Vulcan-Hart VWS Series Specifications

model VW2S
SpECIFICATIONS:
Food warming cabinet, 1, 2, or 3 drawers, Vulcan-Hart Model
Nos. VW1S, VW2S, or VW3S. Heavy duty 20 gauge polished
stainless steel cabinet. 4" adjustable legs. Cabinet sides and top
filled with 1" thick insulation. Oversize drawer pull handle. Heavy
duty 14 gauge stainless steel drawer slides are removable for
easy cleaning. Each self closing drawer includes one 12" x 20"
x 6" stainless steel pan, one recessed thermostat adjustable to
190°F and one humidity control. One 475 watt (3.96 amp) heating
element per drawer. Requires 120 volt, 60 Hz, single phase power
supply. 6' power cord with NEMA 5-15 plug.
Exterior dimensions: VW1S: 2 8¼"w x 21½"d x 16½"h
VW2S: 2 8¼"w x 21½"d x 24"h
VW3S: 2 8¼" w x 21½"d x 32¾"h
NSF listed. UL listed. UL listed to Canadian safety standards.
VULCAN-HART COmpANy, p.O. BOX 696, LOUISVILLE, Ky 40201, TEL. 1-800-814-2028
F-37315 (8-07)
(with legs)
(with legs)
(with legs)
502-778-2791 QUOTE & ORDER FAX: 1-800-444-0602
mODEL VWS Series
STANDARD DRAWER WARmERS
VW1S One drawer, 16½" high
®
VW2S Two drawers, 24" high
®
VW3S Three drawers, 32¾" high
®
STANDARD FEATURES
Heavy duty 20 gauge polished stainless steel cabinet.
n
4" adjustable legs.
n
n Cabinet sides and top filled with 1" thick insulation.
n Oversize drawer handle.
Heavy duty 14 gauge stainless steel drawer slides are
n
removable for easy cleaning.
n Each self closing drawer includes one 12" x 20" x 6" stainless
steel pan, one recessed thermostat adjustable to 190°F and
one humidity control.
n One 475 watt (3.96 amp) heating element per drawer.
Requires 120 volt, 60 Hz, single phase power supply.
n
Furnished with 6' power cord with NEMA 5-15 plug.
n One year limited parts and labor warranty.
OpTIONS
208/240 volt, 60 Hz, single phase with plug (NEMA 6-15)
®
® Two year extended limited parts and labor warranty
ACCESSORIES
Trim kit for built-in applications
®
