- Page 1 OWNER'S MANUAL MODEL NO. 259723 13 HP 38 INCH LAWN TRACTOR For Parts and Service, contact our authorized distributor: call 1-800-849-1297 For Technical Assistance: call 1-800-829-5886 ® 173487 1.8.00 RD ® PRINTED IN U.S.A.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Safety Rules ... 2 Service and Adjustments ... 20 Product Specifications ... 5 Storage ... 25 Assembly ... 7 Troubleshooting ... 26 Operation ... 10 Repair Parts ... 30 Maintenance Schedule ... 16 Warranty ... 46 Maintenance ... 16 SAFETY RULES •... -
Page 3: Limited Warranty
LIMITED WARRANTY The Manufacturer warrants to the original consumer purchaser that this product as manufactured is free from defects in materials and workmanship. For a period of two (2) years from date of purchase by the original consumer pur- chaser, we will repair or replace, at our option, without charge for parts or labor incurred in replacing parts, any part which we find to be defective due to materials or workmanship. -
Page 4: Mower Deck
SAFETY RULES • Be sure the area is clear of other • Watch for holes, ruts, or bumps. people before mowing. Stop machine Uneven terrain could overturn the if anyone enters the area. machine. Tall grass can hide obsta- • Never carry passengers or children cles. -
Page 5: Customer Responsibilities
TRACTOR -- MODEL NUMBER 259723 MOWER DECK 153 154 PRODUCT SPECIFICATIONS GASOLINE CAPACITY AND TYPE: OIL TYPE (API-SF/SG/SH): SAE 5W-30 OIL CAPACITY: SPARK PLUG: (GAP: .030”) VALVE CLEARANCE: GROUND SPEEDFORWARD: (MPH): TIRE PRESSURE: CHARGING SYSTEM: BATTERY: BLADE BOLT TORQUE: CONGRATULATIONS on your purchase of a New Tractor. -
Page 6: Unassembled Parts
UNASSEMBLED PARTS Steering Wheel (1) Hex Bolt 3/8-16 x 1 Steering Wheel Insert (1) Locknut 5/16-18 (1) Hex Bolt 5/16-18 x 1-1/4 Steering Wheel Adapter Seat (1) Washer 17/32 x 1-3/16 x 12 Gauge (1) Lock Washer 1/2 (1) Hex Bolt 1/2-13 x 1 Keys (2) Keys LIFT ASSEMBLY... -
Page 7: Install Steering Wheel
TRACTOR -- MODEL NUMBER 259723 LIFT ASSEMBLY Your new tractor has been assembled at the factory with exception of those parts left unassembled for shipping purposes. To ensure safe and proper operation of your tractor all parts and hardware you assemble must be tightened securely. Use the correct tools as necessary to insure proper tightness. -
Page 8: Install Seat
4900J Decal Clutch/brake English 136832 Decal Mower Drive Schem 38 163128 Decal Mower Enviro 162392 Decal Grille Logo 138311 Decal Lift Handle 173487 Manual Owners English 173488 Manual Owners Spanish PART DESCRIPTION 59192 Cap Value Tire 65139 Stem Value 106222X... -
Page 9: Product Specifications
TRACTOR -- MODEL NUMBER 259723 SEAT ASSEMBLY PART DESCRIPTION 127426X Seat 140551 Bracket Pvt St 71110616 Bolt Fin Hex 3/8-16unc X 1 19131610 Washer Flat 13/32 X 1X10 Ga 145006 Clip Push-In Hinged 73800600 Nut Crownlock 3/8-16 UNC 124181X Spring Seat Cprsn 2 250 Blk 17000616 Screw 3/8-16 X 1-1/2 19131614... -
Page 10: Operation
OPERATION These symbols may appear on your tractor or in literature supplied with the product. Learn and understand their meaning. BATTERY CAUTION OR REVERSE FORWARD WARNING LIGHTS ON ENGINE ON ENGINE OFF OIL PRESSURE PARKING BRAKE FUEL CHOKE MOWER HEIGHT LOCKED ATTACHMENT REVERSE... -
Page 11: Optional Equipment
TRACTOR -- MODEL NUMBER 259723 ENGINE OPTIONAL EQUIPMENT Spark Arrester KNOW YOUR TRACTOR READ THIS OWNER'S MANUAL AND SAFETY RULES BEFORE OPERATING YOUR TRACTOR Compare the illustrations with your tractor to familiarize yourself with the locations of various controls and adjustments. Save this manual for future reference. Clutch/Brake Pedal ATTACHMENT CLUTCH LEVER - Used... -
Page 12: To Use Throttle Control
The operation of any tractor can result in foreign objects thrown into the eyes, which can result in severe eye damage. Always wear safety glasses or eye shields while operating your tractor or performing any adjustments or repairs. We recommend a wide vision safety mask over spectacles or standard safety glasses. - Page 13 TRACTOR -- MODEL NUMBER 259723 STEERING TO ADJUST MOWER CUTTING HEIGHT The position of the attachment lift lever determines the cutting height. • Grasp lift lever. • Press plunger with thumb and move lever to desired position. The cutting height range is approxi- mately 1-1/2 to 4".
-
Page 14: Add Gasoline
BEFORE STARTING THE ENIGNE TO START ENGINE CHECK ENGINE OIL LEVEL When starting the engine for the first time or if the engine has run out of fuel, it will • The engine in your tractor has been take extra cranking time to move fuel shipped, from the factory, already filled from the tank to the engine. -
Page 15: Mowing Tips
TRACTOR -- MODEL NUMBER 259723 GROUND DRIVE MOWING TIPS • Tire chains cannot be used when the • Mower should be properly leveled for • The left hand side of mower should be • Drive so that clippings are discharged •... -
Page 16: Maintenance Schedule
MAINTENANCE MAINTENANCE SCHEDULE FILL IN DATES AS YOU COMPLETE REGULAR SERVICE Check Brake Operation Check Tire Pressure Check Operator Presence and Interlock Systems Check for Loose Fasteners Sharpen/Replace Mower Blades Lubrication Chart Check Battery Level Clean Battery and Terminals Check Transaxle Cooling Adjust Blade Belt(s) Tension Adjust Motion Drive Belt(s) Tension Check Engine Oil Level... - Page 17 TRACTOR -- MODEL NUMBER 259723 CHASSIS AND ENCLOSURES TRACTOR Always observe safety rules when performing any maintenance. BRAKE OPERATION If tractor requires more than six (6) feet stopping distance at high speed in highest gear, then brake must be adjusted. (See “TO ADJUST BRAKE” in the Service and Adjustments section of this manual).
-
Page 18: Engine Lubrication
BATTERY NOTE: Although multi-viscosity oils (5W30, 10W30 etc.) improve starting in Your tractor has a battery charging cold weather, these multi-viscosity oils system which is sufficient for normal use. will result in increased oil consumption However, periodic charging of the battery when used above 32°F. -
Page 19: Repair Parts
REPAIR PARTS TRACTOR -- MODEL NUMBER 259723 ELECTRICAL ENGINE COOLING FINS Remove any dust, dirt or oil from engine cooling fins to prevent engine damage from overheating. See engine manual. AIR FILTER Your engine will not run properly using a dirty air filter. -
Page 20: Service And Adjustments
CLEANING We do not recommend using a garden • Clean engine, battery, seat, finish, etc. hose to clean your tractor unless the of all foreign matter. electrical system, muffler, air filter and • Keep finished surfaces and wheels carburetor are covered to keep water out. free of all gasoline, oil, etc. -
Page 21: Troubleshooting Chart
TROUBLESHOOTING CHART PROBLEM CAUSE Mower blades will not • Frozen idler pulley. rotate (Cont’n) • Frozen blade mandrel. Poor grass discharge • Engine speed too slow. position. • Travel speed too fast. • Wet grass. mowing. • Mower deck not level. •... - Page 22 TO REPLACE MOWER BLADE DRIVE BELT The mower blade drive belt may be replaced without tools. Park the tractor on level surface. Engage parking brake. BELT REMOVAL - • Remove mower from tractor (See “TO REMOVE MOWER” in this section of this manual).
- Page 23 TROUBLESHOOTING CHART PROBLEM CAUSE Will not start • Out of fuel. • Engine not “CHOKED” properly. • Engine flooded. before attempting to start. • Bad spark plug. • Dirty air filter. • Dirty fuel filter. • Water in fuel. • Loose or damaged wiring.
-
Page 24: Repair Parts
ENGINE Seat Pan TO ADJUST THROTTLE CONTROL CABLE Battery The throttle control has been preset at Box Door the factory and adjustment should not be necessary. Check adjustment as de- scribed below before loosening cable. If adjustment is necessary, proceed as follows: •...
