Weslo Pursuit E20 User Manual

Weslo Pursuit E20 User Manual

Weslo home gym user's manual pursuit e 20
Hide thumbs

Advertisement

Table of Contents

Model No. WLEX13820
Serial No.
Write the serial number in the
space above for reference.
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions, or if there are
missing parts, we will guarantee
complete satisfaction through
direct assistance from our factory.
TO AVOID DELAYS, PLEASE
CALL DIRECT TO OUR TOLL-
FREE CUSTOMER HOT LINE. The
trained technicians on our cus-
tomer hot line will provide imme-
diate assistance, free of charge to
you.
CUSTOMER HOT LINE:
1-800-999-3756
Mon.–Fri., 6 a.m.–6 p.m. MST
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Keep this manual
for future reference.
Serial
Number
Decal
USER'S MANUAL
Visit our website at
www.weslo.com
new products, prizes,
fitness tips, and much more!
Patent Pending

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Pursuit E20 and is the answer not in the manual?

Questions and answers

Related Manuals for Weslo Pursuit E20

Summary of Contents for Weslo Pursuit E20

  • Page 1 Mon.–Fri., 6 a.m.–6 p.m. MST CAUTION Read all precautions and instruc- tions in this manual before using this equipment. Keep this manual for future reference. USER'S MANUAL Patent Pending Visit our website at www.weslo.com new products, prizes, fitness tips, and much more!

  • Page 2: Table Of Contents

    LIMITED WARRANTY ............Back Cover WESLO is a registered trademark of ICON Health & Fitness, Inc.

  • Page 3: Important Precautions

    IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read the following important precau- tions before using the exercise cycle. 1. Read all instructions in this manual before using the exercise cycle. 2. Use the exercise cycle only as described in this manual.

  • Page 4: Before You Begin

    BEFORE YOU BEGIN Thank you for selecting the new WESLO E 20 exercise cycle. The PURSUIT E 20 exercise cycle offers an effective form of low-impact exercise that offers greater cardiovascular benefits and increased muscle toning. And the exercise cycle fea- tures adjustable resistance to let you tailor your exer- cise to the level that’s perfect for you.

  • Page 5: Assembly

    ASSEMBLY Place all parts of the exercise cycle in a cleared area and remove the packing materials. Do not dispose of the packing materials until assembly is completed. Assembly requires the included tools and your own adjustable wrench screwdriver PART CHART Use the drawings below to identify the small parts used in assembly.
  • Page 6 1. Carefully slide the Upright (3) onto the Frame (1), while pulling the excess Reed Switch Wire (42) and Resistance Cable (31) up through the Upright. Attach the Upright with three M10 x 25mm Button Head Screws (53) and three M10 Split Washers (54).
  • Page 7 5. Connect the Reed Switch Wire (42) to the corre- sponding console wire. Insert the excess wire into the Upright. Attach the Console (33) to the Upright (3) with four M4 x 16mm Screws (43). Be careful not to pinch the wires or the cable.
  • Page 8 9. Attach the Seat (44) to the Seat Bracket (63) with four M6 x 16mm Screws (46). 10. Attach the Seat Handles (25) to the Seat Bracket (63) with two M10 x 97mm Hex Head Bolts (12) and two M10 Nylon Locknuts (26). 11.

  • Page 9: How To Use The Exercise Cycle

    12. Identify the Left Pedal (39); there is an “L” on the Left Pedal for identification. Using an adjustable wrench, tighten the Left Pedal counterclockwise into the left arm of the Crank (8). Tighten the Right Pedal (not shown) clockwise into the right arm of the Crank.
  • Page 10 DESCRIPTION OF THE CONSOLE Mode Button The innovative console features six modes that pro- vide instant exercise feedback during your workouts: Speed—Displays your pedaling speed, in miles per hour. Time—Displays the elapsed time. Note: If you stop pedaling for ten seconds or longer, the time mode will pause until you resume.

  • Page 11: Maintenance And Storage

    MAINTENANCE AND STORAGE Inspect and tighten all parts of the exercise cycle reg- ularly. The exercise cycle can be cleaned with a soft, damp cloth. To prevent damage to the console, keep liquids away from the console and keep the console out of direct sunlight.
  • Page 12 HOW TO ADJUST THE REED SWITCH If the console does not display correct feedback, the reed switch may need to be adjusted. To adjust the reed switch, you must first remove the left side shield (see HOW TO REMOVE THE LEFT SIDE SHIELD on page 11).

  • Page 13: Conditioning Guidelines

    CONDITIONING GUIDELINES WARNING: • Before beginning this or any exercise pro- gram, consult your physician. This is espe- cially important for individuals over the age of 35 or individuals with pre-existing health problems. The following guidelines will help you to plan your exercise program.

  • Page 14: Part List

    PART LIST—Model No. WLEX13820 Key No. Qty. Description Frame Seat Frame Upright Idler Arm M4 x 12mm Screw Drive Belt M5 Nut 12” Pulley/Crank Bearing Assembly M5 x 30mm Screw M8 x 54mm Carriage Bolt M10 x 97mm Hex Head Bolt M4 x 38mm Self-tapping Screw Hex Crank Nut Flywheel Assembly...

  • Page 15: Exploded Drawing

    EXPLODED DRAWING—Model No. WLEX13820 R0802A...

  • Page 16: Ordering Replacement Parts

    • The MODEL NUMBER of the product (WLEX13820) • The NAME of the product (WESLO • The SERIAL NUMBER of the product (see the front cover of this manual) • The KEY NUMBER and DESCRIPTION of the part(s) (see the PART LIST on page 14) ICON Health &...
