Setup Instructions
Spiderlite TD5 Large Daylight Kit Plus
Style Series: 4893

Description

This kit serves as an ideal main or fill light providing over 900 watts of power utilizing Westcott's new and
powerful 50-watt fluorescent lamps. These lamps give you the natural look of window light or daylight 24 hours a
day. When shooting in a tight space, these lamps generate little heat and are rated for over 8,000 hours of use.
This kit comes standard with a 36" x 48" Soft Box , fluorescent lamps, 10' heavy-duty light stand and carry case
and provide solutions for varying applications. Instructional DVD included featuring Master Photographer James
Schmelzer.

Product Contains

[1] Spiderlite TD5
[1] Tilter Bracket
[1] 36" x 48" Silver Soft Box
[4] 50-watt fluorescent Lamps
[1] 20-watt fluorescent Lamp
[1] 10' Heavy-Duty Light Stand
[1]Location Travel Case
[1] Instructional DVD - Volume 2

INSTRUCTIONS

Set up the included light stand(s) and adjust to your required height using the turn knobs located on the
stem of the stand. Secure each knob to lock into place.
Attach the included tilter bracket(s) onto the top of the light stand insuring the umbrella receptacle is
located towards the top. Tighten knob to lock into place.
Next, insert the support rods into the rod sleeves in the corner of the fabric shell of the included soft box(es) all
the way into the end of the pockets. Before putting on the exterior diffusion panel, place the soft box onto a table
or the floor and spread rods apart so the soft box is rectangular in shape. Insert one rod into the hole located on
the Spiderlite TD5 head next to the slotted hole. Insert the next rod into the hole directly across from the first hole.
Repeat the steps using the two open holes. The slotted hole should be the last rod you insert.
Questions? Please call 800.886.1689 or email . ©F.J. Westcott Company
