Please do not return unit to retailer.
Por favor, no devuelva el aparato al lugar de compra.
Veuillez ne pas retourner l'outil au détaillant.
1-800-554-6723
www.weedeater.com
Manual de Instrucciones
For Occasional Use Only
WARNING:
Read and follow all Safety Rules and Operating Instructions before
using this product. Failure to do so can result in serious injury.
ADVERTENCIA:
Lea el manual de instrucciones y siga todas las advertencias e
instrucciones de seguridad. El no hacerlo puede resultar en lesiones
graves.
AVERTISSEMENT:
Lire le manuel d'instructions et bien respecter tous les avertisse-
ments et toutes les instructions de sécurité. Tout défaut de le faire
pourrait entraîner des blessures graves.
Electrolux Home Products, Inc.
250 Bobby Jones Expressway
Augusta, GA 30907
Copyright E2002 Electrolux Home Products, Inc.
R
Instruction Manual
Manuel d'Instructions
530163513
Trademark
FL25 LE
12/5/02

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 530163513 and is the answer not in the manual?

Questions and answers

Related Manuals for Weed Eater 530163513

Summary of Contents for Weed Eater 530163513

  • Page 1 Lire le manuel d’instructions et bien respecter tous les avertisse- ments et toutes les instructions de sécurité. Tout défaut de le faire pourrait entraîner des blessures graves. Electrolux Home Products, Inc. 250 Bobby Jones Expressway Augusta, GA 30907 Copyright E2002 Electrolux Home Products, Inc. Trademark FL25 LE 530163513 12/5/02...

  • Page 2: Safety Rules

    Keep others away when making carburetor adjustments. Use only recommended Weed Eater" ac- cessories and replacement parts. Have all maintenance and service not ex- plained in this manual performed by an autho- rized service dealer.
  • Page 3 CUTTING SAFETY WARNING: Inspect the area before each use. Remove objects (rocks, broken glass, nails, wire, etc.) which can be thrown by or become entangled in line. Hard objects can damage the trimmer head and be thrown causing serious injury. Use only for trimming, scalping, mowing and sweeping.

  • Page 4: Operation

    2-cycle air-cooled engine oil designed to be mixed at a ratio of 40:1. Poulan/Weed Eater brand synthetic oil is recommended. Mix gasoline and oil at a ratio of 40:1. A 40:1 ratio is obtained by mixing 3.2 ounces (95 ml) of oil with 1 gallon (4...

  • Page 5: Starting A Cold Engine

    Engine Choke Lever ON/STOP Switch HALF FULL HOW TO START YOUR UNIT WARNING: The trimmer head will turn while starting the engine. Avoid any con- tact with the muffler. A hot muffler can cause serious burns. STARTING A COLD ENGINE (or a warm engine after running out of fuel) Starting Position...

  • Page 6: Trimmer Line Advance

    To stop engine: S Release the throttle trigger. S Push and release the engine ON/STOP switch. TRIMMER LINE ADVANCE The trimmer line will advance approximately 2 in. (5 cm) each time the bottom of the trimmer head is tapped on the ground with the engine running at full throttle.

  • Page 7: Maintenance

    MAINTENANCE WARNING: Disconnect the spark plug before performing maintenance except for carburetor adjustments. CHECK FOR LOOSE FASTENERS AND PARTS S Spark Plug Boot S Air Filter S Housing Screws S Assist Handle Screws S Debris Shield CHECK FOR DAMAGED OR WORN PARTS Contact an authorized service dealer for re- placement of damaged or worn parts.

  • Page 8: Service And Adjustments

    SERVICE AND ADJUSTMENTS LINE REPLACEMENT 1. Remove spool by firmly pulling on tap button. 2. Clean entire surface of hub and spool. 3. Replace with pre--wound spool, or cut a length of 20 feet of 0.080! (2 mm) diameter Weed Eaterr brand line.

  • Page 9: Troubleshooting Table

    S Check entire unit for loose screws, nuts, and bolts. Replace any damaged, broken, or worn parts. S At the beginning of the next season, use only fresh fuel having the proper gasoline to oil ratio. TROUBLESHOOTING TABLE WARNING: Always stop unit and disconnect spark plug before performing all of the recommended remedies below except remedies that require operation of the unit.

  • Page 10: Limited Warranty

    LIMITED WARRANTY ELECTROLUX HOME PRODUCTS, INC., warrants to the original purchaser that each new Weed Eaterr brand gasoline tool or attachment free from defects material workmanship and agrees to repair or replace under this warranty any defective gasoline product or attachment as follows from the original date of purchase.
  • Page 11 rights and responsibilities, you should contact your nearest authorized service center or call ELECTROLUX HOME PRODUCTS, INC., at 1--800--554--6723 WARRANTY PERIOD: Any warranted part which is not scheduled for re- placement as required maintenance, or which is scheduled only for regular inspection to the ef- fect of “repair or replace as necessary”...
