5) lamps into the (5) sockets located on the Spiderlite TD5. If you are using the (5) pack of Westcott’s new 50-watt Daylight Balanced Fluorescent lamps, the smaller 20-watt lamp included goes into the center socket. This lamp must be inserted first. The (4) remaining 50-watt lamps will go into the (4) outer sockets.
