Patent Pending
Model No. WLHS42081
Serial No.
Write the serial number in the space
above for reference. The serial
number decal is on the frame behind
the access cover.
QUESTIONS?
PLEASE CALL DIRECT TO OUR
TOLL-FREE CUSTOMER HOT
LINE. The trained technicians
on our customer hot line will
provide immediate assistance,
free of charge to you.
CUSTOMER HOT LINE:
1-800-999-3756
Mon.ÐFri., 6 a.m.Ð6 p.m. MST
CAUTION
Read all precautions and instruc-
tions in this manual before
using this equipment. Save this
manual for future reference.
USERÕS MANUAL
A pH testing kit (not included) is required
for proper use and maintenance of this
product. A pH testing kit can be pur-
chased at any spa or pool supply store.
Advertisement
Table of Contents
Related Manuals for Daybreak Fitness Daybreak 515 WLHS42081
Summary of Contents for Daybreak Fitness Daybreak 515 WLHS42081
- Page 1 Patent Pending Model No. WLHS42081 Serial No. Write the serial number in the space above for reference. The serial number decal is on the frame behind the access cover. QUESTIONS? PLEASE CALL DIRECT TO OUR TOLL-FREE CUSTOMER HOT LINE. The trained technicians on our customer hot line will provide immediate assistance, free of charge to you.
-
Page 2: Table Of Contents
TABLE OF CONTENTS IMPORTANT SAFETY INSTRUCTIONS ............3 BEFORE YOU BEGIN . -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS WARNING: TO REDUCE THE RISK OF DROWNING, ELECTRIC SHOCK, OR SERIOUS INJURY, READ THE FOLLOWING IMPORTANT PRECAUTIONS BEFORE USING THE DAYBREAK 515. READ AND FOLLOW ALL INSTRUCTIONS 1. It is the responsibility of the owner to ensure that all users of the hydrotherapy spa are adequately informed of all precautions. - Page 4 20. Do not use an extension cord with the hydrotherapy spa. This could damage the motor and will void the warranty. 21. DANGERÑIf you will be using the hydrother- apy spa outside, do not bury the power cord; you should also keep the power cord away from lawn mowers, hedge trimmers and other similar equipment.
-
Page 5: Save These Instructions
34. WARNINGÑTo reduce the risk of injury or drowning: Consult your physician about pos- sible side-effects of any medications you may be taking before using the hydrotherapy spa. Heat from the water, in conjunction with some medications may cause drowsiness and increase the risk of drowning. -
Page 6: Before You Begin
Interrupter (GFCI) Wood Panels For your safety and benefit, read this manual care- fully before using the DAYBREAK 515 by WESLO If you have additional questions, please call our Customer Service Department toll-free at 1-800-999- 3756, Monday through Friday, 6 a.m. until 6 p.m. -
Page 7: Choosing A Location For The Hydrotherapy Spa
CHOOSING A LOCATION FOR THE HYDROTHERAPY SPA There are many factors to consider when choosing a location to set up the hydrotherapy spa. These factors vary depending on whether you use the hydrotherapy spa inside or outside. We have listed several factors you may wish to consider as you decide where you want to use the hydrotherapy spa. -
Page 8: Set-Up And Assembly
SET-UP AND ASSEMBLY Before beginning assembly, carefully read the following information and instructions: ¥ Place all parts in a cleared area and remove the packing materials from the spa shell; do not dis- pose of the packing materials until assembly is completed and the spa is in operation. - Page 9 3. Wipe out the spa shell using a damp cloth. Remove the two warning decals (not shown) from the spa shell. Before you fill the spa, be sure that it is in the position you want, and that it can be easily ser- viced, if needed.
-
Page 10: Using The Hydrotherapy Spa
USING THE HYDROTHERAPY SPA The hydrotherapy spa is designed to seat two adults. The ten thera-jets can be regulated to provide a relax- ing massage to sooth away stress, and the strength of the water massage can be adjusted by the air con- trol. -
Page 11: Spa Shell Diagram
SPA SHELL DIAGRAM SPA OPERATION Refer to the diagram above. The function of each component is explained below: The eight uni-directional thera-jets (A) are located on both sides of the spa. Five jets focus the water massage on your upper or lower back. The remaining three jets provide a foot hydro-massage for three of the seating positions. -
Page 12: Console Diagram
CONSOLE DIAGRAM USING THE CONSOLE Refer to the console diagram above. The function of each console control is explained below: Temperature Display: During normal use this display shows the actual water temperature. When the Set Temp indicator is lit, the display shows the set temperature. - Page 13 USING THE DIVERTER The Diverter is located on the other side of the spa from the console. The Diverter controls the flow and intensity of the water through the hydrotherapy jets. Diverter Diverter Right Middle Refer to the drawing above. When the diverter is turned to the left, the pump will provide intense hydrotherapy through the eight jets shown above the dotted line.
-
Page 14: Posting The Warning Sign
POSTING THE WARNING SIGN The warning sign, shown below, must be posted on a wall or fence, where all users of the hydrotherapy spa will be able to see it. Whenever the spa is moved, the sign must also be moved and reposted near the spa. -
Page 15: Maintenance
MAINTENANCE The hydrotherapy spa is designed to provide you with years of enjoyment. Please follow the guidelines below to properly maintain your hydrotherapy spa. MAINTENANCE SCHEDULE DAILY ¥ Check the water level and refill the spa to the level shown on page 9, step 3. ¥... - Page 16 WATER CHEMISTRY The hydrotherapy spa comes with a starter chemical pack for maintaining the water in the spa. (See TEST- ING AND TREATING THE WATER on page 10.) Additional chemicals can be purchased at a pool and spa supply store. CAUTION: The chemicals used to maintain the pH balance of the water and to sanitize the water can be dangerous.
- Page 17 To drain the hydrotherapy spa, follow these steps: 1. Set the temperature control on the console to the lowest setting. 2. Shut off the circuit breaker or GFCI. 3. Remove the access cover from the back of the spa unit. 4.
- Page 18 CONVERTING THE SPA TO A 240 VOLT POWER SOURCE The hydrotherapy spa is designed to operate with either a 120v or 240v power source. For your conve- nience, it is shipped ready to be plugged directly into a 120v/15 amp home outlet. However, you can greatly improve the performance of the spa by converting the spaÕs power supply to receive power from a 240v power source.
-
Page 19: Maintenance Notes
MAINTENANCE NOTES Maintenance is an important part of keeping your spa in top operational condition. Use the space below to make any special notes you may want to remember for future reference, or to keep a maintenance log. -
Page 20: Trouble-Shooting
TROUBLE - SHOOTING Most problems can be solved by following the simple steps below. Find the symptom that applies and follow the steps listed. If further assistance is needed, call our Customer Service Department toll-free at 1-800-999-3756, Monday through Friday, 6 a.m. until 6 p.m. Mountain Time. 1. - Page 21 9. SYMPTOM: THE WATER LEVEL DROPS a. Some water loss due to evaporation is normal. If rapid water loss occurs, or if you notice wet- ness on the floor around the hydrotherapy spa, then the spa shell may have a leak. Contact your local spa and pool service provider for repairs.
-
Page 22: Part List
PART LISTÑModel No. WLHS42081 Key No. Qty. Description Buckle Screw Buckle Bracket Screw Mounting Bolt Mounting Nut Blue Lens Heater Switch Small Star Washer Heat Sensor Filter Cartridge Hose Cap Diverter Pump Motor Control Unit Spa Unit Console Air Control Knob Spa Cover Control Unit Screw Small Index Nut... -
Page 23: Exploded Drawing
EXPLODED DRAWINGÑModel No. WLHS42081 R0698A... -
Page 24: Ordering Replacement Parts
1. The MODEL NUMBER of the product (WLHS42081). 2. The NAME of the product (DAYBREAK 515 by WESLO ¨ 3. The SERIAL NUMBER of the product (see the front cover of this manual).
