Vulcan-Hart VCD5 Specifications

model VCD5
SpECIFICATIONS:
First-in First-out chip warming cabinet, Vulcan-Hart Model No
VCD5. Heavy duty 20 gauge polished stainless steel cabinet
with tubular steel inner frame for increased durability. 1" legs.
One-piece doors. Magnetic door latch with 90 degree stopping
mechanism. Removable heating module (with fan) for easy
cleaning. Illuminated on/off switch. Temperature range from 140°
to 190°F. Capacity 17.5 pounds / 22 gallons. One 1250 watt (10.5
amp) heating element. Requires 120 volt, 60 Hz, single phase
power supply. 6' power cord with NEMA 5-15 plug.
Exterior dimensions: VCD5:
NSF listed. UL listed. UL listed to Canadian safety standards.
VULCAN-HART COmpANy, p.O. BOX 696, LOUISVILLE, Ky 40201, TEL. 1-800-814-2028
F-37318 (8-07)
24¼"w x 26¼"d x 20¾"h
502-778-2791 QUOTE & ORDER FAX: 1-800-444-0602
mODEL VCD5
FIRST-IN FIRST-OUT CHIp WARmER
STANDARD FEATURES
n Heavy duty 20 gauge polished stainless steel cabinet with
tubular steel inner frame for increased durability.
n 1" legs.
Magnetic door latch with 90 degree stopping mechanism.
n
Removable heating module (with fan) for easy cleaning.
n
n One-piece doors.
Illuminated on/off switch.
n
Temperature adjust from 140° to 190°F.
n
n Capacity 17.5 pounds / 22 gallons.
n One 1250 watt (10.5 amp) heating element.
Requires 120 volt, 60 Hz, single phase power supply.
n
Furnished with 6' power cord with NEMA 5-15 plug.
n One year limited parts and labor warranty.
OpTIONS
Lexan door.
®
® Adjustable cord length.
® Two year extended limited parts and labor warranty.
