eSky wireless ES825 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
eSky wireless Inc.
ES825
User Manual
V1.1
2019
2 2 - 3 0 3 , 3 2 8 X
S
, S
, C
I N G H U
T R E E T
U Z H O U
H I N A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ES825 and is the answer not in the manual?

Questions and answers

Related Manuals for eSky wireless ES825

Summary of Contents for eSky wireless ES825

  • Page 1 Inc. ES825 User Manual V1.1 2019 2 2 - 3 0 3 , 3 2 8 X I N G H U T R E E T U Z H O U H I N A...

  • Page 2: Table Of Contents

    Version history ..........................3 1. ES825 introduction ........................5 1.1 ES825 Appearance Introduction ..................5 1.2 ES825 Working Mode Introduction ..................6 1.2.1 1-day-1-report mode ....................6 1.2.2 Deep sleep interval mode ..................6 1.2.3 1-hour SMS check mode ..................7 1.2.4 SMS standby mode ....................

  • Page 3: Version History

    Version history Version Data Note V1.0 2018.11.12 First version V1.1 2018.12.5 Second version...
  • Page 4 FCC Statement Any Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.

  • Page 5: Es825 Introduction

    1. ES825 introduction ES825 is a 2G (GPRS)/ 4G (Cat.M1&Cat.NB1) mini waterproof GPS tracker for pet (without voice feature). ES825 use BG96 module and support WIFI positioning, it uses magnet charging method. ES825 for non-portable use only. 1.1 ES825 Appearance Introduction 1.

  • Page 6: Es825 Working Mode Introduction

    1.2.1 1-day-1-report mode This mode has the lowest power consumption. The command likes “Mode,0,8#”, which can be checked by ES825 protocol. After setting the command, the device will wake up at 8AM every day to report. After reporting, it will be power off, and will wake up the next day at 8AM.

  • Page 7: 1-Hour Sms Check Mode

    1.2.3 1-hour SMS check mode This mode saves a lot of data traffic. After setting this mode, the device will wake up every one hour to check if has SMS command coming but no reporting, if Yes, it will deal with the SMS command, if not, after waiting some time, it will power off.

  • Page 8: Test Preparation

    2. Test Preparation Make sure the equipment below are all available. Equipment Lists: Equipment Name Number Note ES825 Necessary SIM Card Necessary Mobile phone Necessary( APP) Charging wire Necessary...

  • Page 9: Quick Test Steps

    LED will be off, if still no LED on, please contact Step 4: Green LED Blink slowly or Make sure ES825 is in the open on? (in the open air) air, and there are no tall buildings (Please check in chapter 3.1.4)

  • Page 10: Step1: Insert Sim Card

    3.1.1 Step1: Insert SIM Card First you should take off the rubber ring of ES825 and prepare the Nano SIM Card, like below: Note: This step must be done before power on the ES825. After inserted the SIM Card, you will hear” ka”, it means the SIM Card is inserted OK.

  • Page 11: Step3: Red And Green Led On

    3.1.3 Step3: Red and green LED on? After power on the ES825, Red and green LED will be on for 1 second, and then green LED will start blinking. 3.1.4 Step4: Green LED Blink slowly or on? (in the open air) Please go to the open air, and wait for some minutes, the Green LED blink slowly(if GPRS or LTE not lock) or on( if GPRS or LTE locked) if GPS fixed.

  • Page 12: Step6: Green Led On? (In The Open Air)

    Make sure SIM supports SMS service. Try to use the SIM card send SMS by your mobile phone. Make sure GPRS/LTE coverage is good.   If all above are meet but still no response, please contact us. 3.1.8 Step8: Normal test Now you can do your test follow the ES825 protocol.

  • Page 13: App Test

    3.2 APP test Step 1: Download and install APP (Please check in chapter 3.2.1) Step 2: Register and login (Please check in chapter 3.2.2) Step 3: Register device OK Step 4: Check the reason (Please check in chapter 3.2.3) (Please check in chapter 3.2.4) Step 5: Normal function test (Please check in chapter 3.2.5) (Please check in Lchapter...

  • Page 14: Step1: Download And Install App

    3.2.1 Step1: Download and install APP Please search the key words “etracking” in the app store, and choose the one like below shows, download and install. Open...

  • Page 15: Step2: Register And Login

    3.2.2 Step2: Register and login After install the APP, open the APP. Please click “Register” if you need register first, and follow the steps as below:  Please input your e-mail account on the first white blank  Please click the first blue blank and you will receive 4 numbers from your email. ...

  • Page 16: Step3: Binding Device Device

    3.2.3 Step3: Binding device device After login, you will see the screen as below: if you want the turn into existing account, please click “ Switch account ” If you do not turn into other account, please continue to bind devices.
  • Page 17 You can bind the device by scanning 2 QR code of the device or entering the IMEI of the device . Please click the “ RichScan” or “ Manual input” to bind devices. Then you can see the screen as below: Click “next” and press the SOS button of ES825, and you will enter management interface of the APP. Note: The first account binding the devices is the administrator.

  • Page 18: Step4: Check The Reason

    3.2.4 Step4: Check the reason If register fail,  Device off line noted, please check if the battery has run out of power, you can let the device in charge for a while and then try again.  Make sure GPRS/LTE signal coverage is good. ...
