Elliptical exerciser

Advertisement

Model No. WLEL71807.0
Serial No.
Write the serial number in the space
above for reference.
Serial Number
Decal
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions, or if parts are
damaged or missing, PLEASE
DO NOT CONTACT THE STORE.
For assistance, contact our
Customer Service Department
CALL TOLL-FREE:
1-866-699-3756
Mon.–Fri. 6 a.m.–6 p.m. MST
Sat. 8 a.m.–4 p.m. MST
ON THE WEB:
www.wesloservice.com
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Keep this manu-
al for future reference.
USER'S MANUAL
Visit our website at
www.weslo.com
new products, prizes,
fitness tips, and much more!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WLEL71807.0 and is the answer not in the manual?

Questions and answers

Summary of Contents for Weslo WLEL71807.0

  • Page 1 Model No. WLEL71807.0 Serial No. Write the serial number in the space above for reference. Serial Number Decal QUESTIONS? As a manufacturer, we are com- mitted to providing complete customer satisfaction. If you have questions, or if parts are damaged or missing, PLEASE DO NOT CONTACT THE STORE.
  • Page 2: Table Of Contents

    Apply the decal in the loca- tion shown. Note: The decal may not be shown at actual size. WESLO is a registered trademark of ICON IP, Inc.
  • Page 3: Important Precautions

    IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read all important precautions and instructions in this manual and all warnings on your elliptical exerciser before using your elliptical exerciser. ICON assumes no responsibility for personal injury or property damage sustained by or through the use of this product.
  • Page 4: Before You Begin

    BEFORE YOU BEGIN Congratulations for selecting the new WESLO MOMENTUM 630 elliptical exerciser. The MOMEN- TUM 630 elliptical exerciser is an incredibly smooth exerciser that moves your feet in a natural elliptical path, minimizing the impact on your knees and ankles.
  • Page 5: Assembly

    ASSEMBLY To hire an authorized service technician to assemble the elliptical exerciser, call 1-800-445-2480. Assembly requires two persons. Place all parts of the elliptical exerciser in a cleared area and remove the packing materials. Do not dispose of the packing materials until assembly is completed. In addition to the included hex keys, assembly requires a Phillips screwdriver wrench , and a rubber mallet...
  • Page 6 2. While another person lifts the back of the Frame (1), attach the Rear Stabilizer (28) to the Frame with two M10 x 75mm Carriage Bolts (34) and two M10 Nylon Locknuts (33). 3. The Console (23) requires four “AA” batteries (not included);...
  • Page 7 5. Tip: Be careful not to pinch the Upper Wire (44) and the Lower Wire Harness (53) during this step. While another person holds the Upright (2) near the Frame (1), connect the Upper Wire (44) to the Lower Wire Harness (53). Push the excess wire downward into the Frame.
  • Page 8 7. Identify the Left Pedal Arm (11), which is marked with a “Left” sticker. Attach a Pedal (13) to the Left Pedal Arm with two M6 x 45mm Flat Head Screws (36). Attach the other Pedal (not shown) to the Right Pedal Arm (not shown) in the same way.
  • Page 9: How To Use The Elliptical Exerciser

    HOW TO USE THE ELLIPTICAL EXERCISER HOW TO EXERCISE ON THE ELLIPTICAL EXERCISER To mount the elliptical exerciser, hold the handlebars and step onto the pedal in the lower position. Then, step onto the other pedal. Push the pedals until they begin to move with a continuous motion.
  • Page 10: How To Use The Manual Mode

    HOW TO USE THE MANUAL MODE Turn on the console. To turn on the console, press the On/Reset button or begin pedaling. The entire display and the pace guide will light for a moment; the console will then be ready for use. Select the manual mode.
  • Page 11 If the displayed heart rate appears to be too high or too low, or if your heart rate is not displayed, lift your thumb off the pulse sensor for a few sec- onds. Then, place your thumb on the pulse sensor as described above.
  • Page 12: Maintenance And Troubleshooting

    MAINTENANCE AND TROUBLESHOOTING Inspect and tighten all parts of the elliptical exerciser regularly. Replace any worn parts immediately. To clean the elliptical exerciser, use a damp cloth and a small amount of mild soap. Important: Keep liq- uids away from the console, place only a sealed water bottle in the water bottle holder, and keep the console out of direct sunlight.
  • Page 13: Exercise Guidelines

    EXERCISE GUIDELINES WARNING: Before beginning this or any exercise program, consult your physi- cian. This is especially important for persons over the age of 35 or persons with pre-exist- ing health problems. The pulse sensor is not a medical device. Various factors may affect the accuracy of heart rate readings.
  • Page 14: Part List

    PART LIST—Model No. WLEL71807.0 Key No. Qty. Description Frame Upright Left Side Shield Right Side Shield Handlebar Arm Left Handlebar Idler Assembly Right Handlebar Spring Front Stabilizer Left Pedal Arm Right Pedal Arm Pedal Axle Cap Pedal Disc Disc Crossbar...
  • Page 15: Exploded Drawing

    EXPLODED DRAWING—Model No. WLEL71807.0 30 31 R0607A...
  • Page 16: Ordering Replacement Parts

    ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to provide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) •...
