- Page 1 Setting the Oil Level Magnochem Supplementary Operating Manual...
- Page 2 All rights reserved. The contents provided herein must neither be distributed, copied, reproduced, edited or processed for any other purpose, nor otherwise transmitted, published or made available to a third party without the manufacturer's express written consent. Subject to technical modification without prior notice. © KSB SE & Co. KGaA, Frankenthal 12/02/2018...
- Page 3 Contents Contents General.............................. 4 Adjusting the eccentric ............................ 4 Setting the Oil Level 3 of 8...
- Page 4 1 General 1 General This supplementary operating manual accompanies the installation/operating manual. All information contained in the installation/operating manual must be observed. Table 1: Relevant operating manuals Type series Reference number of the installation/operating manual Magnochem 2747.8 Manufacturer's product For accessories and/or integrated machinery components observe the relevant literature manufacturer's product literature.
- Page 5 1 General Constant level oiler 62-1.49 Eccentric Fig. 2: Eccentric Stud end Disc Socket end (cylindrical reference surface for setting the oil level) Table 2: Adjusting dimensions Bearing Magnetic coupling Adjusting dimension "A" [mm] Adjusting dimension "B" [mm] bracket CS40 085 / 123 18 +/- 0,5 C - 37+/-0,5 CS50...
