LOCATING YOUR GRILL
When determining a suitable location for your Summit
to wind, proximity to traffic paths, and keeping any gas supply lines as short as possible. Never locate the Summit
grill in a garage, breezeway, shed, under an unprotected overhang, or other enclosed area. Locate the grill and structure
so there is enough room to safely evacuate the area in case of a fire.
CLEARANCE FROM SURFACES OR STRUCTURES
WARNING: Clearance from any surface or structure
is 24 inches from the back and sides of the grill. Refer
to "Typical Gas Supply Installation" before starting
installation.
WARNING: The structure, "island", countertops, and
adjacent work areas for the built-in grill installation
must be built from non-combustable materials only.
NOTE: If you have questions on what materials are
considered non-combustable, contact you local
building materials supplier or fire department.
BUILT-IN STRUCTURE CUTOUT DIMENSIONS
ALL DIMENSIONS ARE TO FINISHED SURFACES.
SILVER A - SILVER D - GOLD D
BUILT - IN GAS GRILL DIMENSIONS
THIS GAS APPLIANCE IS DESIGNED FOR
OUTDOOR USE ONLY.
®
®
gas grill installation, give attention to concerns such as exposure
Note: For a counter t op treatment: Recommended 3/4 inc
overhang. Notc h front edg e for f r ame to full y slide in.
WARNING: ALL COUNTERTOP FINISHED SURFACES
MUST BE CONSTRUCTED OF A NONCOMBUSTIBLE
MATERIAL.
Built-In Cutout Dimensions
27" Grill
A
30
1 /
"
4
B
34
1 /
"
4
C
21"
24 inches Any Surface
27 inches min. for lid clearance
Grill Frame
h
39" Grill
Tolerances
38
1 /
"
+
1 /
4
34
1 /
"
+
1 /
4
21"
+
1 /
gas
®
" -
1 /
"
4
4
" -
1 /
"
4
4
" -
1 /
"
4
4
