Making Checks After Completion Of Installation Work; Disposal Parts Check; Operation Check - Canon Buffer Pass Unit-N1 Service Manual

Making Checks after
Completion of Installation
Work

Disposal Parts Check

1. Following disposal parts are remained after
completion of the installation work.
[1] Sensor Flag of the Delivery Tray Full Detection
Sensor1 1pc.
[2] Face Cover 1pc.
[3] Face Cover 1pc.
[4] Subtray 1pc.
[5] Inner Cover (Upper) 1pc.
[6] Inner Cover (Lower) 1pc.
[7] Inner Face Seal 1pc
[8] Screw (RS Tightening ; M3x8) 2pcs.
[9] Left Upper Cover 1pc.
[10] Protection Sheet 1pc.
[11] Face Seal (White) 2pcs.

Operation Check

1. Turn ON the main power of the Host Machine after
installing the Finisher.
2. Check the operation such as paper feed to make
sure that problems such as a jam or malfunction do
not occur.
