Y
OU MUST READ THIS
BEFORE OPERATING YOUR GAS GRILL
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flames.
3. Open lid
4. If odor continues, keep away from the
appliance and immediately call your gas
supplier or your fire department.
Leaking gas may cause a fire or explosion
which can cause serious bodily injury or
death, or damage to property.
WARNING
1. Do not store spare liquid propane
cylinder within 10 feet (3m) of this
appliance.
2. Do not store or use gasoline or other
flammable liquids or vapors within 25
feet (8m) of this appliance.
WARNING: Follow all leak-check
procedures carefully in this manual prior to
barbecue operation. Do this even if the
barbecue was dealer-assembled.
NOTICE TO INSTALLER: These instructions
must be left with the owner and the owner
should keep them for future use.
THIS GAS APPLIANCE IS DESIGNED FOR
OUTDOOR USE ONLY.
WARNING: Do not try to light this
appliance without reading the "Lighting"
Instructions section of this manual
S U M M I T
Natural Gas Grill Owners Guide
O
G
WNERS
UIDE
DANGER
®
#
A405_NG.b
Ba401.b
B405_NG.a
C405_NG.a
D405_NG.b
E403.a
&
43721
43721 US 11/12/02
NG

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 43721 and is the answer not in the manual?

Questions and answers

Related Manuals for Weber 43721

Summary of Contents for Weber 43721

  • Page 1 THIS GAS APPLIANCE IS DESIGNED FOR OUTDOOR USE ONLY. WARNING: Do not try to light this appliance without reading the “Lighting” Instructions section of this manual ® Natural Gas Grill Owners Guide WNERS UIDE A405_NG.b Ba401.b B405_NG.a C405_NG.a D405_NG.b E403.a & 43721 43721 US 11/12/02...

  • Page 2: Danger & Warnings

    Should the burners go out while in operation, turn all gas valves off. Open the lid and wait five minutes before attempting to relight, using the lighting instructions. Do not use charcoal or lava rock in your Weber Never lean over open grill or place hands or fingers on the front edge of the cooking box.

  • Page 3: Table Of Contents

    Contents Danger & Warnings ...A-2 Warranty ...A-4 General Instructions ...A-5 Grilling Methods ...A-6 Cleaning ...A-6 Exploded View ...A-7 Parts List ...A-11 Assembly Instructions ...B-a Gas Instructions ...C-1 Leak Checking ...C-4 Operating ...D-1 Grilling Methods ...D-1 Lighting ...D-3 Manual Lighting ...D-4 Lighting the Side Burner ...D-5 Troubleshooting...

  • Page 4: Warranty

    All Remaining Parts, 5 years, when assembled and operated in accordance with the printed instructions accompanying it. Weber may require reasonable proof of your date of purchase. THEREFORE, YOU SHOULD RETAIN YOUR SALES SLIP OR INVOICE. This Limited Warranty shall be limited to the repair or...

  • Page 5: For Installation In Canada

    Portability ® means you can take your Weber gas barbecue with you if you move. The natural gas supply is easy to use and gives you more cooking control than charcoal fuel.

  • Page 6: Grilling Methods

    Grilling Methods NOTE: If grill looses heat while cooking refer to the troubleshooting section of this manual. WARNING: Do not move the Weber when operating or while barbecue is hot. You can adjust the Left and Right burners in each burner set as desired.

  • Page 7: Exploded View

    Summit ® Silver B Exploded View Summit Silver B NG 111202 ®...
  • Page 8 Summit 1. Hinge Pin 2. Thermometer Hardware 3. Thermometer Bezel 4. Warm-Up ™ Basket 5. 12 inch Cooking Grate ® 6. Left Flavorizer Bar Assembly 7. Cookbox Assembly Hardware 8. 1/4 - 20 Hex Nut 9. Electrode Assembly ® 10. Crossover Tube 11.
  • Page 9 Summit ® Gold B Exploded View Summit Gold B NG 111202 ®...
  • Page 10 Summit 1. Hinge Pin 2. Thermometer Hardware 3. Thermometer Bezel ™ 4. Warm-Up Basket 5. 12 inch Cooking Grate ® 6. Left Flavorizer Bar Assembly 7. Cookbox Assembly Hardware 8. 1/4 - 20 inch Hex Nut 9. Electrode Assembly 10. Crossover ®...

  • Page 11: Parts List

    Summit Lid - 1 Cookbox - 1 Front Frame Rail - 1 Rear Frame Rail - 1 Left Frame Assembly - 1 Right Frame Assembly - 1 Rear Panel - 1 ® Silver B Parts List Bottom Shelf - 1 Left Door - 1 Right Door - 1 Side Table - 1...
  • Page 12 Summit ® Flavorizor Bars - 2 Sets Stainless Steel Cooking Grates - 2 Bottom Tray - 1 Catch-Pan Holder - 1 Catch-Pan - 1 Disposable Drip Pans - 2 ® Silver B Parts List Hinge Pin- 2 Hair Pin Cotter- 2 1-1/4 inch Bolts (1/4 x 20 x 1-1/4 inch Bolt) - 2 Nut Hex (1/4 x 20 Blk Zinc) - 2...
  • Page 13 Summit Lid - 1 Cookbox - 1 Front Frame Rail - 1 Rear Frame Rail - 1 Left Frame Assembly - 1 Right Frame Assembly - 1 Rear Panel - 1 ® Gold B Parts List Bottom Shelf - 1 Left Door - 1 Right Door - 1 Side Table - 1...
  • Page 14 Summit ® Flavorizor Bars - 2 Sets Stainless Steel Cooking Grates - 3 Bottom Tray - 1 Catch-Pan Holder - 1 Catch-Pan - 1 Disposable Drip Pans - 2 ® Gold B Parts List Hinge Pin- 2 Hair Pin Cotter- 2 1-1/4 inch Bolts (1/4 x 20 x 1-1/4 inch Bolt) - 2 Nut Hex (1/4 x 20 Blk Zinc) - 2...
  • Page 15 CAUTION: Before proceeding to the next step check that frame rail (2) is on the side with the swing tables (3). The tab on frame rail (2) must be facing toward the wheels. Ba401.b...
  • Page 16 ATTENTION! Only start these bolts. Do not tighten yet.
  • Page 18 ATTENTION! Completely remove both partially started bolts from top rear frame rail ATTENTION! Reinstall both bolts through rear panel and into rear frame rail.
  • Page 19 ATTENTION! Remove packing tape holding the gas line and bracket(1). When installing cookbox route the gas line and bracket(1) inside the frame rails(2).
  • Page 25 NOTE: Igniter Wire(1) is located up under right side of control panel. B405_NG.a...
  • Page 26 CAUTION: Hold burner cap(1) down while pushing side burner ignition wire(2) on.

  • Page 31: Install Gas Supply

    Install Gas Supply General Specifications for Piping Note - Contact your local municipality for building codes regulating outdoor gas barbecue installations. In absence of Local Codes, you must confirm to the latest edition of ANSI Z223.1. WE RECOMMEND THAT THIS INSTALLATION BE DONE BY A PROFESSIONAL. Some of the following are general requirements taken from ANISI Z223.1 latest edition for complete specifications.

  • Page 32: Leak Checking

    Connect Gas Supply a) To connect gas hose at the supply: Slide back the collar of the quick disconnect. Push male fitting of the hose into the quick disconnect, and maintain pressure(1). Slide the collar closed(2). If it does not engage or lock, repeat procedure.
  • Page 33 WARNING : The gas connections of your Summit gas grill have been factory tested. We do however recommend that you leak check all gas connections before operating your Summit Remove control panel Part required: Phillips Screwdriver. Remove the burner control knobs (1). The screws (2) need to be removed from the control panel (3) before the control panel is removed from the grill.
  • Page 34 Note - All factory-made connections have been thoroughly checked for gas leaks. The burners have been flame- tested. As a safety precaution however, you should recheck all fittings for leaks before using your Weber barbecue. Shipping and handling may loosen or damage a gas fitting.
  • Page 35 Check: 1) Quick disconnect hose to grill connection 2) Side burner hose to manifold connection 3) Side burner hose to side burner connection 4) Hose to quick disconnect connection (gas supply) 5) Valve to manifold connection WARNING: If there is a leak at connections(1),(2),(3),(4) or (5) turn OFF the gas.
  • Page 36 Reinstall control panel Parts required: control panel, screws, and burner control knobs. Place the control panel back onto the control panel brackets on either side of the front of the cooking box. Line up screws with screw holes on both the control panel and control panel brackets.

  • Page 37: Operating Instructions

    Grilling Methods NOTE: If grill looses heat while cooking refer to the troubleshooting section of this manual. You can adjust the Left and Right burners in each burner set as desired. The control settings are High (H), Medium (M), Low (L), or Off (O). If burners go out during cooking, turn off all burners and wait 5 minutes before relighting.

  • Page 38: Grilling Tips & Helpful Hints

    Indirect cooking The Indirect Method is similar to roasting, but with the added benefits of that grilled texture, flavor, and appearance you can’t get from an oven. To set up for Indirect cooking, gas burners are lit on either side of the food but not directly beneath it.

  • Page 39: Lighting

    WARNING: Check hose before each use of barbecue for nicks, cracking, abrasions or cuts. If the hose is found to be damaged in any way, do not use the barbecue. Replace using only Weber authorized replacement hose. Contact the Customer Service Representative in your region using the contact information sheet provided with your manual.

  • Page 40: Manual Lighting

    Manual Lighting DANGER Failure to open lid while igniting the barbecue’s burners, or not waiting 5 minutes to allow the gas to clear if the barbecue does not light, may result in an explosive flame-up which can cause serious bodily injury or death.

  • Page 41: Lighting The Side Burner

    Side Burner Lighting Instructions DANGER Failure to open the lid while igniting the side burner, or not waiting 5 minutes to allow the gas to clear if the side burner does not light, may result in an explosive flame-up which can cause serious bodily injury or death.

  • Page 42: Troubleshooting

    If problems cannot be corrected by using these methods, please contact the Customer Service Representative in your region using the contact information sheet provided with your manual. Check Inspect Weber ® Insect/Spider Screens for possible obstructions. (Blockage of holes.)

  • Page 43: Side Burner Troubleshooting

    Side Burner Troubleshooting Problem Side Burner does not light. Flame is low in HIGH position. Push button ignition does not work. Side Burner maintenance WARNING: All gas controls and supply valves should be in the OFF position. Make sure wire is connected between igniter and electrode.

  • Page 44: Main Burner Cleaning Procedure

    Lightly tap the burner to get debris and dirt out of the burner tube. Once the spider/insect screens and burners are clean replace the burners. If the spider/insect screen becomes damaged or cannot be cleaned, call Weber-Stephen Products Customer Service for replacement parts. Main Burner Flame Pattern ®...

  • Page 45: Replacing Main Burners

    Replacing Main Burners ® 1. Your Summit gas grill must be OFF and cool. 2. Turn gas OFF at source. 3. Disconnect regulator. 4. Remove cooking grates. 5. Remove Smoker box. ® 6. Remove Flavorizer bars. 7. To remove control panel refer to “Remove the control panel” under “Check for Gas Leaks.” 8.
  • Page 46 Maintenance 10. Disconnect the flexible manifold from the manifold. 11. Remove screws from the manifold assembly: (a) Locate the screws on both sides of the manifold frame. (b) Remove the screws from manifold frame.
  • Page 47 12. Pull manifold assembly out from the manifold frame. Maintenance 13. Lift and twist the burner assembly slightly, to separate ® the Crossover 14. Remove the Crossover 15. Pull the selected burner(s) tube(s) from manifold frame and replace with a new burner tube. tube (a) from the burners (b).

  • Page 48: Replace Igniter Batteries

    16. To reinstall the manifold assembly, reverse steps 7 through 15. CAUTION: The burner openings (1) must be positioned properly over the valve orifices (2). Check proper assembly before fastening manifold in place. WARNING: After reinstalling the gas lines, they should be leak checked with a soap and water solution before using the grill.
