8
polarity
phase difference
between both channels
Switching possibilities
externally chopped
voltage required
repetition frequency
rise time
input capacitance
Trigger mode
trace height required in positions
DC, LF and HF
in position AUT.
in positions
TV LINE and TV FRAME
Mechanical data
reversible
not measurable on the screen
1. channel A
2. channel B
3. channels A and B chopped; frequency 500 kc/s or 20 kc/s (internal
selection facility)
4. channels A and B alternately
5. channels A and B added
6. channels A and B externally chopped
symmetrical square-wave voltage:
minimum, 1 VP _p,
maximum, 20 Vp _p
100 kc/s
1-100 ns
70 pF
A, B or A -~ B (in position "ADDED" only)
3 mm for frequencies up to 10 Mc/s
2 cm for frequencies up to 20 Mc/s
1 cm for frequencies up to 1 Mc/s
2 cm
dimension width 15 cm
height 17.5 cm
length 29 cm (knobs and plug included)
weight
3 kg
Accessories
1 Manual
Optional: 2 Measuring probes PM9331A/10
