Summary of Contents for Weed Eater 532 43 46-60
- Page 1 OWNER’S MANUAL Model Number G26LRV Product No. 960 73 00-27 26 Inch Mower Grass Catcher • Assembly • Operation • Customer Responsibilities • Repair Parts 532 43 46-60 Rev. 5 09.22.10 CL Printed in the U.S.A.
-
Page 2: Safety Rules
DANGER: THIS CUTTING MACHINE IS CA PA BLE OF AMPUTATING HANDS AND FEET AND THROWING OBJECTS. FAILURE TO OBSERVE THE FOL LOW ING SAFETY INSTRUCTIONS COULD RESULT IN SERIOUS INJURY OR DEATH. WARNING: In order to prevent ac ci den tal starting when setting up, trans port ing, ad just ing or making repairs, always dis con nect spark plug wire and place... -
Page 3: Table Of Contents
• Do not mow near drop-offs, ditches, or embankments. The machine could suddenly roll over if a wheel is over the edge or if the edge caves in. III. CHILDREN Tragic accidents can occur if the operator is not alert to the presence of children. -
Page 4: Carton Contents
KNOW YOUR GRASS CATCHER READ THIS OWNER'S MANUAL AND SAFETY RULES BEFORE ASSEMBLING OR OPERATING YOUR GRASS CATCH ER. Compare the illustrations with the carton contents to familiarize yourself with the parts before starting the assembly. Study the operating instructions and safety precautions thoroughly to insure proper functioning of your Grass Catcher and to prevent injury to yourself and others. -
Page 5: Assembly
REAR DRAWBAR (See Fig. 1A, 1B) 1. Remove existing drawbar by removing four screws. Insert flat screwdriver to remove bumper from engine plate. Lift up and pull rearward. DRAWBAR ENGINE PLATE Fig. 1A 2. Install new drawbar by replacing screws removed in step 1. - Page 6 MOUNTING COVER ASSEMBLY TO SUPPORT ASSEMBLY (See Fig. 3) NOTE: For ease of assembly, you may wish to obtain the as sis tance of another person for mounting cover assembly to riding mower. 1. Lift and rotate cover to align cover bracket with support assembly.
- Page 7 INSTALL DEFLECTOR GUARD (See Fig. 5) 1. Using the deflector guard as a template, hold deflector guard on the top of the deflector aligning edge with the holes with bottom of writing and angled end with the rear of the deflector as pictured. 2.
-
Page 8: Blade Removal/Replacement
UPPER CHUTE (See Fig. 7A and 7B) 1. Lower mower to its lowest cutting position. 2. Assemble upper chute by inserting curved end into hole in back of cover. TIP: Holding upper chute as shown and twisting while ins- talling in cover will help keep the rubber seal in place. NOTE: Handle carefully so as not to damage full bag in di ca tor. - Page 9 LEVEL MOWER DECK Ensure deck is properly leveled for best mower per for mance. See your riding mower owner's manual for instructions. COUNTERWEIGHT (See Fig. 9) 1. Lower mower to lowest position to allow access to front axle. 2. Turn steering wheel all the way to the right, for access to left side of axle 3.
-
Page 10: Operation
TIPS FOR IMPROVED BAGGING OPE RA TION: Follow the mower operation instructions in your riding mower owner's manual. When operating your grass catcher on a lawn where grass and leaf bagging equipment has not been used, you are picking up thatch and debris that has accumulated for long periods of time. -
Page 11: Customer Responsibilities
CUSTOMER RESPONSIBILITIES GENERAL RECOMMENDATIONS Always observe safety rules when performing any main- te nance. • Before each use check for loose fasteners. • Clean unit thoroughly after each use. BLADE CARE For best results, mower blade must be kept sharp. Re place bent or damaged blade. -
Page 12: Repair Parts
532 43 24-61 Counterweight 819 11 12-16 Washer 810 04 05-00 Lock Washer 874 78 05-16 Bolt 532 43 63-33 Deflector Guard 871 19 10-08 Screw, #10-24 x 1/2 532 43 46-60 Owner's Manual, English/French 532 43 46-61 Owner's Manual, Spanish...
