Weed Eater 545137217 Instruction Manual

Weed Eater 545137217 Instruction Manual

Weed eater blower instruction manual
Hide thumbs
Table of Contents

Advertisement

Quick Links

Please do not return unit to retailer.
Por favor, no devuelva el aparato al lugar de compra.
Veuillez ne pas retourner l'outil au détaillant.
1- -800- -554- -6723
www.weedeater.com
Manual de Instrucciones
IMPORTANT MANUAL - - Do not throw away
MANUAL IMPORTANTE - - No lo descarte
MANUEL IMPORTANT - - À Conserver
WARNING:
Read and follow all Safety Rules and Operating Instructions before
using this product. Failure to do so can result in serious injury.
ADVERTENCIA:
Lea el manual de instrucciones y siga todas las advertencias e
instrucciones de seguridad. El no hacerlo puede resultar en lesiones
graves.
AVERTISSEMENT:
Veuillez lire le manuel d'instructions et bien respecter tous les
avertissements et toutes les instructions de sécurité. Tout défaut
de le faire pourrait entraîner des blessures graves.
WEED EATER
1030 Stevens Creek Road
Augusta, GA 30907
R
Instruction Manual
Manuel d'Instructions
BV200 / BV1650 / BV1800
BV1850 / BV2000
545137217
Trademark
LE Series
11/30/06

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 545137217 and is the answer not in the manual?

Questions and answers

Related Manuals for Weed Eater 545137217

Summary of Contents for Weed Eater 545137217

  • Page 1 AVERTISSEMENT: Veuillez lire le manuel d’instructions et bien respecter tous les avertissements et toutes les instructions de sécurité. Tout défaut de le faire pourrait entraîner des blessures graves. WEED EATER 1030 Stevens Creek Road Augusta, GA 30907 Trademark Instruction Manual...

  • Page 2: Identification Of Safety Symbols

    IDENTIFICATION OF SAFETY SYMBOLS WARNING: This unit can be dangerous! Careless or improper use can cause serious injury. Read your operator’s manual carefully until you completely understand and can follow all warnings and safety rules before operating the unit. Failure to do so can result in serious injury. Save operator’s manual. WARNING: The muffler is very hot during and after use.

  • Page 3: Know Your Unit

    IDENTIFICATION OF SAFETY SYMBOLS WARNING: Stop the engine before opening the vacuum inlet door. The engine must be stopped and the impeller blades no longer turning to avoid serious injury from the rotating blades. Gently tilt the handle of the screwdriver toward the back of the unit to release the latch while pulling up on the vacuum inlet cover with your other hand.

  • Page 4: Special Notice

    Disconnect spark plug before performing maintenance except for carburetor adjust- ments. Use only recommended WEED EATER re- placement parts; use of any other parts may void your warranty and cause damage to your unit. Empty fuel tank before storing the unit. Use up fuel left in carburetor by starting engine and letting it run until it stops.
  • Page 5 ASSEMBLY WARNING: Stop engine and be sure the impeller blades have stopped turning be- fore opening the vacuum inlet door or at- tempting to insert or remove the vacuum or blower tubes. The rotating blades can cause serious injury. Always disconnect the spark plug before performing maintenance or ac- cessing movable parts.

  • Page 6: Shoulder Strap Adjustment

    on the retaining posts of the unit. 6. Pivot the tube until it is secured to the blower unit by the vacuum inlet latch. PIVOT Inlet Cover Latch Retaining Hook Post HOW TO CONVERT UNIT FROM VACUUM USE TO BLOWER USE 1.

  • Page 7: Operation

    OPERATION KNOW YOUR BLOWER READ THIS INSTRUCTION MANUAL AND SAFETY RULES BEFORE OPERATING YOUR UNIT. Compare the illustrations with your unit to familiarize yourself with the location of the various controls and adjustments. Save this manual for future reference. Lower Vacuum Tube Vacuum Bag Spark Plug...
  • Page 8 2-cycle air-cooled engine oil designed to be mixed at a ratio of 40:1. Poulan/WEED EATER brand synthetic oil is recommended. Mix gasoline and oil at a ratio of 40:1. A 40:1 ratio is obtained by mixing 3.2 ounces (95 ml) of oil with 1 gallon (4...

  • Page 9: Maintenance

    If any dealer other than an authorized service dealer performs work on the product, WEED EATER may not pay for repairs under warranty. It is your re- sponsibility to maintain and perform general maintenance.

  • Page 10: Carburetor Adjustments

    Air Filter Cover Screws Air Filter Cleaning the air filter: A dirty air filter decreases engine perform- ance and increases fuel consumption and harmful emissions. Always clean or replace air filter after every 5 hours of operation or yearly, whichever comes first. 1.
  • Page 11 Under FUELING ENGINE in the OPERA- TION section of this manual, see message la- beled IMPORTANT regarding the use of ga- sohol in your engine. Fuel stabilizer is an acceptable alternative in minimizing the formation of fuel gum deposits during storage. Add stabilizer to gasoline in fuel tank or fuel storage container.

  • Page 12: Limited Warranty

    (California only). Where a warrantable condition exists, WEED EATER will repair your small off- - road engine engine at no cost to you. Expenses covered under warranty include diagnosis, parts and labor.
  • Page 13 MODIFIED PARTS: The use of add- -on or mo- dified parts can be grounds for disallowing a warranty claim. WEED EATER is not liable to cover failures of warranted parts caused by the use of add- -on or modified parts.

This manual is also suitable for:

Bv200Bv1650Bv1800Bv1850Bv2000Le series
