Model No. WLEX27181
Serial No.
Write the serial number in the
space above for reference.
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions, or if there are
missing or damaged parts, we
will guarantee complete satis-
faction through direct assis-
tance from our factory.
TO AVOID UNNECESSARY
DELAYS, PLEASE CALL DIRECT
TO OUR TOLL-FREE CUSTOMER
HOT LINE. The trained techni-
cians on our customer hot line
will provide immediate assis-
tance, free of charge to you.
CUSTOMER HOT LINE:
1-800-999-3756
Mon.ÐFri., 6 a.m.Ð6 p.m. MST
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Keep this manual
for future reference.
Serial
Number
Decal
USER'S MANUAL
Visit our website at
www.weslo.com
new products, prizes,
fitness tips, and much more!
¨
Patent Pending
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Weslo WLEX27181
Summary of Contents for Weslo WLEX27181
- Page 1 Model No. WLEX27181 Serial No. Write the serial number in the space above for reference. Serial Number Decal QUESTIONS? As a manufacturer, we are com- mitted to providing complete customer satisfaction. If you have questions, or if there are missing or damaged parts, we...
-
Page 2: Table Of Contents
¨ TABLE OF CONTENTS IMPORTANT PRECAUTIONS .............3 BEFORE YOU BEGIN . -
Page 3: Important Precautions
IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read the following important precautions before using the WESLO ¨ PURSUIT 675s. 1. Read all instructions in this manual before using the exercise cycle. 2. It is the responsibility of the owner to ensure that all users of the exercise cycle are ade- quately informed of all precautions. -
Page 4: Before You Begin
(excluding holidays). To help us assist you, please mention the product model number and serial number when calling. The model number is WLEX27181. The serial number can be found on a decal attached to the PURSUIT 675s (see the front cover of this manual for the location of the decal). -
Page 5: Assembly
ASSEMBLY Place all parts of the WESLO ¨ PURSUIT 675s in a cleared area and remove the packing materials. Do not dispose of the packing materials until assembly is completed. Assembly requires the included tools and your own adjustable wrench... - Page 6 1. Loosen the Frame Knob (29) on the right side of the Frame (1). Slide the Seat Frame (2) out until it stops. Tighten the Frame Knob. 2. Route the Extension Wire (56) down through the Handlebar Post (3) and plug it into the Reed Switch Wire (42).
- Page 7 5. Attach the Seat Upright (64) to the Seat Frame (2) with four M8 x 55mm Carriage Bolts (11) and four M8 Nylon Locknuts (55). Note: It may be helpful to tip the exercise cycle on its side to attach the Seat Upright.
- Page 8 8. Attach the Seat (44) to the Seat Bracket (63) with four M6 x 16mm Hex Head Screws (46). 9. Attach the Seat Handles (25) to the Seat Bracket (63) with two M8 x 100mm Hex Head Bolts (12), two M8 x 16mm Washers (26), and two M8 Nylon Locknuts (55).
-
Page 9: How To Use The Exercise Cycle
11. Identify the Left Pedal (39) (there is an ÒLÓ on the Left Pedal for identification). Using an adjustable wrench, tighten the Left Pedal counterclockwise into the left arm of the Crank (7). Tighten the Right Pedal (not shown) clockwise into the right arm of the Crank (7). - Page 10 DESCRIPTION OF THE CONSOLE The console features six modes that provide instant exercise feedback during your workouts. The modes are described below. ¥ SpeedÑDisplays your pedaling speed, in miles per hour. ¥ TimeÑDisplays the elapsed time. Note: If you stop pedaling for ten seconds or longer, the time mode will pause until you resume.
-
Page 11: Maintenance And Storage
MAINTENANCE AND STORAGE Inspect and tighten all parts of the exercise cycle reg- ularly. The exercise cycle can be cleaned with a soft, damp cloth. To prevent damage to the console, keep liquids away from the console and keep the console out of direct sunlight. -
Page 12: Conditioning Guidelines
CONDITIONING GUIDELINES WARNING: Before beginning this or any exercise program, consult your physician. This is especially important for individuals over the age of 35 or individuals with pre- existing health problems. The following guidelines will help you to plan your exercise program. - Page 13 A Cool-downÑFinish each workout with 5 to 10 min- utes of stretching. This will increase your flexibility and will help to prevent post-exercise problems. EXERCISE FREQUENCY To maintain or improve your condition, plan three work- outs each week, with at least one day of rest between SUGGESTED STRETCHES The correct form for several basic stretches is shown at the right.
-
Page 14: Part List
PART LISTÑModel No. WLEX27181 Key No. Qty. Description Frame Seat Frame Handlebar Post Idler Arm Idler Wheel Drive Belt Crank 12Ó Pulley Bearing Assembly Left Pedal Strap M8 x 55mm Carriage Bolt M8 x 100mm Hex Head Bolt Handle Endcap... -
Page 15: Exploded Drawing
EXPLODED DRAWINGÑModel No. WLEX27181 18 19 53 54 58 22 R0899A... -
Page 16: Ordering Replacement Parts
Friday, 6 a.m. until 6 p.m. Mountain Time (excluding holidays). To help us assist you, please be prepared to give the following information: ¥ The MODEL NUMBER of the product (WLEX27181). ¥ The NAME of the product (WESLO ¥ The SERIAL NUMBER of the product (see the front cover of this manual).
