Weider 831.153991 User Manual

Weider 831.153991 User Manual

Resistance system exerciser
Hide thumbs Also See for 831.153991:
Table of Contents

Advertisement

Quick Links

Download this manual
Model No. 831.153991
Serial No.
Write the serial number in the
space above for future reference.
Serial Number Decal (under seat)
Visit our website at
www.weiderplatinum.com
• Assembly
• Adjustments
• Part List and Drawing
CAUTION
Read all precautions and instruc-
tions in this manual before
using this equipment. Save this
manual for future reference.
RESISTANCE SYSTEM EXERCISER
Sears, Roebuck and Co., Hoffman Estates, IL 60179
User's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 831.153991 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Weider 831.153991

Summary of Contents for Weider 831.153991

  • Page 1 Model No. 831.153991 Serial No. Write the serial number in the space above for future reference. Serial Number Decal (under seat) Visit our website at www.weiderplatinum.com • Assembly • Adjustments • Part List and Drawing CAUTION Read all precautions and instruc- tions in this manual before using this equipment.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS WARNING DECAL PLACEMENT ............. 3 IMPORTANT PRECAUTIONS .

  • Page 3: Warning Decal Placement

    WARNING DECAL PLACEMENT The decals shown here have been placed on the resistance system. If a decal is missing or illegible, please call 1-877-992-5999 to order a free replace- ment decal. Apply the decal in the loca- tion shown. Keep hands and fingers clear of this area.

  • Page 4: Important Precautions

    IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read the following important precautions before using the resistance system. 1. Read all instructions in this manual before using the resistance system. Use the resist- ance system only as described in this manual. 2.

  • Page 5: Before You Begin

    (1-800-469-4663). To help us assist you, please note the product model number and serial number before calling. The model number is 831.153991. The serial number can be found on a decal attached to the resist- ance system (see the front cover of this manual).

  • Page 6: Assembly

    ASSEMBLY Make Things Easier for Yourself This manual is designed to ensure that the resist- ance system can be assembled successfully by most people. However, it is important to realize that the versatile resistance system has many parts and that the assembly process will take time.
  • Page 7 2. Attach the Upright (3) to the Base (1) with two 3/8” x 2 3/4” Carriage Bolts (88), two 3/8” x 3” Bolts (87), and four 3/8” Nylon Locknuts (73) as shown. Note: This step will be easier to com- plete if the Upright and Base are tipped on their sides.
  • Page 8 4. Insert the connector of the lower wire harness (A) into the socket of the Upper Wire Harness (13). The connector should slide easily into the socket and snap into place. If the connector does not slide easily and snap into place, turn the connector over and then insert it.
  • Page 9 6. Grease a 3/8” x 4” Bolt (86) using the included grease pack. Attach the Bench Rail (23) to the Upright (3) with the Bolt and a 3/8” Nylon Jamnut (92). Make sure the Bolt is inserted through the indicated hole in the Bench Rail. Do not overtighten the Jamnut;...
  • Page 10 9. Attach the Lat Tower (5) to the Upright (3) with four 3/8” x 1” Screws (100) and four 3/8” Lock Washers (74). Plug the Upper Wire Harness (13) into the Console (53). Push all of the excess wire into the Upright (3).
  • Page 11 12. Pull the upper cable (B), which is attached inside of the Mech Assembly (6), up between the Upright (3) and the Pulley Plate (18). Attach another Large Pulley (17) between the Upright (3) and Pulley Plate (18) with an M12 x 62mm Button Bolt (80) and an M12 Nylon Locknut (72).
  • Page 12 16. Hold a Large Pulley (17) inside of the upper cable (B). Attach the Pulley to a Pulley Bracket (10) with an M12 x 58mm Button Bolt (81) and an M12 Nylon Locknut (72). Make sure that the cable is routed as shown in the CABLE DIAGRAM on page 18.
  • Page 13 20. Attach a 3 1/2” Pulley (89) inside of the hole in the Front Leg (31) with a 3/8” x 3 1/2” Bolt (90), two 1” Spacers (35), two 3/8” SAE Washers (75), and a 3/8” Nylon Jamnut (92). Make sure the Pulley is above the Leg Lever Cable (62).

  • Page 14: Upper Cable Adjustment

    UPPER CABLE ADJUSTMENT After completing the assembly of the resistance system, the tension on the upper cable (B) will need to be adjusted. Also, the upper cable can stretch slightly when it is first used. When this occurs, the upper cable ten- sion will need to be readjusted.

  • Page 15: Adjustments

    ADJUSTMENTS This section explains how to adjust the resistance system. See the EXERCISE GUIDELINES on page 20 for important information about how to get the most benefit from your exercise program. Also, see the accompany- ing exercise guide to see the correct form for each exercise. Make sure all parts are properly tightened each time the resistance system is used.
  • Page 16 ATTACHING THE ACCESSORIES To attach a Short Handle (67) to a high pulley, first attach the high pulley to the resistance system (see ATTACHING THE HIGH PULLEYS on page 15). Then, attach the Short Handle to the Short Cable (60) with a Cable Clip (64).

  • Page 17: Adjusting The Backrest

    ADJUSTING THE BACKREST The Backrest (40) can be used in a level position or one of three inclined positions. To use the Backrest in a level position, secure the Seat Carriage (48) to the adjustment hole in the Bench Rail (23) next to the Front Leg (31) (see ADJUSTING THE SEAT on page 15).

  • Page 18: Cable Diagram

    CABLE DIAGRAM The cable diagram shows the proper routing of the upper cable (B). Use the diagram to make sure that Upper Cable (B) the cable has been assembled correctly. If the cable has not been correctly routed, the resistance system will not function properly and damage may occur.

  • Page 19: Troubleshooting

    TROUBLESHOOTING CLEANING THE BAR GUIDES Over time, dust may build up on the Bar Guides (55), causing a squeaking noise as the resistance system is used. If this occurs, wipe off the Bar Guides with a damp cloth and a mild, non-abrasive detergent. Do not use solvents.

  • Page 20: Exercise Guidelines

    EXERCISE GUIDELINES THE FOUR BASIC TYPES OF WORKOUTS Muscle Building To increase the size and strength of your muscles, push them close to their maximum capacity. Your mus- cles will continually adapt and grow as you progres- sively increase the intensity of your exercise. You can adjust the intensity level of an individual exercise in two ways: •...

  • Page 21: Cooling Down

    Rest for a short period of time after each set. The ideal resting periods are: • Rest for three minutes after each set for a muscle building workout. • Rest for one minute after each set for a toning work- out.
  • Page 22 EXERCISE MONDAY Date: AEROBIC EXERCISE TUESDAY Date: EXERCISE WEDNESDAY Date: THURSDAY AEROBIC EXERCISE Date: EXERCISE FRIDAY Date: Make photocopies of this page for scheduling and recording your workouts. WEIGHT WEIGHT WEIGHT SETS REPS SETS REPS SETS REPS...
  • Page 23 EXERCISE MONDAY Date: AEROBIC EXERCISE TUESDAY Date: EXERCISE WEDNESDAY Date: THURSDAY AEROBIC EXERCISE Date: EXERCISE FRIDAY Date: Make photocopies of this page for scheduling and recording your workouts. WEIGHT WEIGHT WEIGHT SETS REPS SETS REPS SETS REPS...

  • Page 24: Part Identification Chart

    PART IDENTIFICATION CHART See the drawings below to identify small parts used in assembly. The number in parentheses by each drawing is the key number of the part, from the PART LIST in the center of this manual. Note: Some small parts may have been pre-attached.
  • Page 25 PART LIST—Model No. 831.153991 Key No. Qty. Description Base Base Plate Upright Foot Plate Lat Tower Mech Assembly Front Mech Cover Back Mech Cover Resistance Bar Pulley Bracket 1/4” x 5/8” Screw Transformer Upper Wire Harness Pulley Pivot Bracket Pivot Bracket Bushing...
  • Page 26 EXPLODED DRAWING—Model No. 831.153991 R0304A...

  • Page 27: Full One-Year Warranty

    FULL ONE-YEAR WARRANTY For one year from the date of purchase, if failure occurs due to defect in material or workmanship in this RESISTANCE SYSTEM EXERCISER, contact the nearest Sears Service Center throughout the United States and Sears will repair or replace the RESISTANCE SYSTEM EXERCISER, free of charge. Parts will be replaced for five years.

This manual is also suitable for:

Platinum xp600
