VXI TuffSet TuffSet 15 Technical Specifications

Vxi headset technical specifications
Hide thumbs


Advertisement

TuffSet 10
TuffSet 15
VXI Corporation
One Front Street
Headset Technical Specifications
TUFFSET 10 / TUFFSET 20
TRANSMIT SPECIFICATIONS
Microphone: Noise canceling electret
Sensitivity: -50dB @ 1kHz (defined 1" from talk-
side, 82dB SPL)
Current consumption: 300uA max
Operating Voltage: DC 1.0V min. to 20V max.
RECEIVE SPECIFICATIONS
Speaker: Dynamic; 36mm diameter
SPL: 90db @ 1kHz, 0.55V input
Impedance: 300 Ohms
TuffSet 20
Frequency response: 200Hz to 5 kHz
Rated input: 10mW continuous, 100mW peak
MECHANICAL SPECIFICATIONS
Cables: Standard wire, PVC insulation, polyurethane jacket
Connectors: 4 Pin Quick Disconnect
Mic boom: Flexible, with positioning memory; swivels 270°
Mounting: Left or right ear placement
Headband: Stainless steel, adjustable; ratchet positioning
Operating Current: 300uA max.
Operating Voltage: DC 1.0V min. to 20V max.
TUFFSET 37 CONVERTIBLE
TRANSMIT SPECIFICATIONS
Microphone: Noise canceling electret
Impedance: Low. (~300 Ohm)
Sensitivity: -36 dB / Pa. (=16mV)
DC current: 0.5 mAA. (At 3V./2.2 k.Ohm)
RECEIVE SPECIFICATIONS
Impedance: 300 Ohm
Sound Pressure: 96 dB (At 1 k.Hz./ 1mW)
Frequency response: 300 Hz. To 3400 Hz.
TuffSet 37
Sound Pressure Peak Max: 112 dB (Limited by built-in protective circuit)
Convertible
MECHANICAL SPECIFICATIONS
Cables:Thin, high flexible and ultra high strength
4 conductor cable.
Connectors: 4 Pin Quick Disconnect
Flexible microphone boom.
TUFFSET 15 / TUFFSET 25 NOISE ATTENUATING
TRANSMIT SPECIFICATIONS
Microphone - electret noise canceling
Frequency response - 200~10KHz
Impedance: 1.8 k
Sensitivity: -87dB+5dB AT 1KHz 1.5v
Current consumption - 400 Microamp/Max
Operating voltage: 3.0 V
Test voltage - 1.5 volts
RECEIVE SPECIFICATIONS
Type - Magnetic type unit
TuffSet 25
Voice Coil Impedance - 300ohms
Sound Pressure Level - 100dB+/-4dB c1kHz
Impedance (Monaural): 150 Ohms +20% at 1kHz
Impedance (Binaural): 75 Ohms +20% at 1kHz
Frequency response: 100 Hz to 6.3 kHz
Rated Power: 50m
MECHANICAL SPECIFICATIONS
Cables: polyurethane jacket, PVC resin
Connectors: 4-pin quick disconnect
Microphone boom: Highly flexible gooseneck boom
Headband - Covered stainless steel, adjustable
Ear cushion - PVC leather
Weight - (without lower cord) TuffSet 15: 7.2oz TuffSet 25:11 oz
Rollinsford, NH 03869
www.vxicorp.com
800-742-8588
603-742-2888
