Model No. 831.29522.0
TREADMILL EXERCISER
Serial No.
User's Manual
Serial Number Decal
• Assembly
• Operation
• Maintenance
• Part List and Drawing
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manu-
Sears, Roebuck and Co., Hoffman Estates, IL 60179
al for future reference.
Advertisement
Table of Contents
Related Manuals for Weslo 78e 831.29522.0
Summary of Contents for Weslo 78e 831.29522.0
- Page 1 Model No. 831.29522.0 TREADMILL EXERCISER Serial No. User’s Manual Serial Number Decal • Assembly • Operation • Maintenance • Part List and Drawing CAUTION Read all precautions and instruc- tions in this manual before using this equipment. Save this manu- Sears, Roebuck and Co., Hoffman Estates, IL 60179 al for future reference.
-
Page 2: Table Of Contents
TABLE OF CONTENTS IMPORTANT PRECAUTIONS ..............3 BEFORE YOU BEGIN . -
Page 3: Important Precautions
IMPORTANT PRECAUTIONS WARNING: To reduce the risk of burns, fire, electric shock, or injury to persons, read the following important precautions and information before operating the treadmill. 1. It is the responsibility of the owner to ensure that all users of this treadmill are adequately informed of all warnings and precautions. - Page 4 22. Never drop or insert any object into any opening. DANGER: Always unplug the power cord immediately after use, before cleaning the treadmill, and before performing the maintenance and adjustment procedures described in this manual. Never remove the motor hood unless instructed to do so by an WARNING: Before beginning this or any exercise program, consult your physician.
-
Page 5: Before You Begin
BEFORE YOU BEGIN Thank you for selecting the WESLO treadmill. The CADENCE 78e treadmill combines advanced technology with innovative design to let you enjoy an excellent form of cardiovascular exercise in the convenience and privacy of your home. And when you’re not exercising, the unique CADENCE 78e... -
Page 6: Assembly
ASSEMBLY Assembly requires two persons. Set the treadmill in a cleared area and remove all packing materials. Do not dispose of the packing materials until assembly is completed. Note: The underside of the treadmill walking belt is coated with high-performance lubricant. During shipping, a small amount of lubricant may be transferred to the top of the walking belt or the shipping carton. - Page 7 3. If there is a plastic tie in the right Upright (46), remove the plastic tie. Hold one of the Handrails (59) near the right Upright (46) as shown. Insert the Wire Harness (60) up through the hole in the bottom of the Handrail and out of the round hole in the side of the Handrail.
- Page 8 6. Set the Console (65) in the Console Base (52). Make sure that no wires are pinched. Insert as much of the Wire Harness (60) as possible down into the hole in the right Handrail (59). Securely tighten the plastic tie nearest to the right Handrail.
-
Page 9: Operation And Adjustment
OPERATION AND ADJUSTMENT THE PRE-LUBRICATED WALKING BELT Your treadmill features a walking belt coated with high- performance lubricant. IMPORTANT: Never apply sil- icone spray or other substances to the walking belt or the walking platform. Such substances will deteriorate the walking belt and cause excessive wear. - Page 10 STEP-BY-STEP CONSOLE OPERATION Before operating the console, make sure that the power cord is properly plugged in (see page 9). Next, step onto the foot rails of the treadmill. Find the clip attached to the key, and slide the clip onto the waistband of your clothes.
-
Page 11: How To Fold And Move The Treadmill
HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL FOR STORAGE Before folding the treadmill, unplug the power cord. CAUTION: You must be able to safely lift 45 pounds (20 kg) in order to raise, lower or move the treadmill. 1. -
Page 12: Maintenance And Troubleshooting
MAINTENANCE AND TROUBLESHOOTING Most treadmill problems can be solved by following the simple steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, call toll-free 1-800-4-MY-HOME (1-800-469-4663). PROBLEM: The power does not turn on SOLUTION: a. - Page 13 PROBLEM: The walking belt slows when walked on SOLUTION: a. Use only a single-outlet surge suppressor that meets all of the specifications described on page 8. b. If the walking belt is overtightened, treadmill perfor- mance may decrease and the walking belt may become damaged.
-
Page 14: Conditioning Guidelines
CONDITIONING GUIDELINES WARNING: Before beginning this or any exercise program, consult your physician. This is especially important for individuals over the age of 35 or individuals with pre-existing health problems. The following guidelines will help you to plan your exercise program. For more detailed exercise informa- tion, obtain a reputable book or consult your physician. -
Page 15: Exercise Frequency
A Cool-down Finish each workout with 5 to 10 minutes of stretching to cool down. This will increase the flexibility of your muscles and will help to prevent post-exercise problems. SUGGESTED STRETCHES The correct form for several basic stretches is shown at the right. Move slowly as you stretch—never bounce. 1. - Page 16 PART LIST—Model No. 831.29522.0 Key No. Qty. Description Motor Hood 3/4” Screw 3/4” Tek Screw 8” Cable Tie Cable Tie Clamp Screw Cable Tie Clamp Left Foot Rail Front Isolator Front Platform Screw Wire Cover Incline Leg Washer Catch Belt Guide Belt Guide Screw Reed Switch Clip Spacer Screw...
-
Page 17: Part Identification Chart
PART IDENTIFICATION CHART Remove this chart and use it to identify small parts during assembly. Save this chart and the EXPLODED DRAWING/PART LIST for future reference. 3/4” Screw (2)–12 3/4” Tek Screw (3)–2 Base Leg Screw (62)–4 Handrail Bolt (55)–2... -
Page 19: Full 90 Day Warranty
FULL 90 DAY WARRANTY For 90 days from the date of purchase, if failure occurs due to defect in material or workmanship in this Sears Treadmill Exerciser, contact the nearest Sears Service Center throughout the United States and Sears will repair or replace the Treadmill Exerciser, free of charge. This warranty does not apply when the Treadmill Exerciser is used commercially or for rental purposes.
