Wayne 331100-001 Installation Instructions

Installation Instructions
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the product described. Protect
yourself and others by observing all safety information. Failure to comply with instructions could result in personal injury and/or property dam-
age! Retain instructions for future reference.

System Applications

This system pumps waste water up to an existing water drain
and is designed for residential use in:
Laundry trays
Wet bar sinks
Dehumidifiers

System Benefits

Completely assembled
Lightweight
Easily installed
Fully sealed
Compact

Installation and Hook Up

1. Connect pipe leading from system to discharge pipe
(Depending on the installation, a coupling or reducer may
be necessary).
2. Apply soapy water to seal in system lid and insert vent
through seal.
3. Verify pipe is inserted 2 inches into lid opening.
Figure 2 - Installation with Sink or Laundry Tub

Specifications

Sump Pump
Information Basin Size
4/10 HP 10 Gallon w/ sealed lid
UL Listed 17" x 11" x 14"
Fully Automatic
REMINDER: Keep your dated proof of purchase for warranty purposes! Attach it to this manual or file it for safekeeping.
© 2004 Wayne Water Systems
Removal System
Washing machines
Sinks and tubs
Air conditioners
Economical
Corrosion resistant
Installs above floor
Fully automatic
Suds proof
Inlet
1-1/2"
Drain Water
Figure 1 - Pump and Housing
4. Test operational cycle. (To prolong the life expectancy of
this system, flush with tap water every three months.
WARNING
!
handle raw sewage or effluents. Never use this unit in haz-
ardous or explosive locations.
Figure 3 - Installation with Air Conditioner or
Dehumidifier
Discharge Vent
1-1/2" 1-1/2"
This pump is not designed for use in
septic tanks or underground vaults to
Weight Check Valve
28 lbs. Included
331100-001 1/04
SYLT40
