Weed Eater 545186837 Instruction Manual

Weed eater trimmer instruction manual
Hide thumbs
Table of Contents

Advertisement

Quick Links

Please do not return unit to retailer.
Por favor, no devuelva el aparato al lugar de compra.
Veuillez ne pas retourner l'outil au détaillant.
1-800-554-6723
www.weedeater.com
Manual de Instrucciones
For Occasional Use Only
WARNING:
Read and follow all Safety Rules and Operating Instructions before
using this product. Failure to do so can result in serious injury.
ADVERTENCIA:
Lea el manual de instrucciones y siga todas las advertencias e
instrucciones de seguridad. El no hacerlo puede resultar en lesiones
graves.
AVERTISSEMENT:
Lire le manuel d'instructions et bien respecter tous les avertisse-
ments et toutes les instructions de sécurité. Tout défaut de le faire
pourrait entraîner des blessures graves.
WEED EATER
1030 Stevens Creek Road
Augusta, GA 30907
Instruction Manual
Manuel d'Instructions
850 Matheson Blvd. West
Mississauga, Ontario L5V 0B4
545186837 Rev. 3 3/4/09 BRW
R
Trademark
FL20
FL23
WEED EATER

Advertisement

Table of Contents
loading

Related Manuals for Weed Eater 545186837

Summary of Contents for Weed Eater 545186837

  • Page 1 Lire le manuel d’instructions et bien respecter tous les avertisse- ments et toutes les instructions de sécurité. Tout défaut de le faire pourrait entraîner des blessures graves. WEED EATER 1030 Stevens Creek Road Augusta, GA 30907 545186837 Rev. 3 3/4/09 BRW Trademark Instruction Manual FL20 FL23 WEED EATER 850 Matheson Blvd.

  • Page 2: Identification Of Safety Symbols

    IDENTIFICATION OF SAFETY SYMBOLS DANGER: spool, and 0.065 inch (1,65 mm) recommended trimmer line. Never use blades, flailing devices, wire, rope, string, etc. Unit is designed for line trim- mer use only. Failure to follow these instructions may result in serious injury. WARNING: This unit can be dangerous! Careless or improper use can cause serious injury.

  • Page 3: Safety Rules

    IDENTIFICATION OF SAFETY SYMBOLS Store unit indoors in a high, dry place out of the reach of children. When servicing unit, use only identical replace- ment parts. Always stop unit and disconnect spark plug before cleaning or servicing. WARNING: Fire hazard. Never mix, pour, or store gasoline or use the unit near a flame or sparks (including smoking, open flames, or work that can cause sparks).

  • Page 4: Fuel Safety

    S Keep others away when making carburetor adjustments. S Use only recommended WEED EATER ac- cessories and replacement parts. S Have all maintenance and service not ex- plained in this manual performed by an autho- rized service dealer.

  • Page 5: Adjusting The Handle

    spark arresting screen will not require any service. ASSEMBLY WARNING: If received assembled, repeat all steps to ensure your unit is properly assembled and all fasteners are secure. Examine parts for damage. Do not use dam- aged parts. NOTE: If you need assistance or find parts missing or damaged, call 1-800-554-6723.

  • Page 6: Operation

    2-cycle air-cooled engine oil designed to be mixed at a ratio of 40:1. Poulan/WEED EATER brand synthetic oil is recommended. Mix gasoline and oil at a ratio of 40:1. A 40:1 ratio is obtained by mixing 3.2 fluid ounces (95 ml) of oil with 1...

  • Page 7: Starting A Cold Engine

    oil mixture leading to oil and fuel separation. HELPFUL TIP If your engine switch reads “push to stop”, it is always in the ON position. HOW TO STOP YOUR UNIT S To stop the engine, push and hold the STOP switch in the STOP position until the engine stops.

  • Page 8: Operating Position

    It is recommended that the engine not be operated for longer than 1 minute at full throttle. OPERATING POSITION ALWAYS WEAR: Eye protection Long pants Heavy shoes Cut from your right to your left. WARNING: Always wear eye protec- tion. Never lean over the trimmer head. Rocks or debris can ricochet or be thrown into eyes and face and cause blindness or other serious injury.

  • Page 9: Maintenance

    If any dealer other than an authorized service dealer performs work on the product, WEED EATER may not pay for repairs under warranty. It is your re- sponsibility to maintain and perform general maintenance.

  • Page 10: Service And Adjustments

    2. Clean entire surface of hub and spool. 3. Replace with pre- -wound spool, or cut a length of 18 feet of 0.065″ (1.65 mm) dia- meter WEED EATER brand line. WARNING: Never use wire, rope, string, etc., which can break off and become a dangerous missile.
  • Page 11 STORAGE WARNING: Perform the following steps after each use: S Allow engine to cool, and secure the unit before storing or transporting. S Store unit and fuel in a well ventilated area where fuel vapors cannot reach sparks or open flames from water heaters, electric motors or switches, furnaces, etc.

  • Page 12: Limited Warranty

    WEED EATER, a division of Husqvarna Consumer Outdoor Products N.A., Inc., warrants to the original consumer purchaser that each new WEED EATER brand gasoline tool or attachment is free from defects in material and workmanship and agrees to repair or replace under this warranty any defective gasoline product or attachment as follows from the original date of purchase.

  • Page 13: Your Warranty Rights And Obligations

    COVERED: REPAIR OR REPLACEMENT OF PARTS. Repair or replacement of any warranted part will be performed at no charge to the owner at an approved WEED EATER servicing center. If you have any questions regarding your warranty rights and responsi-...

  • Page 14: Maintenance, Replacement And Repair Of Emission Related Parts

    Moderate (50 hours) Intermediate (125 hours) Extended (300 hours) REPAIR OF EMISSION RELATED PARTS: Any WEED EATER approved replacement part used in the performance of any warranty maintenance or repair on emission related parts will be provided without charge to the owner if the part is under warranty.

This manual is also suitable for:

Fl23Fl20
