VTech T2308 User Manual

Part Check List
To purchase replacement batteries, visit
Parts Check List:
us on the web at www.vtechphones.com
1. Handset
or call VTech Communications at
2. Base Unit
800-595-9511. In Canada go to
3. Telephone line cord
www.vtechcanada.com or call VTech
4. Battery
Electronics at 1-800-267-7377.
5. Power Adapter
6. User's manual
2
Installation
Setting Up Your phone
1. Choose an area near an electrical outlet and a telephone wall
jack.
2. Plug the AC power adapter into an electrical outlet and the DC
connector to the power jack on the bottom of the base unit. Insert
the cord in the channel guide.
CAUTION: Use only the AC adapter shipped with your phone. It is
specifically designed for this product.
Connect power to the base unit before placing the
NOTE:
handset in the cradle.
3. CHARGE THE HANDSET BATTERY BEFORE USE. The battery
recharge automatically whenever the handset is in the base unit.
The battery must be charged for
your phone for the first time.
4. Connect the telephone line cord. Insert one end of the telephone
line cord into the phone jack on the bottom of the base unit. Plug
the other end into a telephone wall jack. Make sure the plugs snap
securely into place. Insert the cord in the channel guide.
5. CHECK FOR A DIAL TONE. After the battery is charged, pick
up the handset and press the TALK key. You should hear a dial
tone. If not, see TROUBLESHOOTING.
4
at least 16 hours before using

NEED HELP?

This book has all the feature operation
and troubleshooting you need to install
and operate your new VTech phone.
Please take the time to review thoroughly
to ensure proper installation and the bene-
fit of this VTech innovative and feature rich
product. You can also visit our website at
www.vtechphones.com for support, shop-
ping, and everything new at VTech.
In Canada, please visit
www.vtechcanada.com.
VTech toll free 1-800-595-9511
In Canada dial 1-800-267-7377
Important!
Before using this telephone, you must read important
safety instructions on page 19.
1
Installation
Installing the Battery
1. Slide the battery cover off by gently pressing on the recessed area with a
downward motion.
2. Unplug and remove the old battery. Do not dispose of the old battery in a
trash compactor or fire - it could explode.
3. With the red and black wires at the bottom of the battery, angle the top of
the battery into the compartment, under the claws. Next, press the lower
end of the battery down, so it is held in place by the lower claw. Now, plug
the connector into the socket, located below the battery. Slip the battery
wires into the guide, located below and to the left of the socket.
4. Replace the battery cover by sliding it into place.
5. The new battery must be charged before using your telephone. Place the
handset in the base unit to allow it to charge for at least 16 hours.
Battery Care and Performance
After your battery is fully charged, you can expect the following performance:
Operation
While in use (talking)
While not in use (standby*)
* Handset is off the base unit or charger but not in use.
• Battery power is consumed whenever the handset is off the base unit or
charger, even when the handset is not in use. The longer you leave the
handset off the base unit or charger, the shorter you can actually talk on
the handset. Actual battery performance depends on a combination of how
often the handset is in use and how often it is not in use.
• Once the battery is fully charged, you do not have to charge it again
until is displayed or flashes. This will maximize the battery life.
CAUTION: To reduce the risk of fire or injury, read and follow these
instructions:
1. Use only the VTech battery supplied, or equivalent.
2. Do not open or mutilate the battery. Released electrolyte is corrosive and
may cause damage to the eyes or skin. It may be toxic if swallowed.
3. Exercise care in handling batteries in order not to short the battery with
conducting materials such as rings, bracelets, and keys. The battery or
conductor may overheat and cause burns.
4. Do not dispose of the battery in a fire, it might explode.
3

Handset Features

In Use/Charging LED
• Lights when the handset is on an active call.
• Flashes in unison with an incoming ring.
• Flashes quickly during programming mode.
• Flashes slowly when the battery is low.
• Illuminates steadily when the handset is charging in the base.
TALK/Flash Key
• Press the TALK key to make a call.
• If you are currently on a call, and hear a call waiting tone, press TALK
to switch to the second call. Press TALK again to return to the original
call.
Volume Keys
• Adjusts the volume of what you hear through the handset.
• While on a call, press the or key to adjust the listening volume. The
handset will emit a double beep when the maximum or minimum volume
level has been reached.
Off Key
• Press the OFF key to exit all modes of operation.
Redial/Pause Key
• When you hear the dial tone, press REDIAL to call the last number dialed
on your phone.
• It can also be used to store the last number dialed into speed dial memory.
See Storing a Redial Number into Speed Dial for details.
5
Operating time
up to 4 hours
up to 4 days
