Product End-of-Life Disassembly Instructions
Product Category: Monitors and Displays
Marketing Name / Model
[List multiple model if applicable]
LCD Monitor / R227DP*/ R247DP*
Purpose: The document is intended for use by end-of-life recyclers or treatment facilities. It provides the basic
instructions for the disassembly of Hyundai IT products to remove components and materials requiring selective
treatment, as defined by EU directive 2012/19/EU, Waste Electrical and Electronic Equipment (WEEE).
1.0 Items Requiring Selective Treatement
1.1 Items listed below are classified as requiring selective treatment.
1.2 Enter the quantity of items contained within the product which require selective treatment in the right column, as
applicable.
Item Description
Printed Circuit Board (PCB) or Printed Circuit
Assemblies (PCA)
Batteris
Mercury-containing components
Liquid Crystal Display (LCD) with a surface
greater than 100 sq cm
Cathode Ray Tubes (CRT)
Capacitors / Condensers (Containing PCB/PCT)
Electrolytic Capacitors / Condensers measuring
greater than 2.5 cm in diameter or height
External electrical cables and cords
Gas Discharge Lamps
Plastics containing Brominated Flame
Retardants weighing > 25 grams (not including
PCBs or PCAs already listed as a separate item
above)
Components and parts containing toner and ink,
including liquids, semi-liquids (gel/paste) and
toner
Components and wates containing asbestos
Components, parts and materials containing
refactory ceramic fibers
Components, parts and material containing
radioactive substances
Notes
With a surface greater than 10 sq
Main board, LCD driver board
All types including standard alkaline and lithium
coin or button style batteries None
For example, mercury in lamps, display backlights.
Scanner lamps, swithches, batteries None
Included background illuminated displays with gas
discharge lamps
None
None
None
DP cable
None
None
Include the cartridges, print heads, tubes, vent
chambers, and service stations. None
None
None
None
Quality
of items
included
in product
2
-
-
1
-
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Hyundai R227DP Series
Summary of Contents for Hyundai R227DP Series
- Page 1 Purpose: The document is intended for use by end-of-life recyclers or treatment facilities. It provides the basic instructions for the disassembly of Hyundai IT products to remove components and materials requiring selective treatment, as defined by EU directive 2012/19/EU, Waste Electrical and Electronic Equipment (WEEE).
- Page 2 2.0 Tools Required List the type and size of the tools that would typically be used to disassemble the product to a point where components and materials requiring selective treatment can be removed. Tool Size (if Tool Description applicable) Screwdrivers Plastic Jig 3.0 Product Disassembly Process List the basic steps that should typically be followed to remove components and materials requiring selective...
- Page 3 3-1. Disassemble and Assemble...
- Page 5 3-2. Disassemble Product 1) Unscrew the screw using the driver. (*Tool) 2) Open Rear Cover with Tool.
- Page 6 3) Separate Rear Cover with Tool Screw 4) Open the Rear cover from Front cover Key Pad 5) Separate cables and Remove the REAR cover Assembly from Front cover Assembly. Separate the KEY board and remove Speakers with screw driver. Screw Screw 6) Unscrew with Driver 2points...
- Page 7 LCD module Assembly Front mold 8) Separate the Main board from Rear Cover. Unscrew with Driver 5points. Separate the main board. Main board Assembly. Separate cables. Cables Main board...
- Page 8 9) Separate the board of LCD driver board on the Panel. Unscrew with Driver 3points Press the film by hand and remove it from the T-con board.
