Summary of Contents for Sunnydaze Decor WAR-191
- Page 1 OWNER'S MANUAL Item No.: WAR-191 READ BEFORE USE! 5010198...
- Page 2 CONSUMER: Retain this manual FOR FUTURE RE FERENCE. READ CAREFULLY AND COMPLETELY BEFORE ASSEMBLY OR USE FOR USE WITH 1.02LBS CYLINDER WITH TYPE 1 CONNECTION ONLY (NOT SUPPLIED) ● For propane use only. This outdoor gas appliance is to be installed on a flat, solid and NON COMBUSTIBLE surface. ●...
- Page 3 DANGER FLAMMABLE GAS UNDER PRESSURE. LEAKING LP-GAS MAY CAUSE A FIRE OR EXPLOSION IF IGNITED CAUSING SERIOUS BODILY INJURY OR DEATH. CONTACT LP GAS SUPPLIER FOR REPAIRS, OR DISPOSAL OF THIS CYLINDER OR UNUSED LP-GAS. WARNING FOR OUTDOOR USE ONLY.* DO NOT USE OR STORE CYLINDER IN A BUILDING, GARAGE OR ENCLOSED AREA.
-
Page 4: Table Of Contents
TABLE OF CONTENTS Important Safety Information.………………………………………………….…… page 5 Information About Propane (LP) Gas………………………………………………page 6 Specifications..…………….………………………………………………………….page 6 Product Diagram…..………………………………………………………….…… page 7 Installation Instructions…………..……………………………………..….……….. page 8 Installation Instructions…………..……………………………………..….……….. page 9 Operation Instruction……………..……………………………..…………………... page 10 Maintenance Information..…………………………………………………………... page 10 Parts List......…………………………………………………………... page 11... -
Page 5: Important Safety Information
IMPORTANT SAFETY INFORMATION • The installation must conform with local codes or, in the absence of local codes, with the National Fuel Gas Code ANSI Z223.1/NFPA 54 or CAN/CGA-B149.2 Propane Installation Code. • Use as directed – do not modify. Do not operate unit when wet. •... -
Page 6: Information About Propane (Lp) Gas
INFORMATION ABOUT PROPANE (LP) GAS A self contained LP-gas for use with this appliance must have a capacity of 1.02 lbs. (height 8 inch, 200mm; diameter 4 inch, 100mm). The LP-gas supply cylinder to be used must be constructed and marked in accordance with the specifications for LP-gas cylinders of U.S. -
Page 7: Product Diagram
FIRE GLASS SUS430 BURNER SOLEPLATE KNOB M6.0*25.0BOLT Q235 PART RETULATOR ASS’Y SUS430 BURNER CONNECTIN GASKET SEAL PART M4.0*6.0 Q235 BURNER SUS430 BODY PART PARTS NAME METERIAL... -
Page 8: Installation Instructions
INSTALLATION INSTRUCTIONS WARNING: This item heavy. necessary precautions should be taken when lifting and assembling this fireplace. Make certain the fireplace body always remains upright. Do not lie on its side or you could cause damage to the body. Most parts of this fireplace are pre-assembled (Figure 1) before shipment. -
Page 9: Installation Instructions
INSTALLATION INSTRUCTIONS Parts List/Assembly Table 1. Put the basin stand on a clean level surface that cannot be damaged by water. 2. Put the pump in the fountain basin, thread the electric cord through the pipe that is not in the center down into the center of the stand. 3. -
Page 10: Operation Instruction
OPERATION INSTRUCTIONS Lighting and Setting Control for Gas Before lighting, make sure the valve knob is in the “OFF” position. 1. From the OFF position, push in and turn control knob counter-clockwise to the LOW position. 2. Always perform a leak test before lighting the burner. See page 4 3.
