Please do not return unit to retailer.
Por favor, no devuelva el aparato al lugar de compra.
Veuillez ne pas retourner l'outil au détaillant.
1-800-554-6723
www.weedeater.com
Manuel de l'utilisateur
U L
R
DANGER:
Read and follow all Safety Rules and Operating Instructions before
using this product. Failure to do so can result in serious injury.
ADVERTENCIA:
Lea el manual del operador y siga todas las advertencias e instruc-
ciones de seguridad. El no hacerlo puede resultar en lesiones graves.
AVERTISSEMENT:
Lire le manuel de l'utilisateur et bien respecter tous les avertisse-
ments et toutes les instructions de sécurité. Tout défaut de le faire
pourrait entraîner des blessures graves.
Electrolux Home Products, Augusta, GA 30907
WCI Outdoor Products, Inc.
R
Trademark
Operator's Manual
Manual del Operador
BC3100
530087645
8/31/00

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 530087645 and is the answer not in the manual?

Questions and answers

Related Manuals for Weed Eater 530087645

Summary of Contents for Weed Eater 530087645

  • Page 1 Lire le manuel de l’utilisateur et bien respecter tous les avertisse- ments et toutes les instructions de sécurité. Tout défaut de le faire pourrait entraîner des blessures graves. Electrolux Home Products, Augusta, GA 30907 WCI Outdoor Products, Inc. Trademark BC3100 530087645 8/31/00...

  • Page 2: Safety Rules

    SAFETY RULES DANGER: This power tool can be dangerous! This unit can cause serious injury including amputation or blindness to the opera- tor and others. The warnings and safety instruc- tions in this manual must be followed to provide reasonable safety and efficiency in using the unit.
  • Page 3 S Keep others away when making carburetor adjustments. S Use only recommended Weed Eater ac- cessories and replacement parts. S Have all maintenance and service not ex- plained in this manual performed by your Au- thorized Service Dealer.
  • Page 4 ASSEMBLY CARTON CONTENTS Check carton contents for the following: Brushcutter tube mounting screws (2) tube mounting nuts (2) control handle mounting screw (1) blade shield screws (4) handlebar screws (2) cupped washer (1) large nut for installing blade (1) long hex key wrench (1) short hex key wrench (1) bracket cover shield for use with blades...
  • Page 5 ATTACHING THE CONTROL HANDLE TO THE HANDLEBAR NOTE: Make sure the wire going to the con- trol handle is routed below the tube and re- mains on the right side of the handlebar and the tube. Screw Screw Hole S Slide handle onto the right side of the han- dlebar and align the screw hole.
  • Page 6 Do not use any blades, or fastening hardware other than the washers and nuts illustrated in the following illustrations. These parts must be provided by Weed Eater, and installed as shown below. Failure to use proper parts can cause the blade to fly off and seriously hurt you or others.

  • Page 7: Starting Your Engine

    Gasoline must be mixed with a good quality 2-cycle air-cooled engine oil designed to be mixed at a ratio of 40:1. Poulan/Weed Eater brand oil is recommended. (A 40:1 ratio is ob- tained by mixing 3.2 ounces of oil with 1 gallon of unleaded gasoline).

  • Page 8: Starting A Warm Engine

    S Slowly press the primer bulb 6 times. S Move choke lever to FULL CHOKE posi- tion. Choke Starter Handle Primer Bulb Muffler S Activate the throttle lock. Keep throttle trigger in the starting position until engine runs smoothly. S Pull starter rope handle sharply 6 times. S Move choke lever to HALF CHOKE posi- tion.

  • Page 9: Replacing The Line

    S WHAT CAUSES BLADE THRUST Blade Thrust can occur when the spinning blade contacts an object that it does not cut. This contact causes the blade to stop for an instant and then suddenly move or “thrust” away from the object that was hit. The “thrusting” re- action can be violent enough to cause the op- erator to be propelled in any direction and lose control of the unit.

  • Page 10: Need Assistance

    SERVICE We recommend all service and adjustments not listed in this manual be performed by an Authorized Service Dealer. CARBURETOR ADJUSTMENT Your carburetor is equipped with limiter caps. Damage will occur if you turn the needles be- yond the limiter caps. Carburetor adjustment is a complicated task.

  • Page 11: Limited Warranty

    POULAN/WEED EATER must warrant the emission control system on your lawn and garden equipment engine for the periods of time listed below provided there...

  • Page 12: Warranty

    OR REPLACEMENT OF PARTS. Repair or replacement of any warranted part will be performed at no charge to the owner at an approved POULAN/WEED EATER servicing center. If you have any questions regarding your warranty rights and responsibilities, you should contact your nearest authorized...
