Model No. WLEX28080
Serial No.
Write the serial number in the
space above for future reference.
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions, or if there are
missing or damaged parts, we
will guarantee complete satis-
faction through direct assis-
tance from our factory.
TO AVOID UNNECESSARY
DELAYS, PLEASE CALL DIRECT
TO OUR TOLL-FREE CUSTOMER
HOT LINE. The trained techni-
cians on our customer hot line
will provide immediate assis-
tance, free of charge to you.
CUSTOMER HOT LINE:
1-800-999-3756
Mon.ÐFri., 6 a.m.Ð6 p.m. MST
Patent Pending
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Keep this manual
for future reference.
Serial
Number
Decal
USER'S MANUAL
Visit our website at
www.weslo.com
new products, prizes,
fitness tips, and much more!
¨
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Weslo WLEX28080
Summary of Contents for Weslo WLEX28080
- Page 1 Model No. WLEX28080 Serial No. Write the serial number in the space above for future reference. Serial Number Decal QUESTIONS? As a manufacturer, we are com- mitted to providing complete customer satisfaction. If you have questions, or if there are...
-
Page 2: Table Of Contents
¨ TABLE OF CONTENTS IMPORTANT PRECAUTIONS .............3 BEFORE YOU BEGIN . -
Page 3: Important Precautions
IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read the following important precautions before using the WESLO ¨ PURSUIT 680s. 1. Read all instructions in this manual before using the 680s. 2. It is the responsibility of the owner to ensure that all users of the 680s are adequately informed of all precautions. -
Page 4: Before You Begin
(excluding holidays). To help us assist you, please mention the product model number and serial number when calling. The model number is WLEX28080. The serial number can be found on a decal attached to the PURSUIT 680s (see the front cover of this manual for the location of the decal). -
Page 5: Assembly
ASSEMBLY Place all parts of the exercise cycle in a cleared area and remove the packing materials. Do not dispose of the packing materials until assembly is completed. Assembly requires the included tools and your own adjustable wrench PART CHART Use the drawings below to identify the small parts used in assembly. - Page 6 1. Loosen the Frame Knob (29) on the right side of the Frame (1). Slide the Seat Frame (2) out until it stops. Tighten the Frame Knob. Attach the Stabilizer (30) to the Seat Frame (2) with two M8 x 70mm Carriage Bolts (27) and two M8 Nylon Locknuts (55).
- Page 7 5. Attach the Console (33) to the Handlebar Post (3) with four #8 x 1/2Ó Screws (43). Be careful to avoid pinching the wires and cables. Next, press the Resistance Knob (32) onto the Resistance Control (31). Attach the Resistance Knob with the Knob Screw (71).
- Page 8 9. Attach the Seat Bracket (63) to the Seat Upright (64) with four M8 x 65mm Carriage Bolts (52) and four M8 Nylon Locknuts (55). 10. Attach the Seat (44) to the Seat Bracket (63) with four M6 x 16mm Hex Head Screws (46). 11.
-
Page 9: How To Use The Exercise Cycle
13. Identify the Left Pedal (39) (there is an ÒLÓ on the Left Pedal). Using an adjustable wrench, tighten the Left Pedal counterclockwise into the left arm of the Crank (7). Tighten the Right Pedal (not shown) clockwise into the right arm of the Crank (7). 14. -
Page 10: Battery Installation
DESCRIPTION OF THE CONSOLE The console is designed to help you get the most from your workouts. As you exercise, you can watch your progress around the LED track, while the display provides continuous exercise feedback. You can even measure your heart rate using the built-in pulse sensor. -
Page 11: How To Use The Pulse Sensor
HOW TO USE THE PULSE SENSOR The convenient pulse sensor allows you to measure your heart rate at any time during your workouts. You can measure your heart rate before you begin exercis- ing, while you exercise, and again when you finish. To use the pulse sensor, first Outer... -
Page 12: Maintenance And Storage
MAINTENANCE AND STORAGE Inspect and tighten all parts of the exercise cycle reg- ularly. The exercise cycle can be cleaned with a soft, damp cloth. To prevent damage to the console, keep liquids away from the console and keep the console out of direct sunlight. -
Page 13: Conditioning Guidelines
CONDITIONING GUIDELINES The following guidelines will help you to plan your exercise program. Remember that proper nutrition and adequate rest are essential for successful results. WARNING: Before beginning this or any exercise program, consult your physician. This is especially important for individuals over the age of 35 or individuals with pre- existing health problems. -
Page 14: Part List
PART LISTÑModel No. WLEX28080 Key No. Qty. Description Frame Seat Frame Handlebar Post Idler Arm Idler Wheel Drive Belt Crank 12Ó Pulley Bearing Assembly Left Pedal Strap M8 x 55mm Carriage Bolt M8 x 100mm Hex Head Bolt Handle Endcap... -
Page 15: Exploded Drawing
EXPLODED DRAWINGÑModel No. WLEX28080 R0100A 53 54 58 22 18 19... -
Page 16: Ordering Replacement Parts
Friday, 6 a.m. until 6 p.m. Mountain Time (excluding holidays). To help us assist you, please be prepared to give the following information: ¥ The MODEL NUMBER of the product (WLEX28080). ¥ The NAME of the product (WESLO ¥ The SERIAL NUMBER of the product (see the front cover of this manual).
