GAS GRILL
Built-In NG Gas Grill Owner's Guide
S-640 - NG
YOU MUST READ THIS OWNER'S GUIDE
BEFORE OPERATING YOUR GAS GRILL
DANGER
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flames.
3. Open lid.
4. If odor continues, keep away from the
appliance and immediately call your gas
supplier or your fire department.
Leaking gas may cause a fire or explosion
which can cause serious bodily injury or
death, or damage to property.
WARNING:
1. Do not store or use gasoline or other
flammable liquids or vapors in the
vicinity of this or any other appliance.
2. An LP cylinder not connected for use
shall not be stored in the vicinity of this
or any other appliance.
#43157
#00000
WARNING: Follow all leak-check
procedures carefully in this manual prior
to barbecue operation. Do this even if the
barbecue was dealer-assembled.
NOTICE TO INSTALLER: These instructions
must be left with the owner and the owner
should keep them for future use.
THIS GAS APPLIANCE IS DESIGNED FOR
OUTDOOR USE ONLY.
WARNING: Do not try to light this
appliance without reading the "Lighting
Instructions" section of this manual.
43157 US 03/03/08
NG
US ENGLISH

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 43157 and is the answer not in the manual?

Questions and answers

Related Manuals for Weber 43157

Summary of Contents for Weber 43157

  • Page 1 THIS GAS APPLIANCE IS DESIGNED FOR OUTDOOR USE ONLY. WARNING: Do not try to light this appliance without reading the “Lighting Instructions” section of this manual. 43157 US 03/03/08 US ENGLISH...

  • Page 2: Dangers And Warnings

    Do not use a flame to check for gas leaks. Combustible materials should never be within 24 inches (61 cm) of the back or sides of your Weber Do not put a barbecue cover or anything flammable on, or in the storage area under the barbecue.

  • Page 3: Shroud

    Weber does not authorize any person or company to assume for it any other obligation or liability in connection with the sale, installation, use, removal, return, or replacement of its equipment; and no such representations are binding on Weber.
  • Page 4 EXPLODED VIEW S-640 S640_NG_US WWW.WEBER.COM ®...

  • Page 5: Table Of Contents

    Burner Tubes Manifold Control Panel Small Knob Bezel Small Knob Large Knob Large Knob Bezel Water Baffle / Heat Shield WWW.WEBER.COM ® EXPLODED VIEW LIST S-640 Disposable Drip Pan Drip Tray Catch Pan Catch Pan Holder Left Rear Panel Left Panel...

  • Page 6: General Instructions

    Check that the area under the control panel and the bottom tray are free from debris that might obstruct the flow of combustion or ventilation air. STORAGE • The gas must be turned off at the natural gas supply when the Weber barbecue is not in use. • When the Weber ®...

  • Page 7: Thermometer

    All connections and joints must be thoroughly tested for leaks in accordance with local codes and all listed procedures in the latest edition of the National Fuel Gas Code: ANSI Z 223.1/NFPA 54, or CAN/CGA-B149.1 WWW.WEBER.COM ® GAS INSTRUCTIONS Do not use cleaners that contain acid, mineral spirits or xylene. Rinse well after cleaning.

  • Page 8: Type Of Gas

    Your grill operates at 4.5” of water column pressure. If replacement of the hose becomes necessary, factory specified parts are required. See your local dealer. For safety and design reasons, the conversion of a Weber Natural gas to operation using LP gas requires the change out of the entire gas supply system of the grill.
  • Page 9 Note: All factory-made connections have been thoroughly checked for gas leaks. The burners have been flame-tested. As a safety precaution however, you should recheck all ® fittings for leaks before using your Weber gas barbecue. Shipping and handling may loosen or damage a gas fitting.

  • Page 10: Reinstall Control Panel

    If a leak persists after re-tightening the fitting, turn off the gas. DO NOT OPERATE THE GRILL. Contact the Customer Service Representative in your area using the contact information on our web site. Log onto www.weber.com Gas supply to shutoff connection. Valves to manifold connections.
  • Page 11 For longer cooking times, add water to the foil pan to keep drippings from burning. The drippings can be used to make gravies or sauces. WWW.WEBER.COM ® OPERATING INSTRUCTIONS ®...

  • Page 12: Handle

    Do not line the funnel-shaped bottom tray with foil. This could prevent the grease from flowing into the grease catch pan. • Using a timer will help to alert you when “well-done” is about to become “over- done.” WWW.WEBER.COM ®...
  • Page 13 WARNING: Check hose before each use of barbecue for nicks, cracking, abrasions or cuts. If the hose is found to be damaged in any way, do not use the barbecue. Replace using only Weber ® authorized replacement hose. Contact the Customer Service Representative in your area using the contact information on our web site.
  • Page 14 Weber authorized replacement hose. Contact the Customer Service Representative in your area using the contact information on our web site. Log onto www.weber.com Open the grill lid. Open smoker box lid. Fill smoker with water soaked wood chunks or chips.

  • Page 15: Rotisserie Motor

    The rotisserie motor is equipped with a three prong (grounding) power cord for your protection against shock hazard. • The power cord should be plugged directly into a WWW.WEBER.COM ® OPERATING INSTRUCTIONS ® * The grill illustrated may have slight differences than the model purchased.

  • Page 16: Cooking Grates

    WARNING: Check hose before each use of grill for nicks, cracking, abrasions or cuts. If the hose is found to be damaged in any way, do not use the grill. Replace using only a Weber ® authorized replacement hose. Contact the Customer Service Representative in your area using the contact information on our web site.

  • Page 17: Manually Lighting The Rotisserie Burner

    WARNING: Check hose before each use of grill for nicks, cracking, abrasions or cuts. If the hose is found to be damaged in any way, do not use the grill. Replace using only a Weber ® authorized replacement hose. Contact the Customer Service Representative in your area using the contact information on our web site.

  • Page 18: Burner Tubes

    OPERATING THE HANDLE LIGHT The Weber Grill Out™ Handle Light has a built-in “Tilt Sensor.” With the power button (a) activated, the light will come on when the grill lid is open. The light will turn off when the lid is closed.

  • Page 19: Rotisserie Troubleshooting

    If problems cannot be corrected by using these methods, please contact the Customer Service Representative in your area using the contact information on our ® web site. Log onto www.weber.com WEBER ® SPIDER/INSECT SCREENS Your Weber ®...

  • Page 20: Manifold

    Remove the two screws that secure the control panel to the frame. Remove the control panel. Tilt panel forward and lift up and away from grill. Completely remove the control panel from the cooking box assembly exposing the valves, burners, igniter, and manifold. MAINTENANCE WWW.WEBER.COM ®...

  • Page 21: Burner Flame Pattern

    Insect screens and burners are clean replace the burners. If the Spider/Insect screen becomes damaged or cannot be cleaned, please contact the Customer Service Representative in your area using the contact information on our web site. Log onto www.weber.com ® BURNER FLAME PATTERN The Weber ®...
  • Page 22 ©2007 The following trademarks are registered in the name of Weber-Stephen Products Co., an Illinois corporation, located at 200 East Daniels Road, Palatine, Illinois 60067 U.S.A. Australia; Smokey Joe, Weber, Kettle Silhouette , Genesis, Austria; Kettle Silhouette , Smokey Joe, Weber, Benelux; Kettle Silhouette , Smokey Joe, Weber, Compact Grill Configura- tion, Botswana;...
  • Page 23 (If you register online, you do not need to send in this registration card.) Para registrar el producto, llene y envíe por correo este formulario o REGÍSTRESE EN LÍNEA en www.weber.com (Si se registra en linea, no necesita enviar esta tarjeta de registro).
  • Page 24 Knowing more about who buys our grills helps the crew back in R&D come up with new cutting edge Weber products. Please fill in the answers you feel comfortable sharing with us, and pass by any question you prefer to leave blank.
