User’s manual Accessory handset for use with VTech models CS6219/CS6219-2/CS6219-3/ CS6219-4/CS6228-3/CS6228-6/ CS6229/CS6229-2/CS6229-3/ CS6229-4/CS6229-5 w w w.v t e c h p h o n e s . c o m Model: CS6209...
The ENERGY STAR encourages the use of products that save energy and help protect our environment. We are proud to mark this product with the ENERGY STAR label indicating it meets the latest energy efficiency guidelines. Telephones identified with this logo have reduced noise and interference Compatible with Hearing Aid T-Coil when used with most T-coil equipped hearing aids and cochlear implants.
Table of contents Getting started ... 1 Parts checklist ... 1 Battery installation and charging ... 2 Add and register a handset ... 3 Replace a handset ... 4 Handset layout ... 5 Appendix ... 6 Battery ... 6 Important safety instructions ... 7 Operating range ...
Getting started Parts checklist Your telephone contains the following items. Save your sales receipt and original packaging in the event warranty service is necessary. Battery compartment cover Handset To purchase a replacement battery or a power adapter, visit our website at www.vtechphones.com or call 1 (800) 595-9511.
Getting started Battery installation and charging Install the battery as shown below. After installing the battery, you might be able to make and receive short calls. For best performance, charge the handset for at least 16 hours before use. When not in use, place the handset in the telephone base or charger.
Getting started Add and register a handset Each newly purchased handset (CS6209) must be registered to the telephone base (CS6219, CS6228 or CS6229) before use. When first purchased, each expansion handset shows NOT REGISTERED. To make registration easier, read all of the instructions on this page before you begin.
Getting started Replace a handset If you want to replace a handset or reassign the designated handset number of a registered handset, you must deregister all the handsets and then individually register each handset. To make deregistration easier, read all of the instructions on this page before you begin.
Getting started Handset layout CHARGE light On when the handset is charging in the telephone base or charger. (Directory) Press to enter the directory when the telephone is not in use. While in a menu, press to scroll up. During a call, press to raise the listening volume.
Appendix Battery It takes up to 16 hours for the battery to be fully charged. When it is fully charged, you can expect the following performance: Operation While in handset use (talking*) While in speakerphone mode (talking*) While not in use (standby**) *Operating times vary depending on your actual use and the age of the battery.
Appendix Important safety instructions When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury, including the following: Read and understand all instructions. Follow all warnings and instructions marked on the product. Unplug this product from the wall outlet before cleaning.
Appendix Operating range This cordless telephone operates with the maximum power allowed by the Federal Communications Commission (FCC). Even so, this handset and telephone base can communicate over only a certain distance - which can vary with the locations of the telephone base and handset, the weather, and the layout of your home or office.
RBRC VTech product service centers. Please call 1-800-8-BATTERY information on Ni-MH battery recycling and disposal bans/restrictions in your area. VTech’s involvement in this program is part of its commitment to protecting our environment and conserving natural resources. RBRC Corporation.
Warranty What does this limited warranty cover? The manufacturer of this VTech Product warrants to the holder of a valid proof of purchase (“Consumer” or “you”) that the Product and all accessories provided in the sales package (“Product”) are free from defects in material and workmanship, pursuant to the following terms and conditions, when installed and used normally and in accordance with the Product operating instructions.
Product in transit. If the Product failure is not covered by this limited warranty, or proof of purchase does not meet the terms of this limited warranty, VTech will notify you and will request that you authorize the cost of repair prior to any further repair activity. You must pay for the cost of repair and return shipping costs for the repair of Products that are not covered by this limited warranty.
Appendix FCC, ACTA and IC regulations FCC Part 15 This equipment has been tested and found to comply with the requirements for a Class B digital device under Part 15 of the Federal Communications Commission (FCC) rules. These requirements are intended to provide reasonable protection against harmful interference in a residential installation.
Appendix FCC, ACTA and IC regulations If this equipment is causing harm to the telephone network, the telephone company may temporarily discontinue your telephone service. The telephone company is required to notify you before interrupting service. If advance notice is not practical, you will be notified as soon as possible. You will be given the opportunity to correct the problem and the telephone company is required to inform you of your right to file a complaint with the FCC.
Appendix Technical specifications Frequency control Crystal controlled PLL synthesizer Transmit Handset: 1921.536-1928.448 MHz frequency Telephone base: 1921.536-1928.448 MHz Channels Nominal effective Maximum power allowed by FCC and IC. Actual operating range range might vary according to environmental conditions at the time of use.
A member of THE VTECH GROUP OF COMPANIES. Distributed in the U.S.A. by VTech Communications, Inc., Beaverton, Oregon 97008 Distributed in Canada by VTech Technologies Canada, Ltd., Richmond, B.C. V6W 1L5 Copyright © 2010 for VTECH TELECOMMUNICATIONS LTD. Printed in China.
