Model No. 831.153930
Serial No.
Write the serial number in the
space above for reference.
Serial Number Decal (under seat)
SEARS, ROEBUCK AND CO.
HOFFMAN ESTATES, IL 60179
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
USER'S MANUAL
Patent Pending
www.weiderfitness.com
new products, prizes,
fitness tips, and much more!
Visit our website at

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 831.153930f and is the answer not in the manual?

Questions and answers

Related Manuals for Weider 831.153930f

Summary of Contents for Weider 831.153930f

  • Page 1 Model No. 831.153930 Serial No. Write the serial number in the space above for reference. Serial Number Decal (under seat) SEARS, ROEBUCK AND CO. HOFFMAN ESTATES, IL 60179 CAUTION Read all precautions and instruc- tions in this manual before using this equipment.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS IMPORTANT PRECAUTIONS .............3 BEFORE YOU BEGIN .

  • Page 3: Important Precautions

    IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read the following important precautions before using the weight system. 1. Read all instructions in this manual and in the accompanying literature before using the weight system. 2. It is the responsibility of the owner to ensure that all users of the weight system are ade- quately informed of all precautions.

  • Page 4: Before You Begin

    BEFORE YOU BEGIN Thank you for selecting the versatile WEIDER 4850 weight system. The WEIDER system offers an impressive array of weight stations designed to develop every major muscle group of the body. Whether your goal is to tone your body, build...

  • Page 5: Assembly

    ASSEMBLY Make Assembly Easier Everything in this manual is designed to ensure that the weight system can be assem- bled successfully by anyone. Before beginning assembly, make sure to read the information on this page. This brief introduction will save you much more time than it takes to read it.

  • Page 6: Frame Assembly

    FRAME ASSEMBLY Make sure that you understand all of the information on page 5 before you begin assembling the weight system. Locate and open the parts bags labeled “FRAME ASSEMBLY 1” and “FRAME ASSEMBLY 2.” Press a 2” Square Inner Cap (105) into the open end of the Long Base (120).
  • Page 7 4. Press a 1 1/2” Square Inner Cap (67) into the square tube on the Butterfly Upright (3). Slide the Butterfly Upright (3) onto the two indicated 5/16” x 2 1/2” Carriage Bolts (110) in the Short Base (2). Finger tighten a 5/16” Nylon Locknut (86) onto each Carriage Bolt.
  • Page 8 7. Press a 2” x 3” Inner Cap (58) into the top of the Squat Upright (4). Slide the Squat Upright onto the two indicated 5/16” x 2 1/2” Carriage Bolts (110) in the Long Base (120). Finger tighten a 5/16” Nylon Locknut (86) onto each Carriage Bolt.
  • Page 9 9. Attach a Roller (39) and two 5/16” Washers (90) between the indicated set of holes in the Squat Slider (38) with a 5/16” x 3 1/2” Bolt (94), two 5/16” Washers (90), and a 5/16” Nylon Locknut (86) as shown.

  • Page 10: Arm Assembly

    12. Attach the Top Frame (6) between the Squat Upright (4) and the Swivel Upright (5) with four 5/16” x 3 3/4” Bolts (92), the two Short Frame Plates (52), and two 5/16” Nylon Locknuts (86) as shown. Do not tighten the Bolts and Locknuts yet.

  • Page 11: Cable Assembly

    16. Press a 1 1/2” x 2” Inner Cap (21) into the Right Butterfly Arm (26). Wet the lower end of the Arm with soapy water. Slide a Long Pad (54) onto the Arm. Slide two Nut Clips (108) onto a Press Handle (27). Attach the Press Handle to the Right Butterfly Arm (26) with two 5/16”...
  • Page 12 19. Route the Swivel High Cable (74) through the Swivel Upright (5) and over a 4 1/2” Pulley (119). Attach the Pulley inside the Upright with a 3/8” x 2 3/4” Bolt (101), two 3/8” Washers (91), two 1/2” Spacers (89), and a 3/8”...
  • Page 13 24. Remove the preattached 3 1/2” Pulleys (78) from the Offset Double “U”-bracket (61). Wrap the Swivel Cable (17) around a 3 1/2” Pulley (78). Attach the Pulley to the Offset Double “U”- bracket (61) with a 3/8” x 1 3/4” Bolt (93) and a 3/8” Nylon Locknut (87).
  • Page 14 29. Wrap the Lat Cable (88) around a 3 1/2” Pulley (78). Attach the Pulley and a Long Cable Trap (102) to the Top Frame (6) with a 3/8” x 1 3/4” Bolt (93) and a 3/8” Nylon Jamnut (113). Make sure the Cable Trap is turned to hold the Cable in the groove of the Pulley.
  • Page 15 34. Remove the preattached 3 1/2” Pulleys (78) from the Double “U”-bracket (62). Wrap the Butterfly Cable (69) under a 3 1/2” Pulley (78). Attach the Pulley to the Double “U”-bracket (62) with a 3/8” x 1 3/4” Bolt (93) and a 3/8” Nylon Locknut (87).
  • Page 16 39. Route the Leg Lever Cable (75) under a 4 1/2” Pulley (119). Attach the Pulley and a Large Cable Trap (121) to the indicated side of the Butterfly Upright (3) with a 3/8” x 3 3/4” Bolt (122), a 3/8” Washer (91), and a 3/8”...
  • Page 17 44. Wrap the Swivel Low Cable (72) over a 3 1/2” Pulley (78). Attach the Pulley to the Offset Double “U”- bracket (61) with a 3/8” x 1 3/4” Bolt (93) and a 3/8” Nylon Locknut (87). 45. Wrap the Swivel Low Cable (72) under a 3 1/2” Pulley (78).
  • Page 18 49. Wrap the Swivel Low Cable (72) over a 3 1/2” Pulley (78). Attach the Pulley and a Cable Trap (68) between the lower set of holes in the “U”-bracket (64) with a 3/8” x 2” Bolt (100) and a 3/8” Nylon Locknut (87).

  • Page 19: Seat Assembly

    53. Wrap the Squat Cable (73) under a 3 1/2” Pulley (78). Attach the Pulley and a Cable Trap to the sec- ond set of holes from the top in the indicated brack- et on the Long Base (120) with a 3/8” x 2” Bolt (100) and a 3/8”...
  • Page 20 57. Attach the Seat (16) to the Seat Frame (8) with two 1/4” x 3/4” Screws (114), a 1/4” x 2 1/2” Screw (99), and a 1/4” Washer (97). 58. Attach the Butterfly Backrest (15) to the Butterfly Upright (3) with four 1/4” x 3/4” Screws (114). 59.
  • Page 21 61. Unscrew the Adjustment Knob (115) and remove it from the Squat Bracket (37). Turn the Squat Backrest (35) so that the four screw holes are clos- er to the bottom of the Squat Backrest than the top. Attach the Squat Backrest to the Squat Bracket with four 1/4”...

  • Page 22: Adjustments

    ADJUSTMENTS The instructions below describe how each part of the weight system can be adjusted. Refer to the exercise guide accompanying this manual to see how the weight system should be set up for various exercises. IMPOR- TANT: When attaching the lat bar, row bar, or handle, make sure that the attachments are in the correct starting position for the exercise to be performed.
  • Page 23 ADJUSTING THE SQUAT ARM OR SWIVEL CARRIAGE To adjust the height of the Squat Arm (32), first turn the Adjustment Knob (115) on the Squat Bracket (37) counterclockwise several turns to loosen it. Next, pull the Handle and slide the Squat Bracket up or down to the desired position.

  • Page 24: Weight Resistance Chart

    WEIGHT RESISTANCE CHART The chart below shows the approximate weight resistance at each weight station. “Top” refers to the 10-pound top weight. The other numbers refer to the 10-pound weight plates. The butterfly arm resistance listed is the resistance for each butterfly arm. Note: The actual resistance at each weight station may vary due to differ- ences in individual weight plates as well as friction between the cables, pulleys, and weight guides.

  • Page 25: Troubleshooting

    TROUBLESHOOTING Make sure all parts are properly tightened each time the weight system is used. Replace any worn parts immedi- ately. The weight system can be cleaned using a damp cloth and mild non-abrasive detergent. Do not use solvents. TIGHTENING THE CABLES Woven cable, the type of cable used on the weight system, can stretch slightly when it is first used.

  • Page 26: Cable Diagrams

    CABLE DIAGRAMS The cable identification chart below shows the ends of each cable and the lengths of the cables. The cable dia- grams on this page and the following page show the proper routing of the cables. The numbers in the diagrams show the routes of the cables.
  • Page 27 Leg Lever Cable (75) Swivel Cable (17) Swivel Low Cable (72)

  • Page 28: Replacement Parts

    SEARS, ROEBUCK AND CO., DEPT. 817WA, HOFFMAN ESTATES, IL 60179 Part No. 190959 R1102A The model number and serial number of your WEIDER 4850 weight system are listed on a decal attached to the frame. See the front cover of this manual to find the location of the decal.
  • Page 29 This chart is provided to help you identify the small parts used in assembly. The number in parenthesis below each part refers to the key number of the part from the PART LIST in the center of this manual. Important: Some parts may have been pre-assembled for shipping purposes.
  • Page 30 1" Round Inner Cap (29) 1 1/2" x 2” Inner Cap (21) 2" x 2 1/2” Inner Cap (125) 2" Square Inner Cap (105) 1 1/2" Square Inner Cap (67) 2" x 3” Inner Cap (58)
  • Page 31 PART IDENTIFICATION CHART—Model No. 831.153930 1/2" Washer (1) 3/8" Washer (91) 5/16" Washer (90) 1/4" Washer (97) 1/2" Spacer (89) 3/4" Spacer (124) 1/2" Nut (118) 3/8" Nylon Locknut (87) 3/8" Nylon Jamnut (113) 5/16" Nylon Locknut (86) 1/4" Nylon Locknut (34) R1102A Cable Clip (83) 4 1/2"...
  • Page 32 3/8" x 2 1/2" Carriage Bolt (106) 1/4" x 1 1/2" Bolt (99) 3/8" x 2" Bolt (100) 3/8" x 1 3/4" Bolt (93) 5/16" x 1" Shoulder Bolt (103) 3/8" x 1" Bolt (13) #10 x 1" Screw (14) 5/16"...
  • Page 33 REMOVE THIS PART LIST/EXPLODED DRAWING FROM THE MANUAL. SAVE THIS PART LIST/EXPLODED DRAWING FOR FUTURE REFERENCE...
  • Page 34 PART LIST—Model No. 831.153930 No. Qty. Description 1/2” Washer Short Base Butterfly Upright Squat Upright Swivel Upright Top Frame Butterfly Top Frame Seat Frame Seat Upright Leg Lever Curl Pad Curl Post 3/8” x 1” Bolt #10 x 1” Screw Butterfly Backrest Seat Swivel Cable...
  • Page 35 EXPLODED DRAWING—Model No. 831.153930 R1102A...
