Summary of Contents for Watlow ULTRAMIC 600
- Page 1 ULTRAMIC ™ DVANCED ERAMIC EATER LTRA FAST ATES ENSITIES CONTAMINATING...
- Page 2 ULTRAMIC 600 heaters are constructed of aluminum nitride (AIN) and incorporate a thermally matched proprietary heating element that provides maximum performance in challenging applications.
-
Page 3: Application Examples
IC. Optimum bonding is achieved by ramping the solder and lead temperature through the eutectic state. Watlow’s ULTRAMIC 600 heater is ideal for this application because a temperature ramp of up to 150°C/second can be achieved while also achieving a fast cool down in preparation for processing the next device. - Page 4 Configurations and Dimensions Maximum Dimensions 4032 mm Length Flat Square Max: 63.5 mm (2.5 in.) Rectangular Max: 100 mm (3.94 in.) Inside Diameter (I.D.) Ring Min: 3 mm (0.118 in.) Flatness Parallelism <0.05 mm (0.002 in.) <0.05 mm (0.002 in.) Voltage Leakage Current 24 to 480V...
- Page 5 Non-contaminating AlN composition ULTRAMIC 600 Thermal and Physical Properties Thermal Properties Thermal Conductivity (W/mK) CTE (ppm/˚C) Surface Temperature 600˚C (1112˚F) Flexural Strength (MPa) Terminal Temperature 400˚C (752˚F)
- Page 6 Mexico, +52 (442) 217-6235 • Shanghai, +86-21-3950-9504 • Singapore, +65-6773-9469 • Spain, +34 91 675 1292 • Sweden, +46 35-27-11-66 • Taiwan, +886-7-288-5168 • United Kingdom, +44 (0) 115-964-0777 How to Order To order your standard ULTRAMIC 600 heater, please specify Watlow code number. If our standard units do not meet your application needs, Watlow can rapidly manufacture the ULTRAMIC 600 to your special requirements.
