Weber Summit S-640 Owner's Manual

Built-in lp gas grill
Hide thumbs Also See for Summit S-640:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Installation Manual
GAS GRILL
Built-In LP Gas Grill Owner' s Guide
S-640
YOU MUST READ THIS OWNER'S GUIDE
BEFORE OPERATING YOUR GAS GRILL
DANGER
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open fl ames.
3. Open lid.
4. If odor continues, keep away from the
appliance and immediately call your gas
supplier or your fi re department.
Leaking gas may cause a fi re or explosion
which can cause serious bodily injury or
death, or damage to property.
WARNING:
1. Do not store or use gasoline or other
fl ammable liquids or vapors in the
vicinity of this or any other appliance.
2. An LP cylinder not connected for use
shall not be stored in the vicinity of this
or any other appliance.
#43154
#00000
WARNING: Follow all leak-check
procedures carefully in this manual prior
to barbecue operation. Do this even if the
barbecue was dealer-assembled.
NOTICE TO INSTALLER: These instructions
must be left with the owner and the owner
should keep them for future use.
THIS GAS APPLIANCE IS DESIGNED FOR
OUTDOOR USE ONLY.
WARNING: Do not try to light this
appliance without reading the "Lighting
Instructions" section of this manual.
43154 US 05/02/07
LP
US ENGLISH

Advertisement

Table of Contents
loading

Related Manuals for Weber Summit S-640

Summary of Contents for Weber Summit S-640

  • Page 1 GAS GRILL Built-In LP Gas Grill Owner’ s Guide S-640 YOU MUST READ THIS OWNER’S GUIDE BEFORE OPERATING YOUR GAS GRILL DANGER If you smell gas: 1. Shut off gas to the appliance. 2. Extinguish any open fl ames. 3. Open lid.

  • Page 2: Dangers And Warnings

    Do not use a fl ame to check for gas leaks. Combustible materials should never be within 24 inches (61 cm) of the back or sides of your Weber Do not put a barbecue cover or anything fl ammable on, or in the storage area under the barbecue.

  • Page 3: Warranty

    Weber does not authorize any person or company to assume for it any other obligation or liability in connection with the sale, installation, use, removal, return, or replacement of its equipment; and no such representations are binding on Weber.
  • Page 4 EXPLODED VIEW S-640 S640_LP_US WWW.WEBER.COM ®...
  • Page 5 Control Panel Small Knob Bezel Small Knob Large Knob Large Knob Bezel Water Baffl e / Heat Shield WWW.WEBER.COM ® EXPLODED VIEW LIST S-640 Disposable Drip Pan Drip Tray Catch Pan Catch Pan Holder Left Rear Panel Left Panel Left Door...
  • Page 6 STORAGE AND/OR NONUSE • The gas must be turned off at the liquid propane cylinder when the Weber barbecue is not in use. • LP cylinder must be stored outdoors in a well-ventilated area out of reach of children.

  • Page 7: General Instructions

    DANGER NEVER store a spare LP Cylinder under or near this barbecue. NEVER fi ll the tank beyond 80% full. Your Weber ® gas grill is equipped for a cylinder supply system designed for vapor withdrawal. WARNING: Only use this grill outdoors in a well-ventilated area.

  • Page 8: Gas Instructions

    One series of tanks mount with the valve facing front (a). The other tanks mount with the valve facing away from the fuel scale (b). Weber recommends the use of cylinder manufacturer’s Manchester and Worthington, with a 47.6 lb water capacity.

  • Page 9: Check For Gas Leaks

    Note: All factory-made connections have been thoroughly checked for gas leaks. The burners have been fl ame-tested. As a safety precaution however, you should recheck ® all fi ttings for leaks before using your Weber Gas Barbecue. Shipping and handling may loosen or damage a gas fi tting.

  • Page 10: Reinstall Control Panel

    DO NOT OPERATE THE GRILL. Contact the Customer Service Representative in your area using the contact information on our web site. Log onto www.weber.com When leak checks are complete, turn gas supply off at the source and rinse connections with water.

  • Page 11: Refilling The Liquid Propane Cylinder

    Be sure the regulator is mounted with the small vent hole pointed downward so that it will not collect water. This vent should be free of dirt, grease, bugs etc. • The gas connections supplied with your Weber and tested to meet 100% CSA and ANSI requirements. WWW.WEBER.COM ®...
  • Page 12 Because of the special design of the Flavorizer directed through the funnel-shaped bottom tray into the grease catch pan. START/ MED. ® bars, ® bars and the fl exible temperature controls, ® bars and burners, excess fats are WWW.WEBER.COM ®...

  • Page 13: Grilling Tips & Helpful Hints

    WARNING: If the burner still does not light, turn the burner control knob to “OFF” and wait 5 minutes to let the gas clear before you try again or try to light with a match. WWW.WEBER.COM ® GAS INSTRUCTIONS • Trim excess fat from steaks, chops and roasts, leaving no more than a scant ¼ inch (6.4mm) of fat.
  • Page 14 Weber authorized replacement hose. Contact the Customer Service Representative in your area using the contact information on our web site. Log onto www.weber. ® Open the lid. Make sure all burner control knobs are turned off. (Push control knob in and turn clockwise to ensure that it is in the “OFF”...

  • Page 15: Using The Smoker

    DANGER Do not use any fl ammable fl uid in the smoker to ignite the wood. This will cause serious bodily injury. WWW.WEBER.COM ® OPERATING INSTRUCTIONS * The grill illustrated may have slight differences than the model purchased.
  • Page 16 ® authorized replacement hose. Contact the Customer Service Representative in your area using the contact information on our web site. Log onto www.weber.com 1) Open the grill lid. 2) Open smoker box lid. 3) Fill smoker with water soaked wood chunks or chips.

  • Page 17: Manually Lighting The Smoker Burner

    WARNING: Check hose before each use of grill for nicks, cracking, abrasions or cuts. If the hose is found to be damaged in any way, do not use the grill. Replace using only Weber authorized replacement hose. Contact the Customer Service Representative in your area using the contact information on our web site.

  • Page 18: Using The Rotisserie

    Indirect Method without using the rotisserie. • Smoker can be used in conjunction with rotisserie for more smoke fl avor. Note: When using the rotisserie burner, grill thermometer will not refl ect the temperature inside the cooking box. ® bars. WWW.WEBER.COM ®...

  • Page 19: Lighting Rotisserie Burner

    If the hose is found to be damaged in any way, do not use the grill. Replace using ® only a Weber authorized replacement hose. Contact the Customer Service Representative in your area using the contact information on our web site.

  • Page 20: Manually Lighting The Rotisserie Burner

    Weber authorized replacement hose. Contact the Customer Service Representative in your area using the contact information on our web site. Log onto www.weber. ® Open the lid. Remove the warming rack and the cooking grates from the cookbox.

  • Page 21: Troubleshooting

    OPERATING THE HANDLE LIGHT The Weber Grill Out™ Handle Light has a built-in “Tilt Sensor.” With the power button (a) activated, the light will come on when the grill lid is open. The light will turn off when the lid is closed.

  • Page 22: Rotisserie Troubleshooting

    fl ickering fl ame activated. If problems cannot be corrected by using these methods, please contact the Customer Service Representative in your area using the contact information on our web ® site. Log onto www.weber.com US_Rotis_Trblsht_LP WEBER ®...

  • Page 23: Maintenance

    Remove the two screws that secure the control panel to the frame. Remove the control panel. Tilt panel forward and lift up and away from grill. Completely remove the control panel from the cooking box assembly exposing the valves, burners, igniter, and manifold. WWW.WEBER.COM ® MAINTENANCE...

  • Page 24: Main Burner Flame Pattern

    Insect screens and burners are clean replace the burners. If the Spider/Insect screen becomes damaged or cannot be cleaned, please contact the Customer Service Representative in your area using the contact information on our web site. Log onto www.weber.com ® MAIN BURNER FLAME PATTERN The Weber ®...
  • Page 25 WWW.WEBER.COM ®...
  • Page 26 ©2007 The following trademarks are registered in the name of Weber-Stephen Products Co., an Illinois corporation, located at 200 East Daniels Road, Palatine, Illinois 60067 U.S.A. Australia; Smokey Joe, Weber, Kettle Silhouette , Genesis, Austria;...
  • Page 27 Printemps. Été. Automne. Hiver. Vous recevrez quatre exemplaires GRATUITS de Weber Nation™, notre lettre d’information électronique contenant toutes les actualités sur les grillades. Chaque numéro regorge d’astuces et de conseils pour les grillades, de recettes éprouvées, plus tout ce que vous devez savoir pour devenir un véritable Gourou des grillades Weber. Pour activer votre inscription, il vous suffit de vous connecter sur www.weber.com...
  • Page 28 Knowing more about who buys our grills helps the crew back in R&D come up with new cutting edge Weber products. Please fill in the answers you feel comfortable sharing with us, and pass by any question you prefer to leave blank.
