- Page 1 LCD COLOUR TV USER'S MANUAL Part No:...
-
Page 2: Table Of Contents
SAFETY CLASS This is an IEC safety class I product and must be grounded for safety. CONTENTS CONTENTS Important safeguard ........................Preparation for Using your new TV . - Page 3 OSD language Settings When you start using your set for the first time, this menu will be displayed on the screen as shown on the right. 1.Press the [CH+ or CH-] button to select the OSD language 2.Press the [VOL+ or VOL-] button to select the language that you want to use.
-
Page 4: Important Safeguard
The lightning flash with arrowhead symbol, within an equilateral triangle is intended to alert the user to the CAUTION presence of uninsulated dangerous voltage within the product s enclosure that may be of sufficient magnitude to constitute a risk of electric shock. CAUTION: TO REDUCE THE RISK OF ELEC- TRIC SHOCK, DO NOT REMOVE COVER(OR BACK).NO USER-... -
Page 5: Preparation For Using Your New Tv
Preparation for Using your new TV Selecting a location for the TV 1)Place the TV on the floor or on a sturdy platform in a location where light does not directly hit the screen. 2)Place the TV far enough from the walls to allow proper ventilation. Inadequate ventilation may cause overheating, which may damage the TV. -
Page 6: Connecting Your Tv
Preparation for Using your new TV MENU button S-Video input /PC audio input Source select SCART2 Wall mounting locating hole Volume down / cursor left SCART1 AC Power switch Volume up / cursor right Headphone output Channel down / cursor down RS232C DEBUG terminal Channel up / cursor up DVI input... -
Page 7: Connecting To A Computer
Preparation for Using your new TV Connecting to A Computer You can use your TV as a monitor/speakers for your computer by connecting through its 15pin standard RGB interface and PC audio interface. Connect the devices as shown below. PC/NB RGB line ANT.IN RS-232... -
Page 8: Using The Remote Control
Using the remote control Preparing the remote control for use Installing the remote control batteries 1. Open the battery cover on the back of the remote control. 2. Install two AAA size(1.5V) batteries. Match the + and - signs on the batteries to the signs on the battery compartment. -
Page 9: Learning About The Remote Control
Using the remote control Learning about the remote control Power : Power on/off Power Channel Number : Direct channel selection Red/Green/Yellow/Cyan buttons : Fastext Recall : Return to previous channel Display Recall Display : Display current input P.Mode : Select picture mode P.Mode Text CH+ : Channel up... -
Page 10: Using The Tv Features
Using the TV features Understanding the TV features Multimedia - TV receiver, Video monitor and PC display, all in one Wider viewing angle, 16:9 display - over 160 viewing angle, 16:9 ergonomical display panel Digital display device - truthfully reproducing the images, without distortion or blurring, irrespective of magnetic or geomagnetic effect 200 channels storage Sleep timer... - Page 11 Using the TV features Select channels by numbers To select a channel : Press the channel numbers in series to select channel directly. For example, to seclect channel 120, Press the button 1, and 1_ _ will display on the top right corner of the screen, then press the button 2, 12_ will display, press the button zero, you can enjoy the program of channel 120.
-
Page 12: Using The Channel Menu
Using the TV features Using the CHANNEL menu PROGRAM CHANNEL 1) Press the [MENU] button to enter the main menu. 2) Press the [VOL+ or VOL-] button to select the item CHANNEL. 3) Press the [CH+ or CH-] button to select PROGRAM. 4) Press the [VOL+ or VOL-] button to select the present channel. -
Page 13: Using The Picture Menu
Using the TV features Using the PICTURE menu PROGRAM Adjust picture settings PICTURE PARAMETERS 1) Press the [MENU] button to enter the main menu. 2) Press the [VOL+ or VOL-] button to select the item BRIGHTNESS PICTURE PARAMETERS. CONTRAST 3) Press the [CH+ or CH-] button to select the item you want to adjust. -
Page 14: Using The Menu Lock Setting Menu
Using the TV features Using the MENU LOCK SETTING menu LOCK MENU MENU LOCK SETTING 1) Press the [MENU] button to enter the main menu. 2) Press the [VOL+ or VOL-] button to select the item MENU LOCK SETTING. 3) Press the [CH+ or CH-] button to select the LOCK MENU. -
Page 15: Using The General Settings Menu
Using the TV features Using the GENERAL SETTINGS menu OSD POSITION GENERAL SETTINGS 1) Press the [MENU] button to enter the main menu. 2) Press the [VOL+ or VOL-] button to select the item LANGUAGE ENGLISH GENERAL SETTINGS. 3) Press the [CH+ or CH-] button to select OSD POSITION. -
Page 16: Teletext Operations
Using the TV features Using the GENERAL SETTINGS menu DEINTERLACER 1) Press the MENU button to enter the main menu. 2) Press the [ VOL+ or VOL- ] button to select the item GENERAL SETTINGS. 3) Press the [ CH+ or CH- ] button to select DEINTERLACER. 4) Press the [ VOL+ ] button to enter the DEINTERLACER . -
Page 17: Appendix
Using the TV features Teletext Operations ZOOM (Top/Bottom/Full) Using SIZE to enable easier reading (larger display). Press the [ PC ] button to display the TOP HALF of the page. Press again to display the BOTTOM HALF of the page. Press again to return to a FULL PAGE display. -
Page 18: Troubleshooting
Appendix Troubleshooting Before calling a service technician, please check the following table for a possible cause of the problem and some solutions. Possible Solutions Symptoms Make sure the power cord is plugged in, then press [Power]. TV will not turn on The remote control batteries may be dead. -
Page 19: Specifications
Specifications Screen Size: 26-inc h(66c m)TFT LCD TV Native Resolution: 1280 768 Pixels(corresponding to WXGA) Brightness: 500 cd/m2 Contrast Ratio: 600:1 Colour System: PAL/SECAM Sound System: B/G, D/K, I, L/L Tuner: VHF/UHF:48.25~863.25MHz Antenna: 75 VHF/UHF input Stereo: NICAM/A2 VIDEO INPUT: SCART-1 (Video and RGB) Video:1 Vp-p, negative sync, 75 input...
