INTRODUCTION
Congratulations! You have purchased
one of the most sophisticated cordless
telephones on the market! The VTech
VT 1901 has been designed to offer
a new standard in cordless telephone
technology.
Unlike most other cordless phones, the
VTech VT 1901 digitizes your voice
using advanced ADPCM digital voice
coding to provide noise and distortion
free performance. In most conditions
you will not be able to tell you are using
a cordless phone.
annoyances of static, interference and
having to listen to other people's
conversations on your cordless phone.
The VTech VT 1901 scrambles your
voice before it transmits it.
ensures that no one can tune in and
eavesdrop on your conversations.
With the VTech VT 1901 the user can
easily answer a call on the handset by
simply pressing any key other than the
OFF, MUTE or Volume Keys. This is
very useful in a dark environment, so
that the user does not have to fumble
around looking for the PHONE key to
answer the call.
The VTech VT 1901 also provides a
one-way Page/find. Pressing the base
PAGE key will cause the handset to
ring in a manner which distinguishes
it from normal incoming ringing. This
can be used to alert the handset user
or to simply locate the handset in the
event that it is misplaced.
1901MANUAL
The VTech VT 1901 uses special
memory in both the base and handset
which is not susceptible to power
failures. This provides permanent
storage of all memory dial numbers, as
well as the base and handset security
codes.
When an optional spare battery pack
is installed in the base unit, the VTech
VT 1901 uses this battery to provide
operational backup in case of power
failure. In this way you have access
Gone are the
to all normal phone functions during a
total power outage. Calls can still be
p l a c e d a n d r e c e i v e d w i t h o u t
interruption. More than 5 hours backup
will be possible with a fully charged
battery in the base unit.
This
The VTech VT 1901 informs you that
another extension is currently in use
on the same phone line. The phone
will also alert you when you are Out
of Range even when you're not using
the phone!
1
1
1/28/99, 3:29 PM
Advertisement
Table of Contents
Related Manuals for VTech VT 1901
Summary of Contents for VTech VT 1901
-
Page 1: Introduction
This ensures that no one can tune in and eavesdrop on your conversations. With the VTech VT 1901 the user can easily answer a call on the handset by simply pressing any key other than the OFF, MUTE or Volume Keys. This is... -
Page 2: Special Features
Detachable power supply. Non- volatile storage of security code and memory dial memories • Programmable Ringer Types This manual is designed to make you familiar with the VTech VT1901. We strongly recommend you read the manual before using your phone. 1/28/99, 3:29 PM... -
Page 3: Parts Check List
REDIAL PROG QUI.MEM MUTE HANDSET BASE UNIT AC POWER ADAPTOR TELEPHONE LINE CORD 1901MANUAL To purchase replacement battery packs, call VTECH Communications at 1-800-595-9511. In Canada, call VTECH Electronics at 1-800-267- 7377. POWER VT 1901 HS IN-USE CHARGING SPARE BATT... -
Page 4: Handset Features
THE HANDSET LAYOUT ANTENNA LOW BATTERY/MUTE INDICATOR PHONE INDICATOR PHONE MUTE/ LO BATT HOLD KEY FLASH PAUSE OFF KEY PHONE HOLD PHONE KEY DIALING KEYS (0-9) TONE (Temporary Tone) REDIAL wxyz pqrs FLASH tone oper MEMORY FLASH REDIAL MUTE PROG QUI.MEM MUTE QUICK MEMORY... -
Page 5: Base Unit Features
THE BASE UNIT LAYOUT TONE/PULSE SELECTOR VT 1901 POWER HS IN-USE MEMORY DIALING CHARGING SPARE BATT PAGE DIGITAL 900MHz CORDLESS BASE UNIT FEATURES 1901MANUAL DC 9V TEL LINE AC POWER JACK PHONE CORD JACK ANTENNA MEMORY DIALING POWER INDICATOR IN USE INDICATOR... -
Page 6: Fcc And Ic Regulations
Should you experience trouble with this telephone equipment, please contact: VTECH COMMUNICATIONS SERVICE DEPT. at 1-800-595-9511. In Canada, call VTECH Electronics at 1-800-267-7377. For repair/warranty information. The telephone company may ask you to disconnect this equipment from the line network until the problem has been corrected. - Page 7 FCC. For repair procedures, follow the instructions outlined under the VTECH Limited Warranty. 1901MANUAL This equipment may not be used on coin service provided by the phone company or Party Lines.
- Page 8 1901MANUAL Your VTech VT1901 is designed to operate at the maximum power allowed by the FCC and IC. This means your h a n d s e t a n d b a s e u n i t c a n...
-
Page 9: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury to persons, including the following: R e a d a n d u n d e r s t a n d a l l instructions. -
Page 10: Save These Instructions
IMPORTANT SAFETY INSTRUCTIONS 12. Unplug this product from the wall outlet and refer servicing to qualified service personnel under the following condition: A. When the power supply cord plug is damaged or frayed. B. If liquid has been spilled into the product. -
Page 11: Replacing The Handset Battery Pack
REPLACING THE HANDSET BATTERY PACK Charging the handset batteries The handset of your VTech VT 1901 cordless telephone is powered by a rechargeable battery pack. It charges automatically whenever the handset is in the base. You should charge the battery pack for 16 hours when you first receive your phone. - Page 12 16 hours. CAUTION: To Reduce the Risk of Fire or Injury to Persons, Read and Follow the Instructions 1. Use only VTECH rechargeable battery pack. 2. Do not dispose of the battery in a fire. The cell may explode. IMPORTANT: Do not dispose of this battery into household garbage.
-
Page 13: A Word About Rechargeable Batteries
However, to maximize the life of your battery pack, do not retum your VT 1901 Handset to the Base Unit cradle for recharging until the MUTE/LO BATT begins to flash. SPARE BATTERY CHARGER The VT 1901 has a built-in Spare Battery Charger, which is located in the cradle of the Base Unit. - Page 14 REPLACING THE HANDSET BATTERY PACK Power Backup When a Spare Battery pack is installed in the Base Unit, the VTech VT 1901 uses this battery to provide operational backup in case of a power failure. if you have a fully charged battery pack...
-
Page 15: Getting Started
GETTING STARTED SETTING UP YOUR VTECH VT 1901 Choose an area near an electrical outlet and a telephone wall jack. AC POWER ADAPTOR Plug the AC power adaptor into an electrical outlet and the DC connector to the back of the base unit. -
Page 16: Check For A Dial Tone
GETTING STARTED CHECK FOR A DIAL TONE. After charging the battery pack, rotate the Base Unit antenna to an upright position. Pick up the Handset, making sure the Handset antenna is fully extended. Now press PHONE , you should hear dial tone. If not, see ‘IN CASE OF DIFFICULTY’... -
Page 17: Wall Mounting
WALL MOUNTING U S I N G T H E WA L L M O U N T ADAPTOR 1. Choose a spot near an electrical outlet and a telephone jack. You phone requires a modular telephone jack and a standard electrical outlet (120v AC). -
Page 18: Quick Reference Guide
QUICK REFERENCE GUIDE SET-UP • Plug AC adaptor into a standard electrical outlet and connect to Base Unit. • Set Dial Mode switch to PULSE or TONE . The unit is factory set to TONE . • Let handset battery pack charge for 16 hours before first use. -
Page 19: Storing Memory Dial Numbers
QUICK REFERENCE GUIDE STORING MEMORY DIAL NUMBERS • The phone should be OFF . • Press PROG . • Enter the two digit memory location (00 .. 20). • Enter the number you wish to store, up to a maximum of 20 digits. -
Page 20: Basic Operation
Base Unit, or press OFF EXTENSION IN USE INDICATOR When another phone is in use on the same line, and the VTech VT1901 is in standby mode, the PHONE LED will flash slowly. Extension In Use indication will not function when the Handset is out of range. -
Page 21: Advanced Functions
ADVANCED FUNCTIONS TEMPORARY TONE If you have rotary (dial-pulse) telephone service (TONE/PULSE switch is set to PULSE), this feature allows you to temporarily switch to TONE dialing for such purposes as remote access to answering machines, bank-by-phone services, use of calling cards and other special services. -
Page 22: Turning Off The Ringer
ADVANCED FUNCTIONS TURNING OFF THE RINGER To turn off the ringer do the following: • Press PROG • Press the # key. • Press • Press PROG or OFF to exit PHONE MUTE/ LO BATT TURNING OFF THE RINGER FLASH PAUSE PHONE HOLD... -
Page 23: Memory (Speed) Dialing
MEMORY (SPEED) DIALING STORING SPEED DIAL NUMBERS To program a speed dial location, do the following: • The phone should be OFF . • Press PROG . The PHONE LED will flash quickly to indicate that the unit is in program mode. •... -
Page 24: Storing Numbers Using Redial
MEMORY (SPEED) DIALING STORING NUMBERS USING REDIAL To store the last number dialed into a permanent memory location, do the following: • The phone should be OFF. • Press PROG . The PHONE LED will flash quickly to indicate the unit is in program mode. -
Page 25: Changing Stored Numbers
MEMORY (SPEED) DIALING CHANGING STORED NUMBERS To change or replace a stored number, simply store a new number in the desired memory location following the instructions listed in STORING MEMORY DIAL NUMBERS. See page DELETING STORED NUMBERS To delete a stored number from memory do the following: •... -
Page 26: Maintenance
MAINTENANCE T A K I N G C A R E Y O U R TELEPHONE. Your VTech VT1901 cordless telephone contains sophisticated electronic parts, so it must be treated with care. Avoid rough treatment Place the handset down gently. -
Page 27: Additional Operating Tips
This is done automatically. Since the VTech VT1901 is a fully digital phone, it does not suffer from noise associated with regular cordless phones. At times you may experience occasional “drop outs”, especially at... -
Page 28: In Case Of Difficulty
If you have difficulty operating your phone, the suggestions below should solve the problem. If you still have difficulty after trying these suggestions, call VTECH Communications at 1-800- 595-9511. In Canada, call VTECH Electronics at 604-273-5131. THE PHONE DOESN’T WORK AT ALL. -
Page 29: You Hear Other Calls While Using Your Phone
IN CASE OF DIFFICULTY YOU HEAR OTHER CALLS WHILE USING YOUR PHONE. Disconnect your base unit from the telephone jack, and plug in a regular telephone. If you still hear other calls, the problem is probably in your wiring or local service. Call your local telephone company. -
Page 30: Warranty Statement
VTECH COMMUNICATIONS 8770 SW NIMBUS AVENUE BEAVERTON, OREGON 97008 IN CANADA VTECH ELECTRONICS 200-7671 Alderbridge Way Richmond,B.C. V6X 1Z9 VTECH Communications assumes no responsibility for units sent without prior Return Authorizatlon WHAT DOES OUR WARRANTY NOT COVER? • Batteries •... -
Page 31: Technical Specifications
TECHNICAL SPECIFICATIONS FREQUENCY CONTROL C r y s t a l C o n t r o l l e d D u a l P L L Synthesizer TRANSMIT FREQUENCY Handset: 925.05 MHz to 927.75 MHz (All ten channels within this range) Base: 902.3 MHz to 905.0... -
Page 32: Table Of Contents
TABLE OF CONTENTS INTRODUCTION ... SPECIAL FEATURES ... 2 PARTS CHECK LIST ... 3 THE HANDSET LAYOUT ... 4 THE BASE UNIT LAYOUT ... FCC AND IC REGULATIONS ... 6 IMPORTANT SAFETY INSTRUCTIONS ... 9 REPLACING THE HANDSET BATTERY PACK... 10 GETTING STARTED ... - Page 33 THE VTECH GROUP OF COMPANIES. Distributed in the U.S.A. by VTECH Communications, 8770 SW Nimbus Avenue / Beaverton, Oregon, 97008. Distributed in Canada by VTECH Electronics Canada Ltd., Suite 200 - 7671 Alderbridge Way Richmond, B.C. V6X 1Z9. Copyright 1997 for VTECH COMMUNICATIONS LTD..
