Model No. WLHS20702
Serial No.
USER'S MANUAL
The serial number can be found in the
location shown below. Write the serial
number in the space above.
Serial Number Decal
(on the frame behind the access cover)
QUESTIONS?
PLEASE CALL DIRECT TO OUR
TOLL-FREE CUSTOMER HOT
LINE. The trained technicians
on our customer hot line will
provide immediate assistance,
free of charge to you.
CUSTOMER HOT LINE:
1-877-897-7493
Mon.–Fri., 6 a.m.–6 p.m. MST
CAUTION
Visit our website at
Read all precautions and instruc-
tions in this manual before
www.weslo.com
using this equipment. Save this
new products, prizes,
manual for future reference.
fitness tips, and much more!
Advertisement
Table of Contents
Related Manuals for Weslo Daybreak 207 WLHS20702
Summary of Contents for Weslo Daybreak 207 WLHS20702
- Page 1 CUSTOMER HOT LINE: 1-877-897-7493 Mon.–Fri., 6 a.m.–6 p.m. MST CAUTION Visit our website at Read all precautions and instruc- tions in this manual before www.weslo.com using this equipment. Save this new products, prizes, manual for future reference. fitness tips, and much more!
-
Page 2: Table Of Contents
LIMITED HYDROTHERAPY SPA WARRANTY .........Back Cover WESLO ®... -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS WARNING: TO REDUCE THE RISK OF DROWNING, ELECTRIC SHOCK, OR SERIOUS INJURY, READ THE FOLLOWING IMPORTANT PRECAUTIONS BEFORE USING THE DAYBREAK 207. READ AND FOLLOW ALL INSTRUCTIONS 1. It is the responsibility of the owner to ensure that all users of the spa are adequately informed of all precautions. - Page 4 20. Do not use an extension cord with the spa; this could damage the motor and will void the warranty. 21. DANGER—If you will be using the spa out- side, do not bury the power cord. Keep the power cord away from lawn mowers, hedge trimmers, and other similar equipment.
-
Page 5: Save These Instructions
34. WARNING—To reduce the risk of injury or drowning: Consult your physician about pos- sible side-effects of any medications you may be taking before using the spa. Heat from the water, in conjunction with some medications, may cause drowsiness and increase the risk of drowning. -
Page 6: Before You Begin
BEFORE YOU BEGIN Congratulations for selecting the new WESLO BREAK 207 hydrotherapy spa. The DAYBREAK 207 offers the features and quality of a traditional hot tub at an affordable price, providing the benefits of hydrotherapy in the comfort and privacy of your home. -
Page 7: Choosing A Location For The Spa
CHOOSING A LOCATION FOR THE SPA There are many factors to consider when choosing a location to set up the spa. These factors vary depending on whether you plan to use the spa inside or outside. We have listed several factors you may wish to consider as you decide where you want to set up your spa. -
Page 8: Setup And Assembly
SETUP AND ASSEMBLY Before beginning assembly, carefully read the following information and instructions: • Place all parts of the spa in a cleared area and remove the packing materials from the spa shell; do not dispose of the packing materials until assembly is completed. - Page 9 4. Attach the nozzle of the included air pump to the valve on the Insulating Liner (12). Fill the Insulating Liner with air. Be careful not to overfill the Insulating Liner. Lay the Spa Cover (13) on the floor as shown. Set the Insulating Liner (12) inside the Spa Cover.
-
Page 10: Posting The Warning Sign
POSTING THE WARNING SIGN The included warning sign, shown below, must be posted on a wall or fence where it will be visible to all users of the spa. If the spa is moved, the sign must also be moved and reposted near the spa. If the sign becomes lost or illegible, call our toll-free Customer Hot Line at 1-877-897-7493 to obtain a free replace- ment sign. - Page 11 TESTING AND TREATING THE WATER The first time you use the spa, you should test and treat the water. You must also treat the water each time you refill the spa. A test strip and a chemical pack are available at your local pool and spa supplier. Follow the directions carefully on the chemical pack to test and treat the water.
- Page 12 SPA JET OPERATION Refer to the diagram above. The function of each fea- ture is explained below: The three fixed thera-jets (A), located on one end of the spa, focus a water massage on your back. The three adjustable thera-jets (B) can be adjusted for a custom water massage.
-
Page 13: Maintenance
MAINTENANCE The spa is designed to provide years of enjoyment. Follow the guidelines below to properly maintain the spa. MAINTENANCE SCHEDULE DAILY • Check the water level. If necessary, refill the spa to the level shown in step 3 on page 8. •... - Page 14 WATER CHEMISTRY CAUTION: The chemicals used to maintain the pH balance of the water and to sanitize the water can be dangerous. Always follow these basic guide- lines when handling the chemicals: 1. Always read and follow the directions on the label, unless directed otherwise.
- Page 15 To drain the spa, follow these steps: 1. Set the temperature control on the console to the lowest setting. 2. Unplug the power cord. 3. Remove the access cover from the spa. 4. Remove the drainage hose from the clip and attach a garden hose to the valve on the drainage hose.
-
Page 16: Trouble-Shooting
TROUBLE - SHOOTING Most problems can be solved by following the simple steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, call our Customer Service Department toll-free at 1-877-897-7493, Monday through Friday, 6 a.m. until 6 p.m. Mountain Time. 1. - Page 17 8. SYMPTOM: THE WATER PULSATES OR THERE IS MINIMUM WATER FLOW a. This usually occurs only when the water level is low. Add water to the level shown in step 3 on page 8. b. The filter may be dirty. Check the filter and clean it if necessary.
-
Page 18: Part List
PART LIST Model No. WLHS20702 Key No. Qty. Description Buckle Screw Buckle 1/4” x 1 1/4” Bolt Lock Washer Heater Wire Harness Temperature/Hi Limit Probe Assembly Console Overlay Pressure Switch Control Box/Power Cord Removable Collar Pump Motor Insulating Liner Spa Cover Drowning Warning Decal Flat Washer Sun Warning Decal... -
Page 19: Exploded Drawing
EXPLODED DRAWING Model No. WLHS20702 R1001A 34 33... -
Page 20: Ordering Replacement Parts
• The MODEL NUMBER of the product (WLHS20702) • The NAME of the product (WESLO • The SERIAL NUMBER of the product (see the front cover of this manual) • The KEY NUMBER and DESCRIPTION of the desired part(s) (see the PART LIST on page 18).
