Model No. WECCSY24540
Serial No.
Write the serial number in the
space above for future reference.
Serial Number Decal (Under Seat)
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions, or if there are
missing parts, please call:
1-888-936-4266
Mon.–Fri. 8h00 until 18h30
EST (excluding holidays).
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
USER'S MANUAL
Patent Pending
Visit our website at
www.weiderfitness.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WECCSY24540 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Weider WECCSY24540

Summary of Contents for Weider WECCSY24540

  • Page 1 Model No. WECCSY24540 Serial No. Write the serial number in the space above for future reference. Serial Number Decal (Under Seat) QUESTIONS? As a manufacturer, we are com- mitted to providing complete customer satisfaction. If you have questions, or if there are...

  • Page 2: Table Of Contents

    Note: A PART IDENTIFICATION CHART and a PART LIST/EXPLODED DRAWING are attached in the center of this manual. Remove the PART IDENTIFICATION CHART and PART LIST/EXPLODED DRAWING before begin- ning assembly. WEIDER is a registered trademark of ICON IP, Inc.

  • Page 3: Warning Decal Placement

    WARNING DECAL PLACEMENT The decals shown here have been placed on the weight system. If a decal is missing or illegible, please call our Customer Service Department toll-free at 1-888-936-4266, Monday through Friday, 8h00 until 18h30 Eastern Time, to order a free replacement decal. Apply the decal in the location shown. Decal 1 Keep hands and fingers clear of...

  • Page 4: Important Precautions

    IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read the following important precautions before using the weight system. 1. Read all instructions in this manual before using the weight system. Use the weight sys- tem only as described in this manual. 2.

  • Page 5: Before You Begin

    18h30 eastern time (excluding holidays).To help us assist you, please note the product model number and serial number before calling. The model number is WECCSY24540. The serial number can be found on a decal attached to the weight system (see the front cover of this manual).

  • Page 6: Assembly

    ASSEMBLY Make Assembly Easier for Yourself Everything in this manual is designed to ensure that the weight system can be assem- bled successfully by anyone. Before begin- ning assembly, make sure to read the information on this page. This brief intro- duction will save you much more time than it takes to read it.

  • Page 7: Frame Assembly

    Frame Assembly Before beginning assembly, make sure you understand the information in the box on page 6. For help identifying small parts, see the PART IDENTIFICATION CHART in the center of this manual. Press three 50mm Square Inner Caps (30) into the Base (1) and the Stabilizer (2).
  • Page 8 3. Press a 50mm Square Inner Cap (30) into the Front Upright (5). Slide the Front Upright (5) onto the indicated M10 x 65mm Carriage Bolts (64) and thread two M10 Nylon Locknuts (80) onto the Bolts. Do not tight- en the Locknuts yet.
  • Page 9 5. Press two 50mm Square Inner Caps (30) into the Foot Plate (4). Lift the Base (1) to align the indicated holes with the holes in the Foot Plate (4). Attach the Foot Plate to the Base with two M10 x 65mm Carriage Bolts (64) and two M10 Nylon Locknuts (80).
  • Page 10 8. Attach the Squat Arm (16) to the Squat Frame (9) with four M10 x 35mm Bolts (69), four M10 Washers (77), and four M10 Nylon Locknuts (80). Make sure the bolt heads rest inside of the hexagonal holes in the Squat Frame. Wet the Squat Arm (16) with soapy water.

  • Page 11: Arm Assembly

    11. Insert two Weight Guides (17) into the indicated holes in the Base (1). While a second person holds the Weight Guides, attach them to the Base with an M10 x 155mm Bolt (66), two M10 Washers (77), and an M10 Nylon Locknut (80). Make sure the slots in the Weight Guides are on the bottom, as shown.
  • Page 12 13. Press a 50mm Round Inner Cap (32) and a 50mm Round Butterfly Cap (89) into the Left Butterfly Arm (14). Press two 29mm Round Inner Caps (33) into a Press Handle (25). Wet the lower end of the Left Butterfly Arm (14) with soapy water.

  • Page 13: Cable Assembly

    Cable Assembly 16. See the CABLE DIAGRAMS on page 23 as you assemble the cables and to identify the cables. Attach the Short Swivel Bracket (50) to the Front Upright (5) with an M10 x 48mm Bolt (86) and an M10 Nylon Locknut (80).
  • Page 14 20. Note: This step is shown from the other side of the weight system. Wrap the Low Cable (55) over a “V”-pulley (47). Attach the Pulley and a Long Cable Trap (85) to the bracket on the Front Upright (5) with an M10 x 60mm Bolt (72) and an M10 Nylon Locknut (80).
  • Page 15 25. Wrap the Low Cable (55) over a 90mm Pulley (46). Attach the Pulley and a Cable Trap (48) to the Top Frame (11) with an M10 x 92mm Bolt (84), an M10 Washer (77), and an M10 Nylon Locknut (80). Make sure the Cable Trap is turned to hold the Cable in the groove of the Pulley.
  • Page 16 30. Identify the High Cable (54). Route the small ball on the Cable up through the Top Frame (11) and over a 90mm Pulley (46). Attach the Pulley inside the Top Frame with an M10 x 67mm Bolt (65), two 12.5mm Spacers (59), two M10 Washers (77), and an M10 Nylon Locknut (80).

  • Page 17: Seat Assembly

    34. Wrap the High Cable (54) under a 90mm Pulley (46). Attach the Pulley and a Cable Trap (48) to the Base (1) with an M10 x 48mm Bolt (86), an M10 Washer (77), and an M10 Nylon Locknut (80). Make sure the Cable Trap is turned to hold the Cable in the groove of the Pulley.
  • Page 18 38. Attach a Backrest (18) to the Front Upright (5) with four M6 x 16mm Screws (67). 39. Attach another Backrest (18) to the Squat Frame (9) with four M6 x 16mm Screws (67). 40. Press two 19mm Round Inner Caps (38) into a Pad Tube (24).
  • Page 19 41. Attach the Leg Lever Lock (41) to the Front Leg (7) with an M8 x 69mm Shoulder Bolt (78), an M10 Washer (77), and an M8 Nylon Locknut (83). Make sure that the shoulder of the Bolt is inserted all the way through the Front Leg. 42.

  • Page 20: Adjustments

    ADJUSTMENTS This section explains how to adjust the weight system. See the EXERCISE GUIDELINES on page 25 for impor- tant information about how to get the most benefit from your exercise program. Also, see the accompanying exer- cise guide to see the correct form for each exercise. Make sure all parts are properly tightened each time the weight system is used.
  • Page 21 ADJUSTING THE SQUAT BASE PLATE To use the Squat Base Plate (3), remove the Short Pin (56) and lower the Base Plate. Reinsert the Short Pin into the hole in the Stabilizer (2) towards the Base Plate, as shown. Make sure that the Short Pin is fully inserted through the Stabilizer.

  • Page 22: Weight Resistance Chart

    WEIGHT RESISTANCE CHART The chart below shows the approximate weight resistance at each exercise station. “Top” and refers to the 6 lb. (2.72 kg) top weight. The other numbers refer to the 12.5 lb. (5.67 kg) weight plates. Weight resistance shown for the butterfly arm station is for each butterfly arm.

  • Page 23: Cable Diagrams

    CABLE DIAGRAMS The cable diagrams show the approximate lengths and the proper routing of the High Cable (54) and the Low Cable (55). Use the diagrams to make sure that the cables and the cable traps have been assembled correctly. If the cables have not been correctly routed, the weight system will not function properly and damage may occur.

  • Page 24: Troubleshooting

    TROUBLESHOOTING Make sure all parts are properly tightened each time the weight system is used. Replace any worn parts immedi- ately. The weight system can be cleaned using a damp cloth and mild non-abrasive detergent. Do not use solvents. TIGHTENING THE CABLES Woven cable, the type of cable used on the weight system, can stretch slightly when it is first used.

  • Page 25: Exercise Guidelines

    EXERCISE GUIDELINES THE FOUR BASIC TYPES OF WORKOUTS Muscle Building To increase the size and strength of your muscles, push them close to their maximum capacity. Your mus- cles will continually adapt and grow as you progres- sively increase the intensity of your exercise. You can adjust the intensity level of an individual exercise in two ways: •...
  • Page 26 Rest for a short period of time after each set. The ideal resting periods are: • Rest for three minutes after each set for a muscle building workout. • Rest for one minute after each set for a toning work- out.
  • Page 27 EXERCISE MONDAY Date: AEROBIC EXERCISE TUESDAY Date: EXERCISE WEDNESDAY Date: THURSDAY AEROBIC EXERCISE Date: EXERCISE FRIDAY Date: Make photocopies of this page for scheduling and recording your workouts. WEIGHT WEIGHT WEIGHT SETS REPS SETS REPS SETS REPS...
  • Page 28 50mm Square Inner Cap (30) 50mm Round Inner Cap (32) 50mm x 70mm Inner Cap (37) 50mm Round Butterfly Cap (89) 19mm Round Inner Cap (38) 25mm x 70mm Inner Cap (31) 29mm Round Inner Cap (33) 25mm Round Outer Cap (36) 25mm Round Cover Cap (52)

  • Page 30: Part Identification Chart

    PART IDENTIFICATION CHART See the drawings below to identify small parts used in assembly. The number in parentheses by each drawing is the key number of the part, from the PART LIST in the center of this manual. Note: Some small parts may have been preattached.
  • Page 31 PART LIST—Model No. WECCSY24540 Key No. Qty. Description Base Stabilizer Squat Base Plate Foot Plate Front Upright Rear Upright Front Leg Seat Frame Squat Frame Short Foam Pad Top Frame Butterfly Frame Right Butterfly Arm Left Butterfly Arm Leg Lever...
  • Page 32 REMOVE THIS PART LIST/EXPLODED DRAWING FROM THE MANUAL. SAVE THIS PART LIST/EXPLODED DRAWING FOR FUTURE REFERENCE...
  • Page 33 EXPLODED DRAWING—Model No. WECCSY24540 R0704A...

  • Page 34: Ordering Replacement Parts

    Friday, 8h00 until 18h30 Eastern Time (excluding holidays). When ordering parts, please be prepared to give the following information: 1. The MODEL NUMBER of the product (WECCSY24540) 2. The NAME of the product (WEIDER 3. The SERIAL NUMBER of the product (see the front cover of this manual) 4.
