Model No. WLEL36070
Serial No.
Serial
Number
Decal
QUESTIONS?
As a manufacturer, we are
committed to providing com-
plete customer satisfaction. If
you have questions, or if there
are missing or damaged parts,
we will guarantee complete
satisfaction through direct
assistance from our factory.
TO AVOID DELAYS, PLEASE
CALL DIRECT TO OUR TOLL-
FREE CUSTOMER HOT LINE.
The trained technicians on our
customer hot line will provide
immediate assistance, free of
charge.
CUSTOMER HOT LINE:
1-800-999-3756
Mon.ÐFri., 6 a.m.Ð6 p.m. MST
CAUTION
Read all precautions and instruc-
tions in this manual before
using this equipment. Keep this
manual for future reference.
Patent Pending
USER'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WLEL36070 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Weslo WLEL36070

Summary of Contents for Weslo WLEL36070

  • Page 1 ¨ Model No. WLEL36070 Serial No. Serial Number Decal QUESTIONS? As a manufacturer, we are committed to providing com- plete customer satisfaction. If you have questions, or if there are missing or damaged parts, we will guarantee complete satisfaction through direct assistance from our factory.

  • Page 2: Table Of Contents

    MAINTENANCE ............... .8 HOW TO USE THE WESLO ECLIPSE .

  • Page 3: Important Precautions

    IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read the following important precautions before using the elliptical exerciser. 1. Read all instructions in this manual before using the elliptical exerciser. Use the ellipti- cal exerciser only as described. 2.

  • Page 4: Before You Begin

    The model number is WLEL36070. The serial number can be found on a decal attached to the ECLIPSE (see the front cover of this manual for the location of the decal).

  • Page 5: Part Identification Chart

    PART IDENTIFICATION CHART Use the chart below to identify the small parts used in assembly. The number in parenthesis below each part is the key number of the part, from the PART LIST on page 14. The number after the dash indicates the M8 x 55mm Hex Head Bolt (63)Ð2 M4 x 16mm Screw (51)Ð6 Console Screw (33)Ð4...

  • Page 6: Assembly

    ASSEMBLY Place all parts of the WESLO ¨ ECLIPSE in a cleared area and remove the packing materials. Do not dispose of the packing materials until assembly is completed. In addition to the included allen wrench and flat wrench, a phillips screwdriver adjustable wrenches 1.
  • Page 7 4. Connect the Reed Switch Wire (3) to the Extension Wire (15). Slide the Upright (2) onto the Frame (1); be careful not to pinch the Reed Switch Wire (3), the Extension Wire (15), or the Resistance Cable (17). Attach the Upright with three M10 x 25mm Button Head Screws (25) and three Split Washers (69).

  • Page 8: Maintenance

    7. The Console (13) requires two ÒAAÓ batteries (not included). Alkaline batteries are recommended. To install batteries, first slide up the Battery Cover (14). Carefully remove the battery clip from the Console (13). Insert two batteries into the battery clip. Make sure that the negative ends of the batteries (marked ÒÐÓ) are touching the springs.
  • Page 9 ELECTRONIC MONITOR TROUBLE-SHOOTING If the console does not function properly, the batteries should be replaced. To replace the batteries, see assembly step 7 on page 8. In addition, make sure that the console wire is connected to the extension wire. See assembly step 6 on page 7. HOW TO ADJUST THE REED SWITCH If the console does not display correct feedback, the reed switch should be adjusted.

  • Page 10: How To Use The Weslo

    HOW TO USE THE WESLO HOW TO EXERCISE ON THE ECLIPSE To mount the ECLIPSE, pin the handlebars in the sta- tionary position, hold the handlebars, and step onto the pedal that is in the lowest position. Next, step onto the other pedal.
  • Page 11 DESCRIPTION OF THE CONSOLE The console features five modes that provide instant exercise feedback during your workouts. The modes are described below. Display ¥ Reps/Min.ÑDisplays your speed, in repetitions (strides) per minute. ¥ TimeÑDisplays the length of time you have exer- cised.

  • Page 12: Conditioning Guidelines

    CONDITIONING GUIDELINES The following general guidelines will help you to plan your exercise program. Remember that proper nutri- tion and adequate rest are essential for successful results. WARNING: Before beginning this or any exer- cise program, consult your physician. This is especially important for persons over the age of 35 or persons with pre-existing health problems.
  • Page 13 WORKOUT GUIDELINES Each workout should include the following three parts: A warm-up, lasting 5 to 10 minutes. Begin with slow, controlled stretches, and progress to more rhythmic stretches to increase the body temperature, heart rate, and circulation in preparation for strenuous exercise. Training zone exercise, consisting of 20 to 30 min- utes of exercising with your heart rate in your training zone.

  • Page 14: Part List

    PART LISTÑModel No. WLEL36070 Key No. Qty. Description Frame Upright Reed Switch Wire Stabilizer Left Side Shield Right Side Shield Left Pedal Arm Right Pedal Arm Pedal Left Handlebar Right Handlebar Foam Handgrip Console Battery Cover Extension Wire Pedal Resistance Knob...

  • Page 15: Exploded Drawing

    EXPLODED DRAWINGÑModel No. WLEL36070 68 55 20 23 R1297A...

  • Page 16: How To Order Replacement Parts

    Friday, 6 a.m. until 6 p.m. Mountain Time (excluding holidays). To help us assist you, please be pre- pared to give the following information when calling: ¥ The MODEL NUMBER of the product (WLEL36070). ¥ The NAME of the product (WESLO ¥...
