Page 1 This manual deals with the operation and care of your Volvo. Welcome to the world-wide family of Volvo owners. We trust you will enjoy many years of safe driving in your Volvo, an automobile designed with your safety and comfort in mind. To ensure your satisfaction with this vehicle, we encourage you to familiarize yourself with the equipment descriptions, operating instructions and maintenance requirements/recommendations in this manual.
Page 2: Table Of Contents
All information, illustrations and specifications contained in this manual are based on the latest product information available at the time of publication. Volvo reserves the right to make changes at any time, or to change specifications or design, without notice and without incurring obligation.
Page 3: Volvo
1993 Volvo 960 Instruments and controls Instruments, switches and controls pg. 1:1 Instruments, switches and controls IMPORTANT! Your car is equipped with a Shiftlock-Keylock system. SHIFTLOCK: When your car is parked, the gear selector is locked in the (P)ark position. To release the selector from this position, turn the ignition key to position II (or start the engine), depress the brake brake pedal, press the button on the front side of the gear selector and move the selector from (P)ark.
Page 4 1993 Volvo 960 2 Instrument panel illumination 3 Front/rear fog lamps 4 Radio antenna 5 Space for additional equipment 1:1-1:15 6 Instruments 7 Space for additional equipment 8 Electrically operated sun roof 9 Hazard warning flashers 10 Heated rear window/side door mirrors...
Page 5 1993 Volvo 960 1 Ambient temperature sensor (dealer-installed option) Indicates the temperature slightly above the surface of the road. A red warning lamp lights up when the temperature is in the range of 23-36° F (-5 - +2° C). At low speeds or when the car is not moving, the temperature readings may be slightly higher than the actual ambient temperature due to heat generated by the engine.
Page 6 1993 Volvo 960 1 Turn signal, left 2 Turn signal, right 3 Malfunction indicator lamp 4 Direction indicator, trailer 5 Service reminder indicator 6 Low washer fluid level. If the lamp glows continuously when the engine is running, there is only about 1/2 - 1 US qts. remaining in the washer fluid reservoir.
Page 7 Canadian models are equipped with this warning light: Warning! If the fluid level is below the MIN mark in either section of the reservoir: DO NOT DRIVE. Tow the car to a Volvo dealer and have the brake system checked and any leakage repaired.
Page 8 If this light comes on while driving, the coolant level is low. The coolant level in the expansion tank should be checked immediately and topped up if necessary. The cooling system should be inspected by an authorized Volvo dealer. Turn signal indicators-trailer (certain models) When towing a trailer, this light will flash simultaneously with the turn signals on the trailer.
Page 9 1993 Volvo 960 Contents Top of Page file:///K|/ownersdocs/1993/1993_960/93960_1_1.html (7 of 7)12/30/2006 9:46:47 AM...
Page 10 1993 Volvo 960 pg. 1:11 Heating, ventilation and air conditioning ECC - Electronic Climate Control This is an automatic system that also permits manual operation. The in-car temperature is automatically monitored by two sensors located in the passenger compartment. One sensor is located on the top of the dashboard where it can sense sunlight. The second sensor is located on the courtesy light fixture where it can sense the temperature in the center of the car.
Page 11 1993 Volvo 960 B Closed C Directing air flow horizontally D Directing air flow vertically pg. 1:12 Heating, ventilation and air conditioning (cont.) ECC - Electronic Climate Control panel Blower 0=off 5 = max speed aut = blower speed automatically regulated Air in the passenger compartment recirculates with this button depressed.
Page 12 1993 Volvo 960 aut aut = air distribution automatically regulated Air through panel vents Defrost. Air to windshield and side windows. Air to floor, windshield and side windows. Air through floor vents. Bi-level. Air through floor and panel vents. Air supplied from panel vents is slightly colder than air released at foot level.
Page 13 1993 Volvo 960 Set the function dial to The air conditioning light will NOT go on. When the windows have cleared, set the blower control to position 2. NOTE: The air conditioning compressor only engages at temperatures above 45° F (7°...
Page 14 If the light continues to flash more than 20 seconds, a more serious fault is indicated. While the system will again attempt to substitute a standard value, some reduction in system performance will become apparent. Contact your authorized Volvo dealer for service. pg. 1:14 Heated front seats Heated front seats The heated front seats can be switched on and off as required.
Page 15 1993 Volvo 960 Electrically-operated windows The electrically operated windows are controlled by switches from the driver's armrest as shown in the above illustration. The starting (ignition) switch must be ON (position II) for the electrically operated windows to function. The window is lowered if the rear part of the switch is pressed and raised if the front part of the switch is pressed.
Page 16 1993 Volvo 960 Cut-out switch for rear-door windows If the car is equipped with rear door power windows, this function can be disabled by a switch located on the driver's door armrest. This switch is positioned 90° in relation to the other switches.
Page 17 1993 Volvo 960 Parking brake (hand brake) The lever is situated between the front seats. The brake is applied to the rear wheels. WARNING! Always use the parking brake (hand brake) when parking. On hills, also turn the front wheels toward the curb.
Page 18 1993 Volvo 960 Cigarette lighter To operate, depress the knob fully. When the knob automatically releases, the cigarette lighter is ready for use. The starting (ignition) switch must be switched on (to position I or II) for the cigarette lighter to function.
Page 19 1993 Volvo 960 Contents Top of Page file:///K|/ownersdocs/1993/1993_960/93960_1_11.html (10 of 10)12/30/2006 9:46:49 AM...
Page 20 1993 Volvo 960 pg. 1:17 Audio system The following pages describe the use of your SC-810 Cassette Radio and CD remote control 1. - On/off (turn) - Volume (turn) - Pause/Mute (push) 2. CD mode selector 3. Bass control 4. Treble control 5.
Page 21 1993 Volvo 960 CD-Random play 13. Cassette eject 14. Display 15. Cassette slot 16. TP-Next song CD-Next track UP 17. TP-Fast forward CD-Music search UP 18. TP-Rewind CD-Music search DOWN 19. TP-Previous song REPEAT CD-Previous track DOWN 20. Tape mode selector...
Page 22 1993 Volvo 960 Anti-theft code The radio features anti-theft circuitry. If the set is removed from the vehicle or if the battery power is disconnected, a special code must be entered to enable operation of the set. Refer to the radio code card supplied with your vehicle or ask your dealer for the correct code.
Page 23 1993 Volvo 960 A - On/off switch and volume control Turn the button clockwise to switch on and to increase the volume. B - Waveband selector The desired waveband is set by pressing one of the waveband selector buttons. The frequency and waveband is shown on the display.
Page 24 1993 Volvo 960 A - Seek tuning Push the tuning knob to seek for higher frequencies.The radio seeks the next audible station and stops there. If you wish to continue the seek tuning, press the tuning knob again. B - Preset programming 1.
Page 25 1993 Volvo 960 A - Automatic programming (Autostore) This function automatically seeks and stores up to 8 strong AM or FM stations. 1. Depress and hold one of the "auto store" buttons for at least 1 second. A number of strong stations (max.
Page 26 1993 Volvo 960 A - Fader control Adjust front/rear speaker balance by sliding the control up or down. (Up to direct more sound to the front speakers, down to direct more sound to the rear speakers. The "detent" indicates "equalized" front /rear balance position.
Page 27 1993 Volvo 960 pg. 1:23 Cassette deck A - Cassette slot The cassette is inserted with the open side to the right (side 1 or A of the cassette upwards). When the cassette is inserted, the radio is disengaged and the cassette will start to play automatically. "TAPE 1" or "TAPE 2"...
Page 28 1993 Volvo 960 A - "nxt" (next) selector Press the "nxt" button and the tape will automatically advance to the next song. There must be a pause of approx. 5 seconds between songs for this function to operate. B - "rpt" (repeat) selector Press the "rpt"...
Page 29 1993 Volvo 960 A - Cassette eject If the button is pressed the tape will stop and the cassette will be ejected. The radio will be automatically engaged. The radio or CD will engage automatically (depending on which mode was activated before the tape was played).
Page 30 * The functions pertaining to the CD-changer are only applicable if the unit has been connected to the Volvo CD-changer which is sold separately as an accessory. B - Disc number selector Depress one of the preset buttons ( 1-6) to select the disc number desired. The selected disc number and track number will be displayed.
Page 31 1993 Volvo 960 A - Track number selector Turn the knob to select the track number desired. B - Changing the selected track number Press "nxt" for forward selection or "rpt" for backward selection. The chosen disc number and track number will be displayed.
Page 32 CD changer The CD changer, which is available separately, is loaded with a cartridge containing 6 discs. Extra cartridges are available at your Volvo dealer. Insert the discs into the cartridge, label (A) up. Insert the cartridge and close the cover.
Page 33 1993 Volvo 960 Eject the cartridge by pressing the eject button (B). Remove the discs by depressing the lock tabs (C). Operating tips: Before using a new disc for the first time, remove any burrs in the center/outer edge by running the stem of a pen or similar object around the hole/edge of the disc.
Page 34 1993 Volvo 960 pg. 1:30 General information Sending signals The FM waves do not follow the earth's surface nor do they bounce off the atmosphere. For this reason their range is limited. The AM waves follow the earth's surface and reflect against the atmosphere, giving them a wide range.
Page 35 1993 Volvo 960 Because of the limited range of the FM senders and the fact that these waves are very reflective, this problem usually occurs with FM reception. If the sender is blocked by buildings or mountains, static can result.
Page 36 1993 Volvo 960 Cross modulation If you listen to a weak station in the vicinity of a stronger one, both stations may be received simultaneously. FM - reasons for distortion FM is affected by the electrical systems of nearby vehicles, especially those without suppression. The distortion increases if the station is weak or poorly set.
Page 37 Reception conditions are not always optimum and this is, of course, beyond our control. However, we have endeavored to make the Volvo Audio System of a quality that will enable you to enjoy the best possible reception no matter what the reception conditions may be.
Page 38 Take up slack using a pen or a pencil before inserting a cassette in the cassette slot. Cassette cleaning We recommend the use of the Volvo Cleaning Cassette available as a genuine Volvo accessory. Regular use improves sound quality, cleans vital parts and prevents tape tangle.
Page 39 1993 Volvo 960 Frequency range 30-15000 hz S/N (120 V) 55 dB S/N (70 V) 55 dB Wow and Flutter 0. 13% file:///K|/ownersdocs/1993/1993_960/93960_1_30.html (6 of 6)12/30/2006 9:46:54 AM Contents Top of Page...
Page 40 1993 Volvo 960 pg. 1:6 Lighting, Turn signals Headlights and parking lights O All lights off * Parking lights on * Headlights and parking lights are on if starting (ignition) switch is in position I or II. If the headlight switch is in position...
Page 41 1993 Volvo 960 pg. 1:7 Windshield, wipers/washer, Ignition switch Wiper/washer 1 Intermittent wiper. With switch in this position, the wipers will sweep approximately every seventh second. 2 "Single sweep" position. Switch returns automatically when released. 3 Wipers, low speed. 4 Wipers, high speed.
Page 42 1993 Volvo 960 5 Windshield wiper/washer. The wiper will make 2-3 complete sweeps after the lever is released. Starting (ignition) switch/steering wheel lock The steering wheel lock might be under tension when the car is parked. Turn the steering wheel slightly to free the ignition key.
Page 43 1993 Volvo 960 The switch has two settings: 1 Front foglights ON. 2 Front and rear foglights ON. When both front and rear foglights are turned on both indicators will light. The rear foglight is considerably brighter than the normal tail light and should be used only when the atmospheric conditions, such as fog, rain, snow, smoke or dust reduce the daytime or nighttime visibility of other vehicles to less than 500 ft (150 meters).
Page 44 1993 Volvo 960 CAUTION: Always lower the antenna when entering a garage or car wash to avoid antenna damage. The antenna mast should be cleaned and lubricated every 10,000 miles (16,000 km). See page 1:32. Steering wheel adjustment The steering wheel can be adjusted to 3 different positions.
Page 45 1993 Volvo 960 roof, depress the side of the rocker switch opposite the side used to open the roof. NOTE: In case of a sun roof malfunction, see "Emergency sun roof operation", page 6:19. Hazard warning flasher The four-way flasher should be used to indicate that the vehicle has become a traffic hazard.
Page 46 1993 Volvo 960 Cruise control The cruise control switches are located on the turn signal switch lever. To engage and set desired speed: 1. Set switch (B) to ON. 2. Accelerate to desired cruise speed. NOTE: The cruise control cannot be engaged at speeds below 22 mph (35 km).
Page 47 1993 Volvo 960 NOTE: When driving up steep hills with the cruise control engaged, the transmission may shift intermittently. This can be avoided by switching between transmission modes E or S while on the hill. Normally, the (E)conomy mode should be used when the cruise control is engaged.
Page 48: Body And Interior
1993 Volvo 960 Body and interior pg. 2:1 Body and interior Body and interior The seats, seat belts, doors, sun roof, mirrors, etc. are described on the following pages. Keys, Doors and Locks Remote keyless entry system Front seats Rear/side view mirrors, Vanity mirror...
Page 49 As an added anti-theft measure, new keys have been developed, which may take slightly longer to copy or replace if the original keys are misplaced. In the event the original keys are lost, duplicates may be ordered from your Volvo dealer. The central locking system is described in detail in section "Doors and locks".
Page 50 1993 Volvo 960 pg. 2:3 Doors and locks Door Locks The vehicle is equipped with a central door- locking system. This means the lock on the driver's door controls the locks on the other doors (including the trunk or, on wagon models, the tailgate) automatically.
Page 51 1993 Volvo 960 To avoid battery drain The interior light and the warning lights in the rear of the doors come on when a door is opened. To avoid battery drain when the doors are opened for prolonged periods, these lights can be switched off by pushing in and turning the door light switches slightly clockwise.
Page 52 1993 Volvo 960 NOTE: The electrically operated front seats have an overload protector which engages if an object blocks either of the seats. If this happens remove the object and wait 20 seconds. The overload protector should then have cooled down and the power seats should function normally.
Page 53 1993 Volvo 960 Driver's seat Movement of the driver's seat can be STOPPED at any time by pressing any button on the seat's control panel. WARNING! On certain models, the driver's seat is operable with the ignition OFF. Therefore, children should never be left unattended in the car.
Page 54 1993 Volvo 960 Rear-view mirror A Normal position B Night position, reduces glare from following headlights CAUTION: Never use ice scrapers made of metal as they can easily scratch the mirror surface. Electrically-operated side-view mirrors file:///K|/ownersdocs/1993/1993_960/93960_2_1.html (7 of 8)12/30/2006 9:46:57 AM...
Page 55 1993 Volvo 960 The control switches are located in the driver's door armrest. A Adjustment sideways B Adjustment up/down WARNING! Objects seen in the wide-angle right-side mirror are closer than they appear to The mirrors should always be adjusted prior to driving.
Page 56 1993 Volvo 960 pg. 2:11 Tailgate, Child safety lock (wagon) Tailgate To unlock - turn the key clockwise and allow it to spring back. To lock - turn the key counter-clockwise and allow it to spring back. NOTE: The tailgate is also unlocked and locked at the same time as the driver's door.
Page 57 1993 Volvo 960 To open the tailgate from the inside of the vehicle move the handle to the left and push outwards. The handle can be used to close the tailgate from the inside (see illustration). WARNING! Do not drive with tailgate open! Poisonous exhaust gases may enter via the open tailgate.
Page 58 1993 Volvo 960 The tailgate incorporates a safety catch which is located to the side of the lock. A the tailgate functions normally B the tailgate cannot be opened from the inside. pg. 2:12 Concealed storage bins, Rear seat head restraints (wagon) Concealed storage bins There are three storage bins under the floor of the cargo space;...
Page 59 1993 Volvo 960 The lid of the largest storage bin is hinged in the middle Folding rear seat; increasing the cargo space The rear head restraints can be raised by pulling straight up or lowered by grasping the restraint, pulling it slightly forward and pushing down.
Page 60 1993 Volvo 960 The rear seat is split 60/40 so that each section can be folded independently. Straighten front backrests if they are tilted too far to the rear. Pull the strap to lift the seat cushion and swing the cushion up and toward the back of the front seats.
Page 61 1993 Volvo 960 WARNING! When the rear seat is folded down, do not place heavy objects against the backs of the front seats. This places a severe strain on the folded down backrest of the rear seat. Cargo must not be stacked higher than the top of seatbacks. This will reduce the possibility of luggage , etc.
Page 62 1993 Volvo 960 Lift the seat cushion part way and remove the seat. Removing seat cushions The seat cushion can be easily removed to provide a slightly larger cargo storage area. To remove, lift the seat cushion out of the hinges.
Page 63 WARNING! The eyelets are not to be used as passenger restraints. See page 3:7. Unless the station wagon is equipped with Volvo's Auxiliary Third Seat (option) passengers should not ride in this section of the car. pg. 2:15 Cargo space lighting, Spare tire and jack (wagon) file:///K|/ownersdocs/1993/1993_960/93960_2_11.html (8 of 10)12/30/2006 9:46:58 AM...
Page 64 1993 Volvo 960 Cargo space lighting There is an extra courtesy light at the rear of the cargo space. 1 Light comes on when the tailgate is opened 2 The light is always OFF 3 The light is always ON Spare tire and jack The spare tire and the jack are located beneath the floor mat in the large storage bin.
Page 65 1993 Volvo 960 spare tire and the jack to prevent them from rattling. NOTE: See pages 6:2-6:3 for information on how the jack should be used. file:///K|/ownersdocs/1993/1993_960/93960_2_11.html (10 of 10)12/30/2006 9:46:58 AM Contents Top of Page...
Page 66 1993 Volvo 960 pg. 2:6 Interior light, Sun roof Interior light 1 Light always on. 2 Light always off. 3 Light is on when either of the front or the rear doors are opened. A time-delay device keeps the interior illuminated for approx. 12 seconds after closing the driver's door. This facilitates finding starting (ignition) switch, etc., at night.
Page 67 1993 Volvo 960 Electrically-operated sun roof The switch for operating the sun roof is located on the instrument panel. The starting (ignition) key must first be turned to the drive position. To open the sun roof as a sliding roof, depress the top portion of the switch. To raise the rear edge of the sun roof, depress the bottom portion of the switch.
Page 68 1993 Volvo 960 WARNING! Remember, in the event of an accident, the rear seat passengers cannot open the doors from the inside with the buttons in position Trunk lid The trunk lock is incorporated in the central locking system. This means that you can either lock or unlock the trunk by means of the driver's door lock.
Page 69 1993 Volvo 960 Withdraw key in vertical position. pg. 2:8 Storage spaces WARNING! Packages on the rear window shelf can obscure vision and may become dangerous projectiles in the event of a sudden stop or accident. pg. 2:9 Hood file:///K|/ownersdocs/1993/1993_960/93960_2_6.html (4 of 7)12/30/2006 9:46:59 AM...
Page 70 1993 Volvo 960 To open the hood Pull the release handle (located under the left side of the dash). Lift the hood slightly, insert a hand under the center line of the hood and depress the safety-catch handle. Open the hood.
Page 71 1993 Volvo 960 NOTE: See pages 6:2-6:3 for information on how the jack should be used. Trunk light A Light always off. B Light is on when trunk lid is opened. Long load storage In the panel behind the rear seat is a door which makes it possible to carry long loads such as skis, etc.
Page 72 1993 Volvo 960 Protective covers (for skis) should also be used to avoid soiling or tearing the upholstery. Please note that the flap in the rear seat is only intended for light loads such as skis, wood etc. Max. length of load 6 1/2 ft = 2 m.
Page 73: Occupant Safety, Reporting Safety Defects
Despite our strongest recommendations, and your best intentions, not wearing a seatbelt is like believing "it'll never happen to me!". Volvo urges you and all adult occupants of your car to wear seatbelts and ensure that children are properly restrained, using an infant, car or booster seat determined by age, weight and height.
Page 74 1993 Volvo 960 tensioners. To buckle: Pull the belt out far enough to insert the latch plate into the receptacle (buckle for rear seats), until a distinct snapping sound is heard. The seat belt retractor is normally "unlocked" and you can move freely, provided that the shoulder belt is not pulled out too far.
Page 75 1993 Volvo 960 Before exiting the car, check that the seat belt retracts fully after being unbuckled. If necessary, guide the belt back into the retractor slot. WARNING! Any device used to induce slack into the shoulder belt portion of the three-point system will have a detrimental effect on the amount of protection available to you in the event of a collision.
Page 76 1993 Volvo 960 Center head restraint The center head restraint can be adjusted according to the passenger's height. The restraint should be carefully adjusted to support the occupant's head. During pregnancy Pregnant women should always wear seat belts. Remember that the belt should always be positioned in such a way as to avoid any possible pressure on the abdomen.
Page 77 As an enhancement to the three-point seat belt system, your Volvo is equipped with a Supplemental Restraint System (SRS). The Volvo SRS consists of an airbag (2) and knee bolster (5) on both the driver's and passenger's sides and seat belt tensioners in both front door pillars (4). The system is designed to supplement the protection provided by the three-point seat belt system.
Page 78 When installing any optional equipment make sure that the SRS system is not damaged. Do not attempt to service any component of the SRS yourself. Attempting to do so may result in serious personal injury. If a problem arises, take your car to the nearest authorized Volvo Dealer for inspection as soon as possible.
Page 79 WARNING! If the SRS warning light stays on after the engine has started or if it comes on while you are driving, drive the car to the nearest authorized Volvo Dealer for inspection as soon as possible. file:///K|/ownersdocs/1993/1993_960/93960_3_1.html (7 of 10)12/30/2006 9:47:01 AM...
Page 80 The SRS decal on your car shows the month and year servicing is due. This service must be performed by an authorized Volvo dealer. Should you have any questions about the SRS system, please contact your authorized Volvo Dealer or the Consumer Affairs Department.
Page 81 1993 Volvo 960 FAILURE TO FOLLOW THESE INSTRUCTIONS CAN RESULT IN INJURY TO THE VEHICLE OCCUPANTS IN AN ACCIDENT. For further information, see owner's manual. VOLVO SRS text at far right of instrument panel and on inside of driver side sun visor WARNING! Do not use child safety seats or child booster cushion/backrests in the front passenger's seat.
Page 82 If you are involved in an accident which has resulted in air bag deployment, we recommend the following: - Have the car towed to an authorized Volvo dealer or collision repair shop. Even if the car is driveable after an accident, we do NOT recommend driving the car with deployed air bags.
Page 83 3:7 Child safety Child Restraint Anchorages Volvo cars are fitted with Child Restraint Top Tether Anchorages in the rear seat. There are three anchorages under the rear section of the car's rear window shelf on sedans and on the back rest on wagons.
Page 84 1993 Volvo 960 WARNING! Child Restraint Anchorages are designed to withstand only those loads imposed by correctly fitted Child Restraints. Under no circumstances are they to be used for adult seat belts of harnesses. The anchorages are not able to withstand excessive forces on them in the event of collision if full harness seat belts or adult seat belts are installed to them.
Page 85 The booster cushion should also be replaced if it is badly worn or damaged in any way. This work should be performed by an authorized Volvo dealer only. The booster cushion should be cleaned while in place in the vehicle if possible. If not, please consult your Volvo dealer.
Page 86 A misused child restraint system can result in increased injuries for both the infant or child and other occupants in the vehicle. If your child restraint requires a top tether strap, consult your authorized Volvo dealer for top tether anchorage and installation information.
Page 87 In the above checks you should not be able to pull the belt out. Volvo Concern for Safety Safety is the cornerstone for Volvo. Our concern dates back to 1927 when the first Volvo rolled off the production line. Three-point seat belts, safety cages, and energy-absorbing impact zones were designed into Volvo cars long before it was fashionable or required by government regulation.
Page 88 However, NHTSA cannot become involved in individual problems between you, your retailer, or Volvo Cars of North America. To contact NHTSA, you may either call the Auto Safety Hotline toll-free at 1-800-424-9393 (or 366-0123 in Washington, D.C. area) or write to: NHSTA, U.S.
Page 89: Starting And Driving
1993 Volvo 960 Starting and driving pg. 4:1 Starting and driving Starting and driving This section on starting and driving contains items such as starting the engine, operating gear selector, towing, trailers. Break-in period Fuel requirements, Refueling Economical driving Starting the engine...
Page 90 Deposit control gasoline Volvo recommends the use of gasoline containing deposit control additives. These additives have shown to be efficient in keeping injectors and intake valves clean. Consistent use of deposit control gasolines will help ensure good driveability and fuel economy.
Page 91 1993 Volvo 960 Unleaded Fuel Each Volvo has a three-way catalytic converter and must use only unleaded gasoline (as specified on the instrument panel and by a label near the filler inlet.). U.S. and Canadian regulations require that pumps delivering unleaded gasoline be labeled "UNLEADED". Only these pumps have nozzles which fit your car's filler inlet.
Page 92 1993 Volvo 960 wagon, with sufficient volume left over to accommodate possible expansion of the fuel in hot weather. Be aware that the "usable" tank capacity will be somewhat less than the specified maximum. When the fuel level is low, such factors as ambient temperature, the fuel's "vapor pressure" characteristics, and terrain can affect the fuel pumps' ability to supply the engine with an adequate supply of fuel.
Page 93 1993 Volvo 960 Dirty engine oil and clogged oil filter Dragging brakes Incorrect front end alignment Some of the above mentioned items and others are checked at the standard Maintenance Service intervals. NOTE: Since using (D)rive improves fuel economy, it should be used as often as possible.
Page 94 1993 Volvo 960 CAUTION: Engine should be idling; never accelerate until after you feel the gear engage! Too rapid acceleration immediately after selecting a gear will cause harsh engagement and premature transmission wear. 6 Release the brakes and accelerate. To stop the car, release the accelerator pedal and apply the brakes.
Page 95 1993 Volvo 960 NOTE: Selecting position P or N when idling at a standstill for prolonged periods of time will help prevent overheating of the transmission oil. pg. 4:6 Automatic transmission AW 30/4 P (Park) Use this position when starting the engine or parking the car.
Page 96 1993 Volvo 960 WARNING! Never leave the car when the engine is running. If, by mistake, the gear selector is moved from P the car may start moving. R (Reverse) Never engage R while is moving forward. N (Neutral) Neutral position = no gear is engaged. Use parking brake. The engine can be started with the gear selector in this position.
Page 97 1993 Volvo 960 L (Low gear) No upshift can occur when L is engaged. Select position L for driving in first and second gears. Use this position to select low gear with no upshift, e.g. when ascending and descending steep grades.
Page 98 * These positions always offer the kick-down facility. CAUTION: Driveability and fuel economy will be adversely affected by prolonged driving in mode W . Volvo recommends using this mode only when starting in extremely slippery conditions. The indicator lamp in the instrument order to disengage the Winter mode.
Page 99 1993 Volvo 960 "Lock-up" The automatic gearbox has a "lock-up" function. It reduces engine speed and saves fuel. The principle of "lock-up" is based on the fact that the gearbox's torque converter is disengaged for changes between 3nd, 3nd and 4th gears. The "lock-up" function can sometimes be felt as an additional gearchange.
Page 100 1993 Volvo 960 pg. 4:14 Three-way catalytic converter Three-way catalytic converter cautions Keep your engine properly tuned. Certain engine malfunctions, particularly involving the electrical, fuel or distributor ignition systems, may cause unusually high three-way catalytic converter temperatures. Do not continue to operate your vehicle if you detect engine misfire, noticeable loss of power or other unusual operating conditions, such as engine overheating or backfiring.
Page 101 If the warning lamp lights up there si a malfunction of the ABS system (the standard braking system will however function) and the vehicle should be driven to a Volvo retailer for inspection. The Anti-lock Braking System (ABS) helps to improve vehicle control (stopping and steering) during severe braking conditions by limiting brake lock-up.
Page 102 When preparing for trailer towing, observe the following: Use a trailer hitch which meets Federal Safety Standards for rear end collisions (FMVSS 301-75). For trailer weights exceeding 2000 lbs (908 kgs) use only a trailer hitch offered as a Genuine Volvo Accessory.
Page 103: Wheels And Tires
More frequent vehicle maintenance is required. Remove the ball and drawbar assembly when the hitch is not being used, Volvo recommends the use of synthetic engine oil when towing a trailer over long distances or in mountainous areas. The trailer hitch tongue load (110/165 lbs - 50/75 kg) is part of the vehicle's capacity weight. It may be necessary to reduce the trunk/cargo area load when towing a trailer to ensure that the max.
Page 104 If you wish to check your car before the approach of cold weather, the following advice is worth noting: Make sure that the engine coolant contains at least 50 percent antifreeze: that is, 5.3 qts. (5 liters) Volvo Genuine Coolant/Antifreeze. This gives protection against freezing down to -31°F (-35°C). See section "Coolant".
Page 105 Before a long distance trip It is always worthwhile to have your car checked at a Volvo retailer before driving long distances. Your retailer will also be able to supply you with bulbs, fuses, spark plugs and wiper blades for your use in the event that problems occur.
Page 106 Open one of the windows slightly for ventilation. Ensure that the coolant contains sufficient anti-freeze to provide protection down to -22°F (-30°C). Volvo Genuine Coolant/Anti-freeze also provides resistance against corrosion. Remove all valuables and lock the car. Keep the battery fully charged.
Page 107 1993 Volvo 960 pg. 4:8 Points to remember "Special Tips" For steep hills and when driving for prolonged periods at low speeds, position L should be selected. Avoid, however, repeated changes since this can cause overheating of the transmission oil. For driving on long continuous uphill gradients, select position 3.
Page 108 1993 Volvo 960 WARNING! Do not drive with trunk lid or tailgate open! Poisonous exhaust gases may enter via the trunk lid or tailgate. If the trunk lid/tailgate must be kept open for any reason, proceed as follows: Close the windows.
Page 109 1993 Volvo 960 WARNING! The Supplemental Restraint System is grounded under the driver's seat. Do not loosen the two screws grounding the unit. Do not ground other electrical components using these screws or any other points near them. Faults in the system could occur if it is improperly grounded.
Page 110 Not more than one protective floor covering may be used at one time. Roof racks (removable and permanent) Roof racks are available as Volvo accessories. Observe the following points when is use: Avoid single-point loads. Distribute the load evenly. Place heavier cargo at bottom of load.
Page 111 1993 Volvo 960 Precautionary steps to observe when car is in tow Steering must be unlocked. Please check with state and local authorities before attempting this type of towing, as vehicles being towed are subject to regulations regarding maximum towing speed, length and type of towing device, lighting, etc.
Page 112 1993 Volvo 960 Only use wheel lift or flat bed equipment. CAUTION: Sling-type equipment applied at the front will damage radiator and air conditioning lines. It is equally important not to use slingtype equipment inside the rear wheels: serious damage to the rear axle may result.
Page 113 1993 Volvo 960 CAUTION: Improper hook-up of jumper cables or use of other than 12-volt batteries could result in damage to equipment and/or battery. Check that cars are not touching to prevent premature completion of negative circuit. Note the position of the battery terminals and using jumper cables, first connect booster battery positive (+) terminal (1) to car battery positive (+) terminal (2).
Page 114 1993 Volvo 960 Contents Top of Page file:///K|/ownersdocs/1993/1993_960/93960_4_8.html (8 of 8)12/30/2006 9:47:05 AM...
Page 115 1993 Volvo 960 Wheels and tires pg. 5:1 Wheels and tires Wheels and tires The handling and riding comfort of the vehicle is dependent on the inflation pressure and the type of tires fitted. Read the following pages carefully. General information...
Page 116 1993 Volvo 960 Snow chains Snow tire chains can be used on your Volvo with the following restrictions: Snow chains should be installed on rear wheels only. Snow chains can be used on the tires and wheels provided as original production equipment with your Volvo.
Page 117 NOTE: Regulations governing the use of studded tires may vary from one state or province to another. WARNING! Special wheel rims for air dams Only special wheel rims, tested and approved by Volvo, are suitable for use with the air dam installed on the 960. pg. 5:4 Wheels and tires Checking and correcting tire pressure file:///K|/ownersdocs/1993/1993_960/93960_5_1.html (3 of 5)12/30/2006 9:47:06 AM...
Page 118 The tire temperature rises after driving just a few miles. Vehicle Loading The tires on your Volvo will perform to specifications at all normal loads when inflated as recommended on the tire information label* located on the rear facing side on the right front door. This label lists both the tire and vehicle design limits.
Page 119 1993 Volvo 960 Contents Top of Page file:///K|/ownersdocs/1993/1993_960/93960_5_1.html (5 of 5)12/30/2006 9:47:06 AM...
Page 120: In Case Of Emergency
1993 Volvo 960 In case of emergency pg. 6:1 In case of an emergency In case of emergency Even if you maintain your car in good running condition, there is always the possibility that something might go wrong and prevent you from driving, such as a punctured tire, blown fuse or bulb, etc.. For additional information, see section "ON CALL Road Assistance".
Page 121 1993 Volvo 960 Changing a wheel On sedans the spare wheel, jack and toolbag are located in the trunk, beneath the carpet. The jack must be completely retracted to fit into the holder. On wagons, the spare tire and the jack are located beneath the floor mat in the large storage bin. Always secure the spare tire and the jack to prevent them from rattling.
Page 122 1993 Volvo 960 There is a jack attachment adjacent to each wheel location. Hang the jack from the attachment (alt. 1) or position the jack on the bar in the jack attachment (alt. 2) as shown in the illustrations above and crank while simultaneously guiding the base to the ground.
Page 123 Recommended tire pressure (see decal) should be maintained irrespective of which position of the car the Special Spare tire is used on. In the event of damage to this tire a new one can be purchased from your Volvo dealer. file:///K|/ownersdocs/1993/1993_960/93960_6_1.html (4 of 5)12/30/2006 9:47:07 AM...
Page 124 1993 Volvo 960 Contents Top of Page file:///K|/ownersdocs/1993/1993_960/93960_6_1.html (5 of 5)12/30/2006 9:47:07 AM...
Page 125 1 x 15A (blue), 1 x 25A (pale yellow), 1 x 30A (green) If fuses burn out repeatedly, have the electrical system tested at a Volvo dealer. If you find it difficult to remove a fuse, you will find a special fuse tool clipped in the fuse box.
Page 126 1993 Volvo 960 pg. 6:14 Fuses Location* Amperage 1 Position lights license plate light 10 2 Position lights 10 3 Left high beam 15 4 Right high beam 15 6 Left low beam 15 7 Right low beam 10 8 Front fog lights 15...
Page 127 Note: Fuses No. 34 and 35 are circuit breakers which activate when overloaded. After 20 seconds, the circuits should have cooled down and function normally. For more detailed information concerning function and location of relays, fuses, etc., refer to the Volvo Service Manuals. These can be purchased directly using the Service Literature Brochure/Order Form or through your Volvo dealer.
Page 128 1993 Volvo 960 The diagnoses outlined below are intended to serve only as guides to locate and temporarily correct minor faults. Causes of unsatisfactory performance should be investigated and corrected by your Volvo dealer only. See section "Road Assistance". Starter fails to operate (or operates very slowly) Weak battery or dead cell.
Page 129 If there is no spark, check that the high tension lead from the coil to the distributor cap is connected and that the wires to the distributor and coil are connected. If no fault is found following the above steps, contact your Volvo dealer. Excessive fuel consumption Fuel lines leaking.
Page 130 1993 Volvo 960 Misfiring at highway driving speed Spark plugs fouled. Drive the vehicle in a lower gear and keep the engine rpm higher for a few miles in order to remove carbon deposit on the spark plugs. If this procedure is not effective, clean or replace the spark plugs.
Page 131 1993 Volvo 960 Shiftlock release The gear selector is locked in the P position. To manually release the shift lock, turn the starting (ignition) key to position I and press firmly on the "SHIFTLOCK OVERRIDE" button located near the base of the gear selector (see illustration). While holding the override button down, move the gear selector from the (P)ark position.
Page 132 1993 Volvo 960 pg. 6:5 Replacing bulbs NOTE! The method for replacement of bulbs in the various lighting units is shown on the following pages. Make sure when installing bulbs, that the guide pin on the socket fits into its corresponding recess.
Page 133 1993 Volvo 960 Power CP (W) Socket US Bulb No. 24/2.2(21/5) BAY 15d 1157 NA pg. 6:6 Replacing bulbs Access to the bulbs is obtained from the engine compartment. Switch off the lights and ignition key. Note: It may be necessary to remove the washer fluid reservoir fill tube in order to gain access to the bulb holder.
Page 134 1993 Volvo 960 Replacing tail light bulbs (sedan models) All tail lamp bulbs are replaced from inside of trunk. To avoid confusion, replace the bulbs one at a time. 1 Unscrew and remove tail lamp inside cover. Note that inside cover is hooked at the lower edge.
Page 135 1993 Volvo 960 5 Back-up light 32 (21) BA 15s 1156 6 Rear foglamp* 32 (21) BA 15s 1156 * Left (driver's) side only pg. 6:8 Replacing bulbs All tail light bulbs are replaced from inside the vehicle. Replacing tail light bulbs (wagon models) Turn off the lights.
Page 136 1993 Volvo 960 3 Turn signals 32(21) BA15s 1156 4 Brake light and tail light 32/3(21/5) BAZ 15d 1157 Reflector - - - High-mounted stop lamp 32(21) BA15s 1156 * Left side only pg. 6:9 Replacing bulbs file:///K|/ownersdocs/1993/1993_960/93960_6_5.html (5 of 13)12/30/2006 9:47:09 AM...
Page 137 1993 Volvo 960 Trunk light (sedan models) Courtesy light (wagon models) Depress the catch with a screwdriver and remove the light assembly. Lift it out to remove. Replace the bulb. Bulb Power Socket Trunk light 10 W SV 8.5 WARNING! When using a screwdriver to pry plastic components, take care to avoid scratching or breakage.
Page 138 1993 Volvo 960 License plate light (sedan models) Turn off the lights. Remove both screws and insert the screwdriver and turn it carefully (see illustration) until the glass comes loose. Replace the bulb and reinstall the glass. Bulb Power Socket License plate light 5W W 2.1x9.5d...
Page 139 1993 Volvo 960 clockwise. Remove the bulb. Install a new bulb and re-install lamp housing. Bulb Power Socket License plate light 4 W BA9s pg. 6:10 Replacing bulbs High-mounted brake light To remove: (Sedans) Turn off ignition. Depress catch with a screwdriver. Pull cover upward to remove it.
Page 140 1993 Volvo 960 Depress catches and fit new bulb. To fit: Fit the reflector and check that the light works. 4-door models Press the cover into position, noting the position of the alignment pin at the top. Wagons Align the catches and press the cover into position.
Page 141 1993 Volvo 960 pg. 6:11 Replacing bulbs Interior light and reading lights Take hold of the front section of the light as shown and pull straight down. Press lens out from inside and replace bulb. Check operation before reinstalling lamp housing.
Page 142 1993 Volvo 960 Bulb Power Socket Interior light 10 W SV 8.5 Reading light 5 W W 2.1x9.5d The bulb in the adjustable reading lamps can be changed as follows: insert a screwdriver as shown and twist off the lamp. Withdraw the bulb and fit a new one.
Page 143 1993 Volvo 960 Door warning lamps All doors are equipped with red warning lamps. To replace a bulb, insert a screwdriver as shown in picture and gently turn it to remove the lens. Withdraw the bulb, replace it and re-insert the lens.
Page 144 1993 Volvo 960 Fuse replacement If an electrical component fails to function, it is likely that a fuse has blown due to an overloaded circuit. The fuse box is located on the far left side of the dashboard. Spare fuses and the fuse tool are located in an illuminated compartment in the fuse box.
Page 145: Car Care
The plastic in the upholstery can be washed with soapy water or a mild detergent. Leather upholstery can be cleaned with a soft cloth and mild soap solution. For more difficult spots, consult your Volvo dealer. On no account must gasoline, naphtha or similar cleaning agents be used on the plastic or the leather since these can cause damage.
Page 146 Rustproofing, inspection and touching-up Your Volvo was carefully and thoroughly rustproofed at the factory. The underbody and wheelhousings were sprayed with a thick, durable rustproofing compound and the beams, internal cavities and end sections were sprayed with a low viscous, penetrating rustproofing agent.
Page 147 7:4 Rustproofing (cont.) The visible rustproofing The visible (external) rustproofing must be inspected by an authorized Volvo dealer at least once a year. If it is necessary to touch-up the rustproofing, this should be done immediately to prevent moisture penetration.
Page 148 Minor scratches can be repaired by using Volvo touch-up paint. NOTE: When ordering touch-up paint from your Volvo dealer, use the paint code indicated on the model plate. The plate is located on the panel above the right-side head lights.
Page 149 1993 Volvo 960 Minor stone chips and scratches Material: Primer - can Paint - spray can or touch-up bottle Brush Masking tape Note: When touching up the car, it should be clean and dry. The surface temperature should be above 60°F (+15°C).
Page 150 1993 Volvo 960 2 Thoroughly mix the primer and apply it with a small brush. When the primer surface is dry, the paint can be applied using a brush. Mix the paint thoroughly: apply several thin paint coats and let dry after each application.
Page 151 1993 Volvo 960 Primer - spray can Paint-spray can Masking tape Note: When touching up the car, it should be well cleaned and dry and have a temperature exceeding 60° F (+15°C). When large surfaces have to be repainted, suitably mask the surrounding area with masking tape and paper.
Page 152 1993 Volvo 960 Washing the car The car should be washed at regular intervals since dirt, dust, insects and tar spots adhere to the paint and may cause damage. When washing the car, do not expose it to direct sunlight. Use lukewarm water to soften the dirt before you wash with a sponge, and plenty of water, to avoid scratching.
Page 153 1993 Volvo 960 WARNING! When the car is driven immediately after being washed, apply the brake several times in order to remove any moisture from the brake linings. Engine cleaning agents should not be used when the engine is warm. This constitutes a fire risk.
Page 154 1993 Volvo 960 After polishing use liquid or paste wax. Several commercially-available products contain both polish and wax. Waxing alone does not substitute for polishing of a dull surface. A wide range of polymer-based car waxes can be purchased today. The waxes are easy to use and produce a long-lasting, high-gloss finish that protects the bodywork against oxidation, road dirt and fading.
Page 155 2 Vehicle Emission Control Information Your Volvo is designed to meet all applicable emissions standards, as evidenced by the certification label on the right side of the firewall. For further information regarding these regulations, please consult your Volvo dealer.
Page 156: Specifications
5 Federal Motor Vehicle Safety Standards (FMVSS) specifications (USA) and Ministry of Transport (CMVSS) Standards (Canada) Your Volvo is designed to meet all applicable safety standards, as evidenced by the certification label on the rear facing side of the driver's door. For further information regarding these regulations, please consult your Volvo dealer.
Page 157 1993 Volvo 960 Your Volvo has passed several major inspections before being delivered to you, according to Volvo specifications. The maintenance services outlined in this book should be performed as indicated. The extended maintenance service intervals make it even more advisable to follow this program. Inspection and service should also be performed any time a malfunction is observed or suspected.
Page 158 1993 Volvo 960 Air Cleaner Filter Spark Plugs Automatic Transmission fluid Rear Axle Oil Timing belt - B 6304 F 1) See section "Engine oil" for detailed information. 2) For services beyond 60,000 miles (96,000 km), consult your "Maintenance records manual" and "Maintenance Service Chart."...
Page 159 1993 Volvo 960 Trunk, Hood Hinges and Latches The following items should be checked weekly by the driver (it takes only a few minutes): Engine oil level Windshield wipers Cleaning Brake fluid level Level of windshield washer fluid Rust protection...
Page 160 1993 Volvo 960 pg. 8:13 Engine compartment Engine compartment 960 (engine B 6304 S) 1 Expansion tank, coolant 2 Oil filler cap, engine 3 Engine oil dip-stick 4 Brake fluid reservoir 5 Data Plate 6 Battery 7 Radiator 8 Power steering fluid reservoir...
Page 161 8 Front seat slide rail and latch Oil 9 Door lock keyhole Low temperature grease or Volvo Teflon lock spray To avoid rattles and unnecessary wear, the body should be lubricated at regular service intervals. This should be done by an authorized Volvo retailer.
Page 162 Check, without removing the cap, that the level is above the "MIN" mark of the fluid reservoir. Always entrust brake fluid changing to an authorized Volvo retailer. Power steering fluid The fluid level should lie between the MIN and MAX on the side of the dipstick. The space between the marks corresponds to 0.2 US qts/liters.
Page 163 WARNING! The engine must not be running when this check is performed. NOTE : The belt on the 960 is equipped with a self-tensioning mechanism and requires no adjustment between changes. pg. 8:17 Cooling system file:///K|/ownersdocs/1993/1993_960/93960_8_13.html (4 of 6)12/30/2006 9:47:14 AM...
Page 164 Add coolant until the level is up to the MAX mark or slightly above. Start the engine and run until hot. Check the cooling system connections for tightness. Also re-check the coolant level. Capacity: See "Specifications" CoolAnt: Volvo Genuine Coolant/Antifreeze only file:///K|/ownersdocs/1993/1993_960/93960_8_13.html (5 of 6)12/30/2006 9:47:14 AM...
Page 165 1993 Volvo 960 CAUTION The cooling system must always be kept filled to correct level. If it is not kept filled, there can be high local temperatures in the engine which could result in damage. Different types of anti-freeze/coolant may not be mixed.
Page 166 WARNING! The oil may be very hot. If you change the engine oil and filter yourself, your Volvo retailer can assist you in disposing of the used oil. Engine oil can be harmful to your skin - gloves should worn when performing this work.
Page 167 8:7 Engine Oil, 10,000-mile (16,000-km) oil/oil filter change interval Oil quality Meeting API specification SG For best fuel economy and engine protection consult with your authorized Volvo retailer for recommended oils. Oils with a different quality rating may not provide adequate engine protection. Viscosity (stable ambient temperatures):...
Page 168 Changing oil and oil filter Oil and oil filter are first changed at 5,000 miles (8,000 km). This service is provided by Volvo to the owner at no cost. The next oil and filter change occurs at the 10,000 mile (16,000 km) service and...
Page 169 1993 Volvo 960 Volvo recommends the use of oils with the American Petroleum Institute (API) label, This label certifies that the oil conforms to the applicable standards and specifications of the API. pg. 8:8 Servicing Torque exhaust and intake manifold nuts A loose manifold could alter air/fuel ratio and cause an increase in emissions and/or poor driveability.
Page 170 Volvo recommends that the this belt be replaced at 30,000 mile (48,000 km) intervals. The first replacement at 30,000 miles (48,000 km) is provided by Volvo at no cost to the owner. All subsequent replacements are the responsibility of the car owner.
Page 171 1993 Volvo 960 Three-way Catalytic Converter This is a supplementary device in the exhaust system, designed to clean exhaust gases. This device is mainly a container with a ceramic material insert, designed to let the exhaust gases pass through channels in the insert. The channel walls are covered by a thin layer of platinum-palladium. These metals act as catalysts, permitting a chemical action to occur without actually taking part in it.
Page 172 1993 Volvo 960 Evaporative control system The car is quipped with a gas evaporative control system, which prevents gasoline fumes from being released into the atmosphere. The system is compromised of an expansion chamber in the fuel tank, a roll-over valve on the cross member in front of the fuel tank, and a charcoal canister with built-in vacuum valve under the left-front wheel housing.
Page 173 1993 Volvo 960 PCV system The orifice nipple in the intake manifold and the filter at the end of the PCV hose in the aircleaner should be inspected every 60,000 miles (96,000 km). Check/replace rubber hoses at the same time.
Page 174 1993 Volvo 960 Adjusting washer nozzles The washer jets should spray the windshield as shown. Use the edge of a small screwdriver to adjust the nozzles, if necessary. Washer fluid reservoir The washer fluid reservoir is located in the engine compartments and holds approx. 0.5 US gal. (2 liters) - sedans and 0.8 US gal (3.2 liters) - wagons.
Page 175 Oil quality Meeting API specification SG For best fuel economy and engine protection, consult with your authorized Volvo retailer for recommended oils. Oil with designation SG/CD complies with this requirement. Oil with a different quality rating may not provide adequate engine protection.
Page 176 1993 Volvo 960 960 (6 cyl. engine) Capacity (including filter) : 5.9 US qts = 5.75 liters SAE 15 W/40 oil is recommended for use in severe driving conditions which involve high oil temperatures or excessive oil consumption (e.g. mountain driving with frequent deceleration, or high- speed driving.)
Page 177 1993 Volvo 960 Type designation Volvo B 6304 S 6 cyl. Output (SAE J 1349) 201 hp at 6000 rpm (150 kW at 100rps) Max. torque (SAE J 1349) at rpm 197 ft. lbs. (267 Nm) at 4300 rpm Number of cylinders 6 Bore 3.27"...
Page 178 1993 Volvo 960 pg. 9:5 Specifications POWER TRANSMISSION Automatic transmission: AW 30/4 Reduction ratios: 1st gear 2.80:1 2nd gear 1.53:1 3rd gear 1:1 Overdrive 0.71:1 Reverse 2.39:1 Rear axle: Reduction ratio 3.31:1 All specifications are subject to change without notice.
Page 179 Generator, rated output 1400 W max. current 120 Amp The battery contains corrosive and poisonous acids. It is of the utmost importance that old batteries are disposed of correctly. Your Volvo retailer can assist you in this matter. Bulbs Bulb Trade No.
Page 180 1993 Volvo 960 * Sedan ** Wagon The following bulbs may be obtained from your nearest Volvo retailer: Bulbs License plate light (wagon) (sedan) Door warning lights Interior light Reading lights, front rear Trunk light Glove box light Instrument lighting...
Page 181 9:7 Specifications Vehicle Loading The tires on your Volvo should perform to specifications at all normal loads when inflated as recommended on the tire information label. The label is located on the rear-facing edge of the right-front door. This label lists both tire and vehicle design limits. Do not load your car beyond the load limits indicated.
Page 182 * if oil cooler is drained, add 0.47 US qts (0.4 liter) pg. 9:8 Service manuals, Road assistance Service Manuals for your Volvo are available for purchase. These are the same manuals used by competent Volvo technicians. Major sections within the Service Manual System include: 0-General Information; 1- Lubrication and Service;...
Page 183 Besides passing exams each mechanic must also have worked in the field for two or more years before a certificate is issued. These professional mechanics are fully able to analyze vehicle problems and perform the necessary service procedures to keep your Volvo at peak operating condition.
Page 184 See also section "Trailer hauling". * The max permissible axle loads or gross vehicle weight must not be exceeded. Consult your Volvo retailer for information. WARNING: When adding accessories, equipment, luggage and other cargo to your vehicle, the total loaded weight capacity of the vehicle must not be exceeded.
Page 185 Your car is equipped with an accessory connector located under the dashboard on the driver's side. Please consult your Volvo retailer if you have any questions before connecting accessory or optional equipment to the vehicle's electrical systems.
Page 186 1993 Volvo 960 Octane rating, see p. 4:3. Tire pressure, see label located on rear edge of right front door. Bulbs Power Socket 45/65 file:///K|/ownersdocs/1993/1993_960/93960_9_7.html (6 of 7)12/30/2006 9:47:19 AM UNLEADED FUEL ONLY VOLVO US Bulb 9004...
Page 187 1993 Volvo 960 27 W BA 15s 21 W BA 15s 21/5 W VOLVO Volvo Car Corporation Goteborg, Sweden TP 3362/2 (Canada & U.S.A.) 7000.9.9 file:///K|/ownersdocs/1993/1993_960/93960_9_7.html (7 of 7)12/30/2006 9:47:19 AM GE881 1156 1157 Contents Top of Page...

This manual is also suitable for:

1993 960

Volvo 960 Owner's Manual

Quick Links

Contents

Related Manuals for Volvo 960

Summary of Contents for Volvo 960

This manual is also suitable for:

Table of Contents
