Weber SUMMIT 650 Operating Manual

Lp gas barbecues
Hide thumbs Also See for SUMMIT 650:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Instruction Manual
DANGER
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flames.
3. Open lid.
4. If odor continues, keep away from the
appliance and immediately call your gas
supplier or your fire service. Leaking gas
may cause a fire or explosion which can
cause serious bodily injury or death, or
damage to property.
WARNING:
1. Do not store or use petrol or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
2. A gas supply cylinder not connected for
use should not be stored in the vicinity
of this or any other appliance.
SUMMIT
INFORMATION FOR THE INSTALLER:
This manual must remain with the owner,
who should keep it for future use.
OUTDOOR USE ONLY.
450 & 650
TM
LP Gas Barbecues
Operating Guide
Read before assembly
WARNING: Follow all leak-check
procedures carefully in this manual prior
to barbecue operation. Do this even if
barbecue was dealer assembled.
WARNING: Do not try to light the Weber
Gas Barbecue without first reading the
"Lighting" instructions in this manual.
72626
01/24/02

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SUMMIT 650 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Weber SUMMIT 650

Summary of Contents for Weber SUMMIT 650

  • Page 1 Do this even if barbecue was dealer assembled. WARNING: Do not try to light the Weber Gas Barbecue without first reading the “Lighting” instructions in this manual. INFORMATION FOR THE INSTALLER: This manual must remain with the owner, who should keep it for future use.

  • Page 2: Warnings

    Improper assembly may be dangerous. Please carefully follow the assembly instructions in this manual. After a period of storage, and/or non-use, the Weber Gas Barbecue should be checked for gas leaks and burner obstructions before use. See instructions in this manual for correct procedures.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS Warnings Warranty A Word of Thanks General Instructions Operating Area Storage *REFER TO YOUR STEP-BY-STEP SECTION AT THIS TIME Lighting Crossover Ignition System To Extinguish Manual Lighting To Extinguish Cooking Storage Cleaning Steam-N-Chips Smoker Refilling The Liquid Propane Cylinder Important LP Cylinder Information Connect Then Filled Liquid Propane Cylinder...

  • Page 4: Warranty

    Weber does not authorize any person or company to assume for it any other obligation or liability in connection with the sale, installation, use, removal, return, or replacement of its equipment; and no such representations are binding on Weber.

  • Page 5: General Instructions

    ® Bars produce that “outdoor” flavor in the food. The Weber Gas Barbecue is portable so you can easily change its location in your yard or on your patio. Portability means you can take your Weber Gas Barbecue with, if you move.

  • Page 6: Lighting

    If the hose is found to be damaged in any way, do not use the barbecue. Replace using only Weber authorized replacement hose. Contact the Customer Service Representative in your region using the contact information sheet provided with your manual.

  • Page 7: To Extinguish

    2) Make sure all burner control knobs are turned OFF. (Push each burner control knob down and turn clockwise.) WARNING: The storage space under the cooking module is intended for storage of nonflammable items only. Summit 450 Summit 650 Manual Lighting Manual Lighting...

  • Page 8: To Extinguish

    3) Turn the tank on by turning the tank valve counterclockwise. 4) Select heat zone. 5) Put a match in the match holder and strike the match. 6) Insert match holder and lit match through matchlight hole to ignite LEFT burner. WARNING: Do not lean over open barbecue.

  • Page 9: Cooking

    • The gas must be turned off at the LP cylinder when the Weber Gas Barbecue is not in use. • When the Weber Gas Barbecue is stored indoors, the gas supply must be DISCONNECTED and the LP cylinder stored outdoors in a well-ventilated space.

  • Page 10: Using The Steam-N-Chips Smoker

    Steam-N-Chips Smoker. To a lesser degree a "smoke" residue will accumulate on the inside of your Weber Gas Barbecue. This residue need not be removed and will not adversely affect the function of your Weber Gas Barbecue.

  • Page 11: Refilling The Liquid Propane Cylinder

    NEVER store a spare LP Cylinder under or near this barbecue. NEVER fill the tank beyond 80% full. Your Weber gas grill is equipped with a cylinder supply system designed for vapor withdrawal. WARNING: Only use this grill outdoors in a well- ventilated area.

  • Page 12: Liquid Propane Cylinder

    This vent should be free of dirt, grease, bugs etc. • The LP cylinder and connections supplied with your Weber Gas Barbecue have been designed and tested to meet government, American Gas Association, and Underwriters Laboratories requirements.

  • Page 13: Liquid Propane Cylinder Requirements

    Liquid Propane Cylinder requirements • Replacement LP cylinders supplied by Weber satisfy the above requirements. Check to be sure other cylinders have a D.O.T. certification(1), and date tested(2) is within five years. Your LP gas supplier can do this for you.

  • Page 14: Main Burner Flame Pattern

    CAUTION: Do not enlarge the burner ports when cleaning. Replacing Main Burners 1. Your Weber Gas Barbecue must be OFF and cool. 2. Turn OFF gas at source. 3. Disconnect regulator. 4. To remove control panel refer to “Remove the control panel and the front panel”...
  • Page 15 9. Pull the manifold(1) out of the burners. 10. Slide the burner assembly from each Heat Zone. The left and right burners are connected by the Crossover tube. Pull out of here Crossover tube Figure 13 Summit 450 Summit 650...

  • Page 16: General Maintenance

    GENERAL MAINTENANCE 11. Lift and twist the burner assembly slightly to separate the crossover tube(1) from the burners. Remove the burners from the cooking box. Separate here 12. To reinstall the burners, reverse steps 3 through 11. CAUTION: The burner openings must be positioned properly over the valve orifices.

  • Page 17: Troubleshooting

    WARNING: The spare or disconnected LP cylinder must be stored outdoors in a well ventilated area out of the reach of children. The spare or disconnected LP cylinder must never be stored under or near your Weber Gas Barbecue.

  • Page 18: Patents And Trademarks

    ©2000 Weber-Stephen Products Co., 200 East Danels Road, Palatine, IL 60067-6266.U.S.A. Printed in the U.S.A.

This manual is also suitable for:

Summit 450Summit 450 lpSummit 650 lpSummit 450
