Model No. WLEX14000
Serial No.
Write the serial number in the
space above for reference.
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions, or if there are
missing parts, we will guarantee
complete satisfaction through
direct assistance from our factory.
TO AVOID UNNECESSARY
DELAYS, PLEASE CALL DIRECT
TO OUR TOLL-FREE CUSTOMER
HOT LINE. The trained techni-
cians on our customer hot line
will provide immediate assis-
tance, free of charge to you.
CUSTOMER HOT LINE:
1-800-999-3756
Mon.ÐFri., 6 a.m.Ð6 p.m. MST
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Keep this manual
for future reference.
Serial
Number
Decal
USER'S MANUAL
Visit our website at
www.weslo.com
new products, prizes,
fitness tips, and much more!
Patent Pending

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WLEX14000 and is the answer not in the manual?

Questions and answers

John Riley
February 10, 2025

How do you reattach the belt

1 comments:
Mr. Anderson
May 14, 2025

To reattach the belt on a Weslo WLEX14000, first remove the left side shield. Then open the Strap Buckle (57) and slightly pull the end of the Resistance Strap (12). Close the Strap Buckle and turn the Flywheel (20) to ensure there is not too much resistance. Once the Resistance Strap is properly adjusted, reattach the left side shield.

This answer is automatically generated

John Riley
March 8, 2025

How do I order a new drive belt for my WesloPursut 719 recumbent bike, WLEX 1400, drive belt is part # 6.

John Riley
March 8, 2025

Yes I need a new drive belt part #6, how do I order it

Subscribe to Our Youtube Channel

Summary of Contents for Weslo WLEX14000

  • Page 1 Model No. WLEX14000 Serial No. Write the serial number in the space above for reference. Serial Number Decal QUESTIONS? As a manufacturer, we are com- mitted to providing complete customer satisfaction. If you have questions, or if there are missing parts, we will guarantee complete satisfaction through direct assistance from our factory.
  • Page 2: Table Of Contents

    TABLE OF CONTENTS IMPORTANT PRECAUTIONS .............3 BEFORE YOU BEGIN .
  • Page 3: Important Precautions

    IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read the following important precau- tions before using the WESLO 1. Read all instructions in this manual before using the exercise cycle. 2. It is the responsibility of the owner to ensure that all users of the exercise cycle are ade- quately informed of all precautions.
  • Page 4: Before You Begin

    (excluding holidays). To help us assist you, please mention the product model number and serial number when calling. The model number is WLEX14000. The serial number can be found on a decal attached to the exercise cycle (see the front cover of this manual for the location of the decal).
  • Page 5: Assembly

    ASSEMBLY Place all parts of the exercise cycle in a cleared area and remove the packing materials. Do not dispose of the packing materials until assembly is completed. Assembly requires the included tools and your own adjustable wrench screwdriver PART CHART Use the drawings below to identify the small parts used in assembly.
  • Page 6 1. Carefully slide the Handlebar Post (3) onto the Frame (1) while pulling the excess Reed Switch Wire (42) and Resistance Cable (31) up through the Handlebar Post. Attach the Handlebar Post with three M10 x 25mm Button Head Screws (53) and three M10 Split Washers (54).
  • Page 7 5. Attach the Seat Upright (64) to the Seat Frame (2) with four M8 x 54mm Carriage Bolts (11), four M8 Flat Washers (51), and four M8 Nylon Locknuts (55). Note: It may be helpful to tip the exercise cycle on its side to attach the Seat Upright.
  • Page 8 8. Attach the Seat (44) to the Seat Bracket (63) with four M6 x 16mm Screws (46). 9. Attach the Seat Handles (25) to the Seat Bracket (63) with two M10 x 97mm Hex Head Bolts (12) and two M10 Nylon Locknuts (26). 10.
  • Page 9: How To Use The Exercise Cycle

    11. Identify the Left Pedal (39); there is an ÒLÓ on the Left Pedal for identification. Using an adjustable wrench, tighten the Left Pedal counterclockwise into the left arm of the Crank (8). Tighten the Right Pedal (not shown) clockwise into the right arm of the Crank.
  • Page 10 DESCRIPTION OF THE CONSOLE Mode Button Upper Display Lower Display The innovative console features six modes that pro- vide instant exercise feedback during your workouts. The upper display will show your current speed, the elapsed time, the distance you have pedaled, and the numbers of fat calories and calories you have burned.
  • Page 11: Maintenance And Storage

    Make sure that your thumb is positioned as shown, and that you are applying the proper amount of pressure to the pulse sensor. Try the sensor several times until you become familiar with it. 5. To turn off the power, wait for about four minutes. Note: The monitor has an Òauto-offÓ...
  • Page 12: Conditioning Guidelines

    CONDITIONING GUIDELINES WARNING: Before beginning this or any exercise program, consult your physician. This is especially important for individuals over the age of 35 or individuals with pre-existing health problems. The pulse sensor is not a medical device. Various factors, including the user's move- ment, may affect the accuracy of heart rate readings.
  • Page 13: Suggested Stretches

    SUGGESTED STRETCHES The correct form for several basic stretches is shown below. Move slowly as you stretchÑnever bounce. 1. Toe Touch Stretch Stand with your knees bent slightly and slowly bend forward from your hips. Allow your back and shoulders to relax as you reach down toward your toes as far as possible.
  • Page 14: Part List

    PART LISTÑModel No. WLEX14000 Key No. Qty. Description Frame Seat Frame Handlebar Post Idler Arm M4 x 12mm Screw Drive Belt M5 Nut 12Ó Pulley/Crank Bearing Assembly M5 x 30mm Screw M8 x 54mm Carriage Bolt M10 x 97mm Hex Head Bolt...
  • Page 15: Exploded Drawing

    EXPLODED DRAWINGÑModel No. WLEX14000 53 54 R1000A...
  • Page 16: Ordering Replacement Parts

    Friday, 6 a.m. until 6 p.m. Mountain Time (excluding holidays). To help us assist you, please be prepared to give the following information: ¥ The MODEL NUMBER of the product (WLEX14000) ¥ The NAME of the product (WESLO ¥ The SERIAL NUMBER of the product (see the front cover of this manual) ¥...
