- Page 1 OWNER'S MANUAL SFH 0521DIS SFH 0521TDIS AGRICULTURAL UNIT HEATER SFHGX 0521TDIS THANK YOU FOR YOUR PURCHASE! NEED ASSISTANCE? CONTACT STELPRO CUSTOMER SERVICE. WWW.STELPRO.COM CONTACT@STELPRO.COM 1-844-STELPRO...
-
Page 2: Important Instructions
9. A heater has hot and arcing or sparking parts inside. Do not determine the optimal power required or consult the Stelpro use it in areas where gasoline, paint or flammable vapors or website. - Page 3 INSTALLING THE UNIT HEATER TAKE A FEW MINUTES TO READ THE FAN HEATER’S INSTALLATION GUIDE TO ENSURE AN EASY AND SAFE INSTALLATION. WHAT’S IN THE BOX TOOLS AND MATERIAL REQUIRED Stud finder Phillips No. 2 screwdriver Measuring tape Flat screwdriver 1/4 x 6 in. (15 cm) maximum Support Wire stripper...
-
Page 4: Unit Heater Location
UNIT HEATER LOCATION You must install your heater in an open area at least 6 ft CAUTION: To avoid any risk of overheating and fire, (1.83 m) from the floor and at a maximum height of 10 ft (3 m). leave a minimum of 24 in. (60 cm) of free space under Make sure that objects or furniture near the heater can the unit and 6 in. -
Page 5: Attaching The Bracket
ATTACHING THE BRACKET 1. Using a stud detector, locate studs and other structures 3. Attach the bracket [A] securely using two ½ x 1 ½" lag in the ceiling or wall. bolts (not supplied) or equivalent hardware that can support the weight of the unit and its 35 lb (16 kg) bracket. 2. - Page 6 CONNECTING THE ELECTRICAL WIRES 1. With a flat or Philips screwdriver, unscrew the two 2. Using a flat screwdriver, remove the protective screws [A] to open the junction box cover. cap [B] to unblock the opening that will be used to insert the power cables. 3.
- Page 7 5. Connect the power supply and thermostat wires 7. Close the cover and tighten the screws securely. according to the diagram that applies to your situation. Leave the central terminal on the circuit Note: You’ll need a 1/4" x 6" flat screwdriver to breaker [E] free.
- Page 8 RESTORING POWER Restore power to the unit heater. Make sure it works by increasing the thermostat temperature set point until the unit starts to heat. UNIT CONTROL AND OPERATION BUILT-IN THERMOSTAT (SFH0521TDIS AND SFHGX0521TDIS) INDICATOR LIGHT Allows you to turn off Indicates a heating and adjust the heating malfunction.
- Page 9 MAINTAINING THE FAN HEATER THE UNIT HEATER’S AIR INLET AND OUTLET MUST BE CLEANED REGULARLY FOR THE WARRANTY TO BE VALID. During maintenance, never use the following: WARNING: Turn off the power to the unit heater • Metal brush or scouring pad directly from the electrical panel before cleaning.
- Page 10 ON as well as the unit’s main switch. • If the problem persists, the thermostat may be defective. Please contact STELPRO Customer Service. • Make sure the fan heater’s wires are connected correctly. Refer to Connecting the electrical wires section on page 7.
- Page 11 RESTORING THE THERMAL PROTECTION (SFHGX0521TDIS ONLY) In the event of overheating or a power failure, the thermal protection may be triggered. 1. Set the main switch to OFF to turn off the power to 3. Press the button [B] at the centre of the thermal the unit before proceeding.
-
Page 12: Claim Procedure
3 years. or the refund of its purchase price, at the discretion of STELPRO. This warranty applies only to the original purchaser; it is non- Any parts replaced or repaired within the warranty period with transferable and cannot be extended.
