Please do not return unit to retailer.
Por favor, no devuelva el aparato al lugar de compra.
Veuillez ne pas retourner l'outil au détaillant.
1-800-554-6723
www.weedeater.com
Manual de Instrucciones
For Occasional Use Only
WARNING:
Read and follow all Safety Rules and Operating Instructions before
using this product. Failure to do so can result in serious injury.
ADVERTENCIA:
Lea el manual del operador y siga todas las advertencias e instruc-
ciones de seguridad. El no hacerlo puede resultar en lesiones gra-
ves.
AVERTISSEMENT:
Lire le manuel de l'utilisateur et bien respecter tous les avertisse-
ments et toutes les instructions de sécurité. Tout défaut de le
faire pourrait entraîner des blessures graves.
Electrolux Home Products, Inc.
250 Bobby Jones Expressway
Augusta, GA 30907
Copyright E2003 Electrolux Home Products, Inc.
R
Instruction Manual
Manuel d'Instructions
TE400 LE
530163368
Trademark
4/23/03

Advertisement

Table of Contents
loading

Related Manuals for Weed Eater 530163368

Summary of Contents for Weed Eater 530163368

  • Page 1 Lire le manuel de l’utilisateur et bien respecter tous les avertisse- ments et toutes les instructions de sécurité. Tout défaut de le faire pourrait entraîner des blessures graves. Electrolux Home Products, Inc. 250 Bobby Jones Expressway Augusta, GA 30907 Copyright E2003 Electrolux Home Products, Inc. Trademark TE400 LE 530163368 4/23/03...

  • Page 2: Safety Rules

    S Maintain unit according to recommended pro- cedures. Keep cutting line at proper length. S Use only 0.080” (2 mm) diameter Poulan/ Weed Eater! brand line. Never use wire, rope, string, etc. S Install required shield properly before using the unit. Use only specified trimmer head;...
  • Page 3 S Always store gasoline in a container ap- proved for flammable liquids. CUTTING SAFETY WARNING: Inspect the area before each use. Remove objects (rocks, broken glass, nails, wire, etc.) which can be thrown by or become entangled in line. Hard objects can damage trimmer head and be thrown causing serious injury.

  • Page 4: Operation

    2-cycle air- cooled engine oil designed to be mixed at a ratio of 40:1. Poulan/Weed Eater brand synthetic oil is recommended. Mix gasoline and oil at a ratio of 40:1. A 40:1 ratio is obtained by mixing 3.2 ounces (95ml) of oil with 1 gallon (4 liters) of un- leaded gasoline.
  • Page 5 container momentarily to assure that the fuel is thoroughly mixed. Always read and follow the safety rules relating to fuel before fueling your unit. IMPORTANT Experience indicates that alcohol blended fuels (called gasohol or using ethanol or methanol) can attract moisture which leads to separation and formation of acids during stor- age.

  • Page 6: Operating Position

    OPERATING INSTRUCTIONS It is recommended that the engine not be operated for longer than 1 minute at full throttle. OPERATING POSITION ALWAYS WEAR: Protection Long Pants Heavy Shoes Cut from your right to your left. WARNING: Always wear eye protec- tion.

  • Page 7: Maintenance

    Trimming 3 in. (8 cm) Above Ground SCALPING -- The scalping technique re- moves unwanted vegetationdown to the ground. Hold the bottom of the trimmer head about 3 in. (8 cm) above the ground and at an angle. Allow the tip of the line to strike the ground around trees, posts, monuments, etc.

  • Page 8: Service And Adjustments

    Air Filter Screws Air Filter Cover MUFFLER AND SPARK ARREST- ING SCREEN WARNING: The muffler on this prod- uct contains chemicals known to the State of California to cause cancer. WARNING: Muffler is very hot during and after use. Do not touch the muffler or al- low combustible material such as dry grass or fuel to do so.

  • Page 9: Seasonal Storage

    STORAGE WARNING: Perform the following steps after each use: S Allow engine to cool, and secure the unit before storing or transporting. S Store unit and fuel in a well ventilated area where fuel vapors cannot reach sparks or open flames from water heaters, electric motors or switches, furnaces, etc.
  • Page 10 TROUBLESHOOTING TABLE WARNING: Always stop unit and disconnect spark plug before performing all of the recommended remedies below except remedies that require operation of the unit. TROUBLE CAUSE Engine will not 1. ON/OFF switch in OFF start. position. 2.Engine flooded. 3.

  • Page 11: Limited Warranty

    LIMITED WARRANTY ELECTROLUX HOME PRODUCTS, INC., warrants to the original purchaser that each new Weed Eater brand gasoline tool or at- tachment is free from defects in material and workmanship and agrees to repair or replace under this warranty any defective gasoline product or attachment as follows from the original date of purchase.
  • Page 12 WARRANTY COMMENCEMENT DATE: The warranty period begins on the date the small off--road engine purchased. LENGTH OF COVERAGE: This warranty shall be for a period of two years from the ini- tial date of purchase. WHAT IS COVERED: REPAIR OR REPLACEMENT OF PARTS. Repair or replacement of any warranted part will be performed at no charge to the owner at an approved ELECTROLUX HOME PROD-...
