40232 LARGE RECTANGULAR CEILING RACK
ASSEMBLY INSTRUCTIONS
Contents
1 x Wooden Ceiling Rack
4 x Ceiling/Joist Hooks
32 x hanging Links
8 x swivel Hooks
12 x Pan Hooks
Assembly
Remove all packaging and check contents.
Determine where your ceiling joists are located. Screw the large
ceiling/joist hooks directly into the joists at the appropriate points.
Your 40232 rack is supplied with 32 hanging links. The height of your
ceiling rack is dependent on how many links you use.
Hang the required amount of hanging links from the ceiling/joist hooks
and attach the ceiling rack by using the four of the pan hooks, inserted
into the parallel bars of the frame from the bottom upwards, as hanging
points.
Insert pan hooks and swivel from above, only as shown in the attached
image. Only insert Swivel hooks into the outer frame parallel slats.
IMPORTANT:
The maximum permissible load weight of this rack is 20kg / 44lbs.
Always try to evenly distribute the hanging of items; this will helps spread
the load.
The Old Grain Store
Unit 6 Hullockpit Hill
Newnham
Nr Baldock
Hertfordshire SG7 5DP
England
www.hahn-kitchnenware.com
